Sida 1/16
1 2 3 4 5
6
End of programme when ...
Interrupting the programme
Programmes at high temperatures:
– Cool washing: Select
Programmes at lower temperatures:
Changing the programme, if ...
... you have selected the wrong programme by mistake:
– Reselect the programme.
the beginning.
Correct installation according to the
separate Installation instructions.
Checking the machine
– Never use a damaged machine.
– Inform the after-sales service.
Connecting the mains
plug
Make sure your hands are dry.
Take hold of the plug only.
Turning the tap on
Compartment II: Detergent for the main wash, water softener,
bleach, stain remover
Sorting and loading laundry
Follow the manufacturer's care information.
According to the information on the care labels.
According to type, colour, soiling and temperature.
Insert large and small items of laundry.
Close the washing machine door. Take care not to trap items of laundry
between the washing machine door and the rubber seal.
Add detergent and care products
Measure accordingly:
Amount of laundry, soiling, water hardness (ask your water supply
company) and manufacturer's instructions.
Pour liquid detergent into the appropriate dispenser and place in the drum.
Your washing machine
domestic appliance manufactured by Balay. This washing machine
is distinguished by its economical water and energy consumption.
Each machine that leaves our factory has been inspected thoroughly
to ensure that it functions properly and is in perfect condition.
For further information and a selection of our products go to our web
site:
www.balay.es
All packaging must be disposed of in accordance with
environmental guidelines.
This appliance is certified in accordance with European Directive
2002/96/EC on waste electrical and electronic equipment (WEEE).
This directive provides the framework for the EU-wide collection and
reuse of used appliances.
Intended use
Contents Page
Environmental protection/Conservation tips
– Always fill the washing machine with a maximum amount of
laundry for the relevant programme.
– Wash normally soiled washing without a pre-wash (model-
dependent).
– Instead of choose the resistentes/algod. (cottons) 90 °C,
programme
resistentes/algod. extra (cottons extra) 60 °C. Comparable
cleaning result with significantly lower energy consumption.
– Measure the detergent according to the manufacturer's
instructions and water hardness.
– If the laundry is then dried in the tumble dryer, select the spin
speed according to the instructions of the dryer manufacturer
(model-dependent).
Preparation
Before washing for the first time
Setting and adjusting programmes
Programme selector Start
Programme selector for
switching the machine on
and off and for selecting
the programme. Can be
turned in either direction.
Programmes
resistentes/algod. (cottons) hard-wearing fabrics
resistentes/algod. extra
(cottons extra)
hard-wearing fabrics
resistentes/algod. + prelav.
(cottons + prewash)
hard-wearing fabrics prewash at ,
30 °C
delicado (delicates) delicate washable fabrics
sintéticos (easy-care) easy-care fabrics
page 5.
Washing
1
2
Removing the washing
Open the washing machine door and remove the washing.
speed (model-dependent).
– Remove any foreign objects - risk of rusting.
– Leave the washing machine door and detergent
drawer open so that any residual water can
evaporate.
Turning the tap off
Switching off
Turn the programme selector to .stop (off)
Washing
Detergent drawer with
Washing machine
door
Compartment I: Detergent for pre-wash ( )model-dependent
in detergent solution,
cially available detergents and care products which are
suitable for use in washing machines.
.
– Do not leave children unattended near the
washing machine.
– The washing machine is not to be used by
children or persons not familiar with the
operating instructions.
– Keep pets away from the washing machine.
Dilute thick fabric softener and fabric conditioner with water.
This prevents blockages.
Individual settings
For starting the programme.
Important information
Protecting the washing and the machine
– When determining the dosage of all washing powders, additives and cleaning agents, you
must follow the manufacturer's instructions.
– Empty pockets.
– Look out for metal items (paperclips, etc.).
– Wash delicates in a laundry bag (tights, curtains, underwired bras).
– Fasten zips, do up any buttons.
– Brush sand out of pockets and collars.
– Remove curtain fittings or place in the laundry bag.
Washing with varying degrees of soiling
Wash new items of clothing separately.
light Do not pre-wash.
If required, pretreat stains.
Select programme .resistentes/algod. extra (cottons extra) 60 °C
heavy Load less washing. Select programme resistentes/algod. + prelav.
(cottons + prewash) 60°C.
Starching Washing must not be treated with fabric softener
Starching is possible in all wash programmes if liquid starch is used. Pour the starch in
if necessary).
Dyeing / Bleaching
Dye should only be used in normal household quantities. Salt may damage stainless steel.
Always follow the dye manufacturer's instructions! Do not use the washing machine for
bleaching clothes!
