www.bakerspride.com | p: (800) 527-2100 265 Hobson St. • Smithville, TN 37166
Bakers Pride
®
C-RS series charbroilers feature a standard-
profile design and 15,000 BTU burners for energy
efficiency and broiling performance. Models come in
a range of sizes from 24" to 72" wide. Stainless steel
radiants come standard, as do steel floating rod grates,
which may be adjusted in four separate titling positions
for increased flexibility and temperature control.
A continuously lit, cross-over pilot tube system makes
lighting burners quick and easy. Fully insulated, double
walls help with heat retention, while stainless steel
interior and exterior construction makes this charbroiler
both durable and easy to clean.
This series also offers many options to suit your needs,
such as log holders or Glo-Stones for enhanced flavor
and work decks for added convenience.
• C-RS Radiant - V-shaped radiant
for each burner
• C-RS Glo-Stones - Ceramic coal
screen
• Burners are controlled with a single
valve
• Natural gas or liquid propane
• Steel floating rod grates
(standard) or cast-iron or meat
grates
• Continuously lit crossover pilot
tube
• Double-walled, fully insulated
construction
• Stainless steel exterior, interior,
and combustion chamber
• Stainless steel radiants
• 3/4” NPT rear gas connection
• Towel bar
• One-year limited warranty
FEATURES AT A GLANCE
• Cast-iron radiants
• Glo-Stones
• Natural woodsmoke essence box
• Cut-outs in 10” work deck
• Gas connector hose
• Stainless steel splash guard
• Overhead back shelves
• Warming rack
• 10" work deck
• Stand with casters
• High output burners
OPTIONS & ACCESSORIES
SERIES: C-RS
DANTE SERIES STANDARD-PROFILE COUNTERTOP CHARBROILERS
www.bakerspride.com | p: (800) 527-2100 265 Hobson St. • Smithville, TN 37166
MECHANICAL SPECIFICATIONS
Model
No.
BTU
STANDARD/
HIGH OUTPUT
KW
STANDARD/
HIGH OUTPUT
# Grids
# Burners
Broiling Area
in² (cm²)
Counter Space
(W x D)
Cubic
Feet
Ship Wt.
C-24RS
60,000/
80,000
17.6/
23.4
1 4
513 in²
(3,314 cm²)
24" x 35.5"
(610mm x 902mm)
21.6 ft³
(0.6m³)
412 lbs.
(186.9kg)
C-36RS
105,000/
140,000
30.8/
41.0
1 7
810 in²
(5,233 cm²)
36" x 35.5”
(915mm x 902mm)
21.6 ft³
(0.6m³)
601 lbs
(272.6kg)
C-48RS
150,000/
200,000
44.0/
58.6
2 10
1,107 in²
(7,145 cm²)
48" x 35.5”
(1,219mm x 902mm)
35.9 ft³
(1.0m³)
668 lbs.
(303kg)
C-60RS
195,000/
260,000
57.2/
76.2
3 13
1,404 in²
(9,063 cm²)
60" x 35.5”
(1,524mm x 902mm)
35.9 ft³
(1.0m³)
912 lbs.
(413.7kg)
C-72RS
240,000/
320,000
70.0/
94.1
3 16
1,704 in²
(11,001 cm²)
72" x 35.5”
(1,829mm x 902mm)
43.1 ft³
(1.2m³)
1,078 lbs.
(489kg)
*Height includes 4" adjustable (102 mm) legs.
EQUIPMENT DIMENSIONS
REQUIRED CLEARANCES
Non-Combustible
Left 0" (0 mm)
Right 0” (0 mm)
Back 0” (0 mm)
GAS CONNECTIONS
Natural or LP gas
3/4" NPT on Standard Units
1/2” NPT on Safety Piolt Units
SERIES: C-RS
DANTE SERIES STANDARD-PROFILE COUNTERTOP CHARBROILERS
Freight Class: 70
FOB: Smithville 37166
Bakers Pride reserves the right to modify specifications or discontinue
models without incurring obligation. Dimensions nominal.
2M-Z24096 • REV E • (12-21)
SK2997
