Notice: The description and illustration in this booklet are not to be taken as binding on
the manufacturers. The essential features of the type described and illustrated herein
remaining unaltered, Bajaj Auto Limited reserves the right to carry out at any moment
without being obliged to bring this booklet upto-date, Modifications on the vehicle, parts
or accessories as may be convenient and necessary.
Safety and Warning Information :
Warning : This indicates that a potential hazard or injury to you or other persons & to the
vehicle can happen if advice provided is not followed
Caution : This indicates that a potential hazard that could result in vehicle damage.
Follow the Advice provided with the caution.
Description
1. Technical Specifications................. 1
2. Location of Parts............................ 2
3. How to Ride Motorcycle................ 10
4. Safe Riding Tips..............................11
5. Running In Instruction.....................11
6. Daily Safety Checks........................12
7. Periodic Maintenance Information......... 13
8. Periodic Maintenance/ Service Record. 16
9. Periodic Part Replacement Schedule....18
10. Applicable to all services 19
11. Non-use Maintenance.............................20
Table of Contents
Location of Parts : Speedometer Indicators Technical Specifications
Engine : 4 Stroke, Single Cyl.,
Natural air/ Oil cooled
Bore x Stroke : 67.00mm x 62.4mm
Engine Displacement : 220 cc
Compression Ratio : 9.5 + 0.5 : 1
Idling Speed : 1400 + 100
Max. Net Power 21 PS at 8500 rpm.:
Max. Net Torque 19.12 Nm at 7000 rpm.:
Ignition System : Digital CDI
Spark Plug : 2 Nos. Champion
RG6HCC
Spark Plug Gap : 0.8 to 0.9 mm
Lubrication : Wet sump, Forced
Transmission : 5 speed constant mesh
Brakes (Frt. & Rr.) : Hydraulic operated disc
brakes
Fuel Tank Capacity :
Full : 15.0 liters
Reserve : 3.2 liters
Usable Reserve : 2.0 liters
Tubeless Tyre Size :
Front : 90/90 x 17,49P
Rear : 120/80 x 17, 61P
Tyre Pressure :
Front : 2kg / cm2 (28 PSI)
Rear (solo) : 2 kg / cm2 (28 PSI)
Rear (pillion) : 2.25 kg / cm2 (32 PSI)
Dimensions :
Length : 2035 mm
Width : 750 mm
Height : 1165 mm
Wheel base : 1350 mm
Min. Turning Radius : 2500 mm
Ground Clearance : 165 mm (Min.)
Electrical System : 12 Volts DC
Head Lamp : 55/55 W-H7 (for F)
: 35/35 W (for S)
Pilot Lamp : 5 W Each 2 Nos.
Tail /Stop : LED/LED
Turn Signal Indi. : 10 W - 12 V
Neutral Indicator : LED
Hi Beam Indicator : LED
Turn Pilot Indicator : LED
Side Stand Indi. : LED
Speedometer : LCD Display
Rear No. Plate : 5 W
Horn : 12 V DC (2 Nos.)
Battery : 12V - 9 Ah
Vehicle Kerb Wt. : 152 kg. (for F)
: 148 kg. (for S)
Gross Vehicle Wt. : 282 kg. (for F)
: 278 kg. (for S)
Climbing Ability : 28% (160max)
Note : All dimensions are under UNLADEN condition. Above information is subject to change.
1. Side stand indicator : When Side stand is ‘ON’, the Side stand indicator will be lit.
2. Turn signal indicator : When turn signal switch is turned to LH/RH, pilot indicator flash.
3. Trip meter : It shows the distance travelled since it was last reset to zero.
4. Trip meter knob : Reset trip meter to zero by pressing the trip meter knob.
5. Speedometer : The vehicle speed is displayed digitally.
6. Odometer : The Odometer shows the total distance that the vehicle has accumulated.
7. Fuel level indicator : Fuel level indicator shows available fuel in fuel tank.
8. Tachometer : It shows the engine speed in RPM.
9. Neutral indicator : When the transmission is in neutral, the neutral indicator light will lit.
10. Hi beam indicator : ,When the H/L is on high beam the hi beam indicator light will lit.
5
1
6
3
10
9
2
4
8
7
1
2
Location of Parts (220 F) Location of Parts (220 S)
Front Fork
Clutch Lever
Fuel
Tank
Rear
Shock Absorber
Grab
Handle
Pillion
Foot Rest
Gear Change
Lever
Side
Stand
Center
Stand
Accelerator
Grip
Front Brake
Lever
Rear Brake
Pedal
Center Stand
Silencer
Accelerator
Grip
Fuel
Tank
Rear
Shock
Absorber
Front Fork
Grab
Handle
3
4
