How to install the FAST-9999 with the FAST-BTAH
The FAST-9999 universal harness uses the patented Posi-Tap connector from Posi-Products for making
FAST secure connections to your OEM wire harness.
Posi-Tap Patent # 5,228,875 5,695369 5,868,589 6,692,313 Jap 2881414, Aus 708700, Tia 103534, Can 2204826TM
Mex 200626 Korea 477279, China Z197105562.9 & others pending
Disconnect negative battery clamp from battery.
For easiest installation remove the radio and disconnect
the harness from the back of the radio.
Connect the Posi-Tap connectors to the corresponding
wires of your radio harness. Consult your car or radio
manufacturer’s manual to get the correct color codes
for your vehicle.
Red (+) 12V Power. Turns on when ignition/accessory is on.
Blue/White Turns on remote accessories (amplifiers, etc.).
If there is no Remote Amplifier wire, you can often use the
power antenna wire.
White (+) Left Front Speaker
White/Black (-) Left Front Speaker
Gray (+) Right Front Speaker
Gray/Black (-) Right Front Speaker
Remove the top cap. Place the wire
that is going to be tapped. In the
grove of the cap as far down as it
will go.
Make sure not to cross thread the
cap when screwing it back in place.
Make sure the end with the 6 pin Molex connectors is
toward the radio. Run the BTAH harness behind radio,
dash and along the edge of the vehicle until you get
to the place you have decided to mount the tube.
Continue to thread until the cap
is tight and the wire is pierced.
Make sure to attach all 6 of the
FAST-9999 harness wires to
your OEM harness.
Plug the FAST-9999 harness into
the FAST-BTAH. Mount grounding
ring and plug the 14 pin connector
into the BASS TUBE. For more information
on placement and mounting, consult
your amplified tube instruction manual.
FAST-9999
14 pin connector
to the BAZOOKA
Ground to
chassis of
vehicle
FAST-BTAH
