12 3456

speed)

Select the spin speed (* depending on the model) or

- - - - (Rinse stop = no final spin, laundry soaks in the last

rinsing water, display panel - - - -)

ished in)

Programme end after

Status indicators Programme status indicators:

Programme selector for switching

the machine on and off and for

selecting the programme. Can be

turned in either direction.

Programme selector Display panel

Function/option buttons

Start/ Pause

Individual settings

Signal

1. Activate the setting mode for the signal volume

2. button signals (depending on model)a) Set the volume for

2. information signals b) Set the volume for

Information on the display panel depending on model

supply hose kinked/trapped;

Drainage hose/waste pipe blocked; service, clean the drainage hose at the siphon

Other

displays

Switch off the appliance, wait for 5 seconds and switch it back on again. If the display

appears again, call the after-sales service.

To activate the

setting mode

press and

hold

turn one

position to

the right

press and hold for a

further 5 secs until the

display elements light up;

setting mode is activated

centrifug.

mode for the signal

volume

press repeatedly until

the desired volume is

reached

centrifug.

turn one

position to

the right

press repeatedly until the

desired volume is

reached

setting mode for the

signal volume

centrifug.

Sorting and loading laundry

Follow the manufacturer's care information.

According to the information on the care labels.

According to type, colour, soiling and temperature.

Load items of laundry of varying sizes.

Close the washing machine door. Take care not to trap items of laundry

between the washing machine door and the rubber seal.

Adding detergent and care products

Measure accordingly:

Amount of laundry, level of soiling, water hardness (ask your water

supply company) and manufacturer's instructions.

Models without insert for liquid detergent:

Pour liquid detergent into the appropriate dispenser and place in

the drum.

During operation: Open the detergent drawer with care.

Insert for liquid detergent (depending on model), page 10.

Your washing machine Intended use

Contents Page

Environmental protection/Conservation tips

– Always fill the washing machine with a maximum amount of

laundry for the particular programme.

– Wash normally soiled laundry without a prewash.

– The selectable temperatures apply to the care labels on the

textiles. The temperatures in the machine may deviate from

this so that you get the optimum mix of energy-saving and

washing results.

– Measure the detergent according to the manufacturer's

instructions and water hardness.

– If the laundry is subsequently dried in a tumble drier, select the

spin speed according to the tumble drier manufacturer's

instructions.

Preparation

Before washing for the first time

Setting** and adjusting programmes

Washing

Compartment I: detergent for prewash

in detergent solution,

available detergents and care products which are suitable

for use in washing machines

age of 8 years old and by persons with reduced physical,

sensory or mental capacity or by persons with a lack of

experience or knowledge if they are supervised or have

been instructed by a responsible person.

– Do not leave children unattended near the washing

machine

– Children must not be allowed to play with the

appliance.

– Children may not carry out any cleaning or

maintenance work unless under supervision.

– Keep pets away from the washing machine.

Dilute thick fabric softener and conditioner with water.

This prevents blockages.

Detergent drawer

Control panel

Service flap

Washing machine door

Correct installation according to the

separate installation instructions.

Checking the machine

– Never use a damaged machine.

– Inform the after-sales service.

Connecting the mains

plug

– Make sure your hands are dry.

– Take hold of the plug only.

Turning the tap on

Washing

End of programme when...

Interrupting the programme

Programmes at high temperatures:

Programmes at lower temperatures:

speed) to - - - -).

Changing the programme, if...

... a wrong programme has been selected by mistake:

– Reselect the programme.

the beginning.

Pausing/continuing the

programme...

washing machine door cannot be opened. To continue

Individual settings

Function buttons

The spin speed and temperature can be changed before and during the selected

programme. The effects depend on the programme progress.

temp.

You can change the displayed washing temperature. The maximum washing temperature

that can be selected depends on the programme that has been set.

remains in the water after the last rinse, display panel - - - -). The maximum selectable spin

speed depends on the model and on which programme is currently selected.

diferida (Finished in)

When you select the programme, the relevant programme duration is displayed. You can

delay the start of the programme before it begins. The "Finished in" time can be set in

increments of one hour up to a maximum of 24 hours. Press the diferida (Finished in) button

For washing in a shorter time with a washing result comparable to that

of the standard programme. Maximum load

For saving energy with a comparable washing effect to the standard

programme.