Additional
function*
3
Drum
Control panel
Service flap for
detergent solution
pump
Status
indicators
(*spin speed depending on model)
7
Programmes °C max. Type of laundry Additional functions; information
resistentes/algod.
(cottons)
frio (cold),
40, 60, 90 °C
7 kg Hard-wearing fabrics, heat-resistant fabrics made of cot-
ton or linen
resistentes/algod. extra
(cottons extra) 60 °C
resistentes/algod. + prelav.
(cottons + prewash)
sintéticos (easy-care) frio (cold),
40, 60 °C 3 kg Easy-care fabrics made of cotton, linen, synthetic fibres
or blended fabrics
delicado (delicates) frio (cold)
2 kg
For delicate, washable fabrics, e.g. made of silk, satin,
synthetic fibres or blended fabrics (e.g. curtains) No spin between rinse cycles
taining wool
Particularly gentle wash programme to prevent
shrinkage of laundry. Longer programme breaks (fab-
rics rest in the detergent solution)
(depending on model).
0311 / 9000658854
*658854* 3TS70121A ...
Balay Electrogeräte GmbH
81739 Munich / Alemania
8
Safety instructions
– Read the instruction manual and installation instructions and all other information enclosed
with the washing machine and act accordingly.
– Retain the documents for subsequent use.
Risk of electric shock – Never pull the cable to disconnect the mains plug.
– Never insert/disconnect the mains plug with damp hands.
Danger to life For worn-out appliances:
– Disconnect the mains plug.
– Sever the mains cable and discard along with the plug.
– Destroy the lock on the washing machine door. This will prevent
children from locking themselves in and risking their lives.
Danger of suffocation – Keep packaging, film and packaging parts out of the reach of
children.
Risk of poisoning – Keep detergents and care products out of the reach of children.
Risk of explosion – Items of laundry pretreated with cleaning agents containing
solvents, e.g. stain remover/cleaning solvent may cause an
explosion after being loaded into the washing machine.
Rinse items of laundry thoroughly by hand beforehand.
Risk of injury – The washing machine door can become very hot.
– Be careful when draining hot detergent solution.
– Do not climb onto the washing machine.
– Do not lean on the open washing machine door.
– Do not reach into the drum if it is still rotating.
– Be careful when opening the detergent drawer while the machine
is in operation.
Consumption values depending on model
Programme Load Electricity Water*** ***
Programme
duration
***
resistentes/algod. (cottons) 40 °C* 7 kg 0,85 kWh 65 l 02:25 h
resistentes/algod. (cottons) 60 °C* 7 kg 1,40 kWh 65 l 02:40 h
resistentes/algod. (cottons) 90 °C 7 kg 2,10 kWh 70 l 02:40 h
sintéticos (easy-care) 40 °C* 3 kg 0,55 kWh 48 l 01:15 h
delicado (delicates) frío (cold) 2 kg 0,28 kWh 48 l 00:44 h
* Programme setting for testing in accordance with valid standard EN60456.
Note on comparative tests: For testing the test programmes, wash the specified load using the maximum spin speed
(
depending on model).
Programme Load
Annual energy
consumption
Annual water
consumption
resistentes/algod. (cottons) 40 °C** /
resistentes/algod. extra (cottons extra) 60 °C**
7/3kg 219 kWh 10900 l
** Programme setting for testing and energy labelling in accordance with EU directive 2010/30/EU with cold water (15 ºC).
*** The values deviate from the indicated values depending on water pressure, hardness, and inlet temperature, ambient tem-
perature, type, amount and soiling of the laundry, detergent used, fluctuations in the power supply and selected additional
functions.
9
Care
Before washing for the first time
Do not load any laundry into the machine. Turn on the tap. Add the following to
compartment :II
– approx. 1 litre water
– detergent (dosage according to the manufacturer's instructions for light soiling and the
appropriate degree of water hardness)
the end of the programme, turn the programme selector to .stop (off)
Machine housing, control panel
– Wipe with a soft, damp cloth.
– Do not use any abrasive cloths, scourers or cleaning agents (stainless steel cleaners).
– Remove detergent and cleaning agent residue immediately.
– Do not clean with a jet of water.
Cleaning the detergent drawer...
...if it contains detergent or fabric softener residues.
1. Pull out, press insert down, remove draw completely.
2. To remove the insert: press the insert upwards from below with your
finger.
3. Clean the detergent dispenser tray and insert with water and a brush and
dry it.
4. Attach the insert and engage (connect the cylinder to the guide pin).
5. Push in the detergent drawer.
Leave the detergent drawer open so that any residual water can
evaporate.
Drum
Leave the washing machine door open so that the drum can dry out.