Special spin sequence with subsequent fluffing. Gentle final spin –

residual moisture in the washing increased slightly.

Childproof lock

on the display panel

You can lock the washing machine to prevent the functions you have

set from being changed inadvertently.

ON/OFF: after the start/end of the programme, press and hold the

Note: The childproof lock can remain activated until you wish to start

the next programme, even after switching off the machine.

Then you can deactivate the childproof lock before starting the

programme and activate it again as necessary once the programme

has started.

To start, pause and continue the programme and to activate/deactivate the childproof lock.

Switching off

Turn the programme selector to .Off

Turning the tap off

Not required for Aqua-Stop models

Removing the laundry

Open the washing machine door and remove the laundry.

If - - - - (Rinse stop = no final spin) is active: Turn the

– Remove any foreign objects - risk of rusting.

– Leave the washing machine door and detergent

drawer open so that any residual water can

evaporate.

Congratulations – You have opted for a modern, high-quality

domestic appliance manufactured by Balay. The washing machine is

distinguished by its economical consumption of water and energy.

Each appliance which leaves our factory is inspected thoroughly

to ensure that it functions properly and is in perfect condition.

For further information and a selection of our products go to our web

site: www.balay.es

You can find the contact details for your nearest after-sales service

here or in the after-sales service directory (depending on model), see

also Installation Instructions, .page 7

Environmentally friendly waste disposal

All packaging must be disposed of in accordance with environmental

guidelines.

This appliance is certified in accordance with European Directive

2012/19/EU on waste electrical and electronic equipment (WEEE).

This directive provides the framework for the EU-wide collection and

reuse of used appliances.

Compartment II: detergent for main wash,

water softener, bleach, stain remover

Programmes

Temperature and spin speed can be selected individually, depending on the

selected programme and programme progress.

cottons (algod.) Hard-wearing fabrics

+prewash (algod. +

prelavar)

Hard-wearing fabrics, prewash at 30 °C

easy-care (sintéticos) Easy-care fabrics

+prewash (algod. +

prelavar)

Easy-care fabrics, prewash at 30 °C

mix (rápido/mix) Different types of laundry

delicates (delicados) Delicate washable fabrics

super quick 15 min/

30 min (super rápido 15

min/30 min)

Short programmes

hygienic (antialergias) Hard-wearing fabrics

sport (microfibras) Fabrics made from microfibre

shirts (camisas) Non-iron shirts

dark wash (r. oscura / r.

escura)

Dark-coloured fabrics

Select Start/Pause

If the function buttons are held for

longer, the appliance automatically

runs through the display options.

display panel, the childproof lock

Individual settings, .page 5

Washing machine

door handle

9403 / 9000969626 3TS864B

Balay Electrogeräte GmbH

81739 Munich/Alemania

Programmes °C max. Type of laundry Options; information

cottons (algod.)

6 kg/

3,5 kg*

Hard-wearing fabrics, heat-resistant fabrics made

of cotton or linen

+ prewash (algod + prelavar)

skin, longer wash cycle at selected temperature, higher water

level, additional rinse cycle

easy-care (sintéticos) Easy-care fabrics made of cotton, linen, synthetic

fibers or blended fabrics

+ prewash (algod + prelavar)

be washed together

dark wash (r. oscura /

r. escura)

Dark-coloured fabrics made of cotton and dark

easy-care fabrics cycle

2 kg

Non-iron shirts made of cotton, linen, synthetic

fibres or blended fabrics

For delicate, washable fabrics, e.g. made of silk,

satin, synthetic fibres or blended fabrics

(e.g. curtains)

Hand or machine-washable fabrics made of wool

or containing wool

Particularly gentle wash programme to prevent shrinkage of

laundry. Longer programme breaks (fabrics rest in the deter-

gent solution)

super rápido 15 min/30 min

(ecoSpeed 30 min/15min)

2 kg/

3,5 kg

Easy-care fabrics made of cotton, linen, synthetic

fibres or blended fabrics

Short programme,

suitable for lightly soiled items

Safety instructions

– Read the instruction manual and installation instructions and all other information enclosed

with the washing machine and act accordingly.

– Retain the documents for subsequent use.

Risk of electric shock – Never pull the cable to disconnect the mains plug.

– Only plug in or disconnect the mains plug if your hands are dry.

Danger to life For worn-out appliances:

– Disconnect the mains plug.

– Sever the mains cable and discard along with the plug.

– Destroy the lock on the washing machine door. This will prevent

children from locking themselves in and risking their lives.

Danger of suffocation – Keep packaging, film and packaging parts out of the reach of

children.

Risk of poisoning – Keep detergents and care products out of the reach of children.

Risk of explosion – Items of laundry pretreated with cleaning agents containing

solvents, e.g. stain remover/cleaning solvent may cause an

explosion after being loaded into the washing machine.

Rinse items of laundry thoroughly by hand beforehand.

Risk of injury – The washing machine door can become very hot.

– Be careful when draining hot detergent solution.

– Do not climb onto the washing machine.

– Do not lean on the open washing machine door.

– Do not reach into the drum if it is still rotating.

Consumption values

Programme Load Electricity Water Programme duration*** *** ***

mix 40 °C 2,5 kg 0,40 kWh 44 l 1 h

*Programme setting for testing in accordance with currently applicable EN60456 standard.

Note on comparative tests: When testing the test programmes, wash the specified load using the

maximum spin speed.

Programme

Additional

function

Load Annual energy consumption Annual water consumption

** Programme settings for testing and energy labelling in accordance with europian standard

2010/30/EU with cold water (15 °C).

***The values may deviate from the specified values depending on water pressure, water hardness,

and inlet temperature, ambient temperature, type, amount and level of laundry soiling, detergent

used, fluctuations in the power supply and selection of options.

Important information

Before washing for the first time

Do not put any laundry in the machine. Turn the tap on. Pour into compartment :II

– approx. 1 litre water

– detergent (dosage according to the manufacturer's instructions for light soiling and the appropriate

degree of water hardness)

programme, turn the programme selector to Off.

Protecting the laundry and the machine

– When measuring the amount of all detergents/additives and cleaning agents, always check the

manufacturer's instructions.

– Empty pockets.

– Look out for metal items (paperclips, etc.).

– Wash delicates in a laundry bag (tights, curtains, underwired bras).

– Fasten zips, do up any buttons.

– Brush sand out of pockets and collars.

– Remove curtain fittings or place in the laundry bag.

Loading laundry

Load items of laundry of varying sizes.

Take care not to trap items of laundry between the washing machine door and the rubber seal.

Laundry with varying degrees of soiling

Wash new items of clothing separately.

Pretreat any stains as necessary.

heavy

Do not load as much laundry. Select the programme with prewash.

Soaking Load laundry of the same colour

Pour soaking agent/detergent into compartment II in accordance with the manufacturer's instructions.

Starching Laundry must not be treated with fabric softener

softener compartment in accordance with the manufacturer's instructions (rinse first if necessary).

Dyeing/bleaching

Dye should only be used in normal household quantities. Salt may damage stainless steel. Always

follow the dye manufacturer's instructions. Do use the washing machine for bleaching clothes.not

Insert for liquid detergent depending on model

Position the insert for dispensing liquid detergent:

– Slide the insert forwards.

Do not use the insert (slide upwards):

– For gel-type detergents and washing powder,

– for programmes with Prewash (Vorwäsche) or the

diferida (Finished in)

function.

Cleaning and care

Machine housing, control panel

– Remove detergent residue immediately.

– Wipe off with a soft, damp cloth.

– Do not clean with a jet of water.

Cleaning and care

Cleaning the detergent drawer ...

... if it contains detergent or fabric softener residues.

1. Pull out, press insert down, remove drawer completely.

2. To remove the insert: press the insert upwards from below with your finger.

3. Clean the detergent dispenser tray and insert with water and a brush and dry it.

4. Attach the insert and engage (connect the cylinder to the guide pin).

5. Push in the detergent drawer.

Leave the detergent drawer open so that any residual water can evaporate.

Drum

Leave the washing machine door open so that the drum can dry out.

Rust stains - use chlorine-free cleaning agent, not steel wool.

Descaling Make sure that there is no laundry in the machine.

This should not be necessary if the correct detergent dosage has been used. If it is necessary, however,

proceed according to the descaling agent manufacturer's instructions. Suitable descalers can be obtained via

Maintenance

Detergent solution pump

Turn the programme selector to and disconnect the mains plug.Off

6. Open the service flap

7. Carefully unscrew the pump cover (residual water).

8. Clean the interior, pump cover thread and pump housing (the impeller in the

detergent solution pump must rotate).