Rust stains - use chlorine-free cleaning agent, not steel wool.
Descaling Ensure there is no laundry in the machine
Descale the appliance according to the descaler manufacturer's instructions. This should not
be necessary if the correct dosage of detergent is used.
Information to indicator lights
Indicator lights for status displays and/or buttons flash:
Indicator lights
Close the washing machine door properly; laundry may be caught.
Indicator lights
Open the tap completely, supply hose kinked or trapped;
Indicator lights
Detergent solution pump blocked; Clean the detergent solution pump
Drainage hose/waste pipe blocked; Clean the drainage hose at the
Indicator light
Motor fault. Call the after-sales service.
All indicator lights flash Turn off the tap and call the after-sales service.
–Risk of electric shock. Disconnect the mains plug.
–Risk of explosion. No solvents.
10
Maintenance
Detergent solution pump
Turn the programme selector to and disconnect the mains plug.stop (off)
1. Open and remove the service flap.
2. For models with a drainage hose: Remove the drainage hose from the retainer and pull it
from the housing. Remove the container.
Remove the sealing cap, allow the detergent solution to flow out.
Replace the sealing cap and place the drainage hose in the retainer.
2* For models without a drainage hose: Carefully unscrew the pump cover until the
detergent solution begins to flow out. When the service flap is half full, close the pump cover
and empty the service flap. Repeat the above steps until all the detergent solution has
completely drained out.
3. Carefully unscrew the pump cover (residual water).
4. Clean the interior, pump cover thread and pump housing (the impeller in the detergent
solution pump must rotate).
5. Replace the pump cover and screw it in place tightly.
6. Place the service flap back on and close.
To prevent unused detergent from flowing straight into the drain during the next wash: Pour 1 litre of water into
Drainage hose at the siphon
Turn the programme selector to and disconnect the mains plug.stop (off)
1. Loosen the hose clamp, carefully remove the drainage hose (residual water).
2. Clean the drainage hose and siphon connecting piece.
3. Reattach the drainage hose and secure the connection with the hose clamp.
Filter in the water supply
Reduce the water pressure in the supply hose:
1. Turn off the tap.
4. Turn the programme selector to . Disconnect the mains plug. stop (off)
Clean the filter:
1. Depending on model:
Disconnect the hose from the tap.
Clean the filter using a small brush.
and/or for Standard and Aqua-Secure models:
Remove the hose on the rear of the appliance,
Remove the filter with pliers and clean.
2. Connect the hose and check for leaks.
–Risk of scalding.
Allow the detergent solution to cool down.
– Turn off the tap.
11
What to do if...
Water is leaking out. – Attach/replace the drainage hose correctly.
– Tighten the screw connection of the supply hose.
No water supply.
Detergent not dispensed.
– Tap not turned on?
– Supply hose kinked or trapped?
Washing machine door cannot
be opened.
– Safety function active. Wait approx. 2 minutes.
– Washing machine door closed?
Detergent solution is not
drained.
– Clean the waste pipe and/or drainage hose.
Water not visible in the drum. – Not a fault - water below the visible area.
Unsatisfactory spin result.
Laundry wet/too damp.
– Not a fault - the unbalanced-load detection system has cancelled the spin cycle
because of uneven distribution of the laundry.
Distribute small and large items of laundry evenly inside the drum.
Spin cycle performed several
times.
– Not a fault - unbalanced load detection system adjusts the imbalance.
Residual water in the
compartment for care
products.
– Not a fault - the action of the care product is not affected.
Odour formation in the washing
machine.
– Run programme without laundry. Use resistentes/algod. (cottons) 90 °C
standard detergent.
Foam escaping from the
detergent drawer.
– Too much detergent used?
If foam is escaping from the detergent drawer:
Mix 1 tablespoon of fabric softener with ½ litre of water and pour into
compartment I
I
I
I
II (not with outdoor or down fabrics).
– Reduce the detergent dosage for the next wash cycle.
Intense noise formation,
vibrations and “walking” during
the spin cycle.
– Are the appliance feet fixed?
– Transportation safety devices removed?
Noises during spin and drain
cycles.
The indicator lights do not
function during operation.
– Power cut?
– Fuses tripped? Reset/change the fuse.
– If the fault occurs repeatedly, call the after-sales service.
Programme sequence longer
than usual.
– Not a fault - unbalanced load detection system adjusts imbalance by repeatedly
distributing the laundry.
– Not a fault - foam detection system active - adds an additional rinse cycle.
Detergent residues on the
laundry.
– Occasionally, phosphate-free detergents contain water-insoluble residues.