9. Replace the pump cover and screw it on tightly.

10. Replace the service flap.

To prevent unused detergent from flowing straight into the drain during the next wash: Pour 1 litre of

Drainage hose at the siphon is blocked

Turn the programme selector to and disconnect the mains plug.Off

Loosen the hose clamp and carefully remove the drainage hose (caution: residual

water).

2. Clean the drainage hose and siphon connecting piece.

3. Reattach the drainage hose and secure the connection with the hose clamp.

Filter in the water inlet is blocked

Risk of electric shock

Do not immerse the Aqua-Stop safety device in water (it contains an electric valve).

Reduce the water pressure in the supply hose:

Turn off the tap.

4. Turn the programme selector to . Disconnect the mains plug. Off

Clean the filter:

5. Disconnect the hose from the tap.

Clean the filter with a small brush.

and/or on standard and Aqua-Secure models:

Remove the hose from the rear of the appliance,

Take out the filter with a pair of pliers and clean it.

6. Connect the hose and check for leaks.

Risk of scalding

– Allow the detergent solution to cool down.

– Turn off the tap.

– Disconnect the mains plug.Risk of electric shock.

– No solvents.Risk of explosion.

What to do if...

Water is leaking out. – Attach/replace the drainage hose correctly.

– Tighten the screw connection of the supply hose.

No water supply.

Detergent not dispensed.

– Tap not turned on?

– Supply hose kinked or trapped?

Washing machine door

cannot be opened.

Programme does not start.

diferida (Finished in) time selected?

– Washing machine door closed?

Detergent solution is not

drained.

– Clean the waste pipe and/or drainage hose.

Water not visible in the

drum.

– Not a fault - water below the visible area.

Spin result not satisfactory.

Laundry wet/too damp.

– Not a fault - the imbalance monitoring system has interrupted the spin

because the laundry is unevenly distributed.

Distribute large and small items of laundry evenly in the drum.

The programme duration

changes during the wash

cycle.

– Not a fault - the programme cycle is optimised for the particular

washing process. This can cause changes in the programme duration

on the display panel.

Spin cycle performed

several times.

– Not a fault - unbalanced-load detection system is adjusting the

imbalance.

compartment for care

products.

– Not a fault - the action of the care product is not affected.

Odour formation in the

washing machine.

– Run programme without laundry. Use standard cottons 90 °C

detergent.

Appliance has detected a

detergent overload.

– Too much detergent used?

Mix one tablespoonful of fabric softener with ½ litre water and pour

into compartment II (Not for outdoor fabrics, sportswear fabrics or

those made with down.)

– .Reduce the detergent dosage for the next wash cycle

Loud noises, vibrations and

“wandering” during the

spin cycle.

– Are the appliance feet fixed?

– Transportation safety devices removed?

Display panel/indicator

lamps do not function

during operation.

– Power cut?

– Circuit breakers tripped? Switch the circuit breakers back on or

replace.

– If the fault occurs repeatedly, call the after-sales service.

Programme sequence

longer than usual.

– Not a fault - unbalanced-load detection system is adjusting the

imbalance by repeatedly redistributing the laundry.

– Not a fault - foam detection system active - adds an additional rinse

cycle.

There are detergent

residues on the laundry.

– Occasionally, phosphate-free detergents contain water-insoluble

residues.

– Select Rinse

If you cannot correct a fault yourself (switching on/off) or a repair is required:

– Turn the programme selector to and remove the mains plug from the socket.Off

Instrucciones de uso

Lavadora

Observar las advertencias de seguridad

en la página 8.

Poner la lavadora en funcionamiento sólo

después de haber leído las presentes

instrucciones, así como el manual de

instalación separado.

1 2

speed)

Select the spin speed (* dependi

- - - - (Rinse stop = no final spin, l

rinsing water, display panel - - - -)

ished in)

Programme end after

Status indicators Programme status indicators:

Programme selector Display panel

Function/option buttons

Insert for liquid detergent (depending on model), page 10.

Your washing machine Intended use

Contents Page

Environmental protection/Conservation tips

– Always fill the washing machine with a maximum amount of

laundry for the particular programme.

– Wash normally soiled laundry without a prewash.