If you cannot correct a fault yourself (switching on/off) or a repair is required:
– Turn the programme selector to and remove the mains plug from the socket.stop (off)
Instruction manual
en
Washing
machine
Observe the safety instructions on page 8!
Read these instructions and the separate
installation instructions before operating
the washing machine.
1 2
Correct installation according to the
separate Installation instructions.
Checking the machine
– Never use a damaged machine.
– Inform the after-sales service.
Connecting the mains
plug
Make sure your hands are dry.
Take hold of the plug only.
Turning the tap on
Compartment II: Detergent for the main wash, water softener,
bleach, stain remover
Po
Your washing machine
domestic appliance manufactured by Balay. This washing machine
is distinguished by its economical water and energy consumption.
Each machine that leaves our factory has been inspected thoroughly
to ensure that it functions properly and is in perfect condition.
For further information and a selection of our products go to our web
site:
www.balay.es
All packaging must be disposed of in accordance with
environmental guidelines.
This appliance is certified in accordance with European Directive
2002/96/EC on waste electrical and electronic equipment (WEEE).
This directive provides the framework for the EU-wide collection and
reuse of used appliances.
Intended use
Contents Page
Environmental protection/Conservation tips
– Always fill the washing machine with a maximum amount of
laundry for the relevant programme.
– Wash normally soiled washing without a pre-wash (model-
dependent).
– Instead of resistentes/algod. (cottons) 90 °C, choose the
programme
resistentes/algod. extra (cottons extra) 60 °C. Comparable
cleaning result with significantly lower energy consumption.
– Measure the detergent according to the manufacturer's
instructions and water hardness.
– If the laundry is then dried in the tumble dryer, select the spin
speed according to the instructions of the dryer manufacturer
( ).model-dependent
Preparation
Programme selector Start
Pro
swi
and
the
turn
Programmes
resistentes/algod. (cottons) hard-wearing fabrics
resistentes/algod. extra
(cottons extra)
hard-wearing fabrics
resistentes/algod. + prelav.
(cottons + prewash)
hard-wearing fabrics prewash at ,
30 °C
delicado (delicates) delicate washable fabrics
sintéticos (easy-care) easy-care fabrics
Compartment I: Detergent for pre-wash ( )model-dependent
in detergent solution,
cially available detergents and care products which are
suitable for use in washing machines.
.
– Do not leave children unattended near the
washing machine.
– The washing machine is not to be used by
children or persons not familiar with the
operating instructions.
– Keep pets away from the washing machine.
Additional
function*
Status
indicators
(*spin speed depending on model)
Produktspecifikationer
| Varumärke: | Balay |
| Kategori: | tvättmaskin |
| Modell: | 3TS70105T |
| Bredd: | 600 mm |
| Djup: | 590 mm |
| Höjd: | 848 mm |
| Sladdlängd: | 1.6 m |
| Energieffektivitetsklass (gammal): | A |
| Strömförsörjning: | 220 - 240V 50 Hz |
| Maximal centrifugeringshastighet: | 1000 RPM |
| Cykeltid (max): | 155 min |
| Tvättprogram: | Hygiene/anti-allergy, Black |
| Nominell kapacitet: | 7 kg |
| Produktens färg: | Silver |
| Strömförbrukning (vanlig): | 2300 W |
| Tvättklass: | A |
| Apparatens placering: | Fristående |
| Gångjärnssida: | Vänster |
| Ström: | 10 A |
| Laddning: | Frontmatad |
| Centrifugering klass: | C |
| Fördröjd start: | 0 h |
| Vattenförbrukning per omgång: | 49 l |
| Energiförbrukning vid tvätt: | 1.19 kWh |
| Lastbalansering systemet: | Ja |
| Skumkontrollssystem: | Ja |
Behöver du hjälp?
Om du behöver hjälp med Balay 3TS70105T ställ en fråga nedan och andra användare kommer att svara dig
tvättmaskin Balay Manualer
18 Juli 2025
18 Juli 2025
18 Juli 2025
18 Juli 2025
18 Juli 2025
18 Juli 2025
18 Juli 2025
18 Juli 2025
18 Juli 2025
18 Juli 2025
tvättmaskin Manualer
- White Knight
- Amica
- Kenny
- Daewoo
- Hyundai
- Haden
- Miele Professional
- Icecool
- Castor
- Linetech
- Adora
- Tisira
- Kluge
- Corberó
- Constructa
Nyaste tvättmaskin Manualer
31 Juli 2025
31 Juli 2025
31 Juli 2025
30 Juli 2025
30 Juli 2025
30 Juli 2025
30 Juli 2025
30 Juli 2025
29 Juli 2025
29 Juli 2025