– The selectable temperatures apply to the care labels on the

textiles. The temperatures in the machine may deviate from

this so that you get the optimum mix of energy-saving and

washing results.

– Measure the detergent according to the manufacturer's

instructions and water hardness.

– If the laundry is subsequently dried in a tumble drier, select the

spin speed according to the tumble drier manufacturer's

instructions.

Preparation

Compartment I: detergent for prewash

in detergent solution,

available detergents and care products which are suitable

for use in washing machines

age of 8 years old and by persons with reduced physical,

sensory or mental capacity or by persons with a lack of

experience or knowledge if they are supervised or have

been instructed by a responsible person.

– Do not leave children unattended near the washing

machine

– Children must not be allowed to play with the

appliance.

– Children may not carry out any cleaning or

maintenance work unless under supervision.

– Keep pets away from the washing machine.

Correct installation according to the

separate installation instructions.

Checking the machine

– Never use a damaged machine.

– Inform the after-sales service.

Connecting the mains

plug

– Make sure your hands are dry.

– Take hold of the plug only.

Turning the tap on

Congratulations – You have opted for a modern, high-quality

domestic appliance manufactured by Balay. The washing machine is

distinguished by its economical consumption of water and energy.

Each appliance which leaves our factory is inspected thoroughly

to ensure that it functions properly and is in perfect condition.

For further information and a selection of our products go to our web

site: www.balay.es

You can find the contact details for your nearest after-sales service

here or in the after-sales service directory (depending on model), see

also Installation Instructions, .page 7

Environmentally friendly waste disposal

All packaging must be disposed of in accordance with environmental

guidelines.

This appliance is certified in accordance with European Directive

2012/19/EU on waste electrical and electronic equipment (WEEE).

This directive provides the framework for the EU-wide collection and

reuse of used appliances.

Compartment II: detergent for main wash,

water softener, bleach, stain remover

Programmes

Temperature and spin speed can be selected individually, depending on the

selected programme and programme progress.

cottons (algod.) Hard-wearing fabrics

+prewash (algod. +

prelavar)

Hard-wearing fabrics, prewash at 30 °C

easy-care (sintéticos) Easy-care fabrics

+prewash (algod. +

prelavar)

Easy-care fabrics, prewash at 30 °C

mix (rápido/mix) Different types of laundry

delicates (delicados) Delicate washable fabrics

super quick 15 min/

30 min (super rápido 15

min/30 min)

Short programmes

hygienic (antialergias) Hard-wearing fabrics

sport (microfibras) Fabrics made from microfibre

shirts (camisas) Non-iron shirts

dark wash (r. oscura / r.

escura)

Dark-coloured fabrics

Produktspecifikationer

Varumärke:	Balay
Kategori:	tvättmaskin
Modell:	3TS864B
Inbyggd display:	Ja
Timer:	Ja
Bredd:	600 mm
Djup:	560 mm
Höjd:	850 mm
Sladdlängd:	1.6 m
Energieffektivitetsklass (gammal):	A+++
Ljudnivå (tvätt):	57 dB
Maximal centrifugeringshastighet:	1000 RPM
Cykeltid (max):	270 min
Tvättprogram:	Hygiene/anti-allergy, Black, Blouse/shirt, Cotton, Mix, Quick, Sport, Synthetics, Delicate/silk
Nominell kapacitet:	6 kg
Produktens färg:	Vit
Kontrolltyp:	Buttons, Rotary
Årlig vattenförbrukning tvätt:	10560 l
Djup med öppen dörr:	960 mm
AC-inspänning:	220 - 240 V
Apparatens placering:	Fristående
Växelström Frekvens:	50 hz
Gångjärnssida:	Vänster
Ström:	10 A
Laddning:	Frontmatad
Drum volym:	42 l
Fördröjd start timer:	Ja
Centrifugering klass:	C
Ljudnivå (spinn):	73 dB
Fördröjd start:	24 h
Vattenförbrukning per omgång:	- l
Energiförbrukning vid tvätt:	0.76 kWh
Återstående tidindikering:	Ja
Ansluten effekt:	2300 W
Årlig energiförbrukning tvätt:	153 kWh
Strömförbrukning i avslaget läge:	0.15 W
Längd på anslutningsslang:	1.2 m
Utloppets slanglängd:	1.25 m
