3LIOC8LB

Use and maintenance instructions EN

Instrucciones de uso y mantenimiento

Istruzioni d'uso e manutenzione

CHIMNEY

C O O K E R

HOOD

Instructions pour l'utilisation et manutention FR

3LIOC8LB

Fig.5

Ⓨ

Ⓩ

Ⓔ

Ⓕ

Ⓜ

Fig.4

ⓁⒼ

Fig.7

Fig.6

43LIOC8LB

1. GENERAL

Carefully read the following important information

regarding installation safety and maintenance.

Keep this information booklet accessible for further

consultations.

CONTROL PANEL (Fig.2)

TYPE “A”

1 -First speed

2 -Second speed

3 -Third speed

4 -Fourth speed (maximum)

- Light ON/OFF

2. INSTALLATION INSTRUCTIONS

This hood has been arranged to be installed above a

cook top. It can be used in 2 ways:

• EXHAUST MODE: the kitchen vapours are puried by

the metal anti-grease lters and carried outside through

a ducting system. (Fig. 3A; 3B)

• RECIRCULATING MODE: the kitchen vapours are

puried by the metal anti-grease lters and an activated

carbon lter (sold separately), then conveyed back into

the kitchen. (Fig. 3C)

We suggest to have installation carried out by

qualified personnel, in compliance with all the

current regulations and in particular with the ones

concerning air exhaust and electrical connection.

The manufacturer cannot be held liable for damages

caused by improper installation or if it has not been

carried out according to the state-of-the-art.

2.1 ELECTRIC CONNECTION

The appliance has been manufactured as a class II,

therefore no earth cable is necessary.

The connection to the mains is carried out as follows:

BROWN = lineL

BLUE = neutralN

If not provided, connect a plug for the electrical load

indicated on the description label. Where a plug is

provided, the cooker hood must be installed in order

that the plug is easily accessible.

An omnipolar switch with a minimum aperture of

3 mm between contacts, in line with the electrical

load and local standards, must be placed between

the appliance and the network in the case of direct

connection to the electrical network.

2.2. INSTALLATION

The appliance must be installed at a minimum height of

650 mm from an electric cooker stove, or 750 mm from

gas or combined cooker stoves. (Fig.1)

If a connection tube composed of two parts is used, the

upper part must be placed outside the lower part.

Do not connect the cooker hood exhaust to the same

conductor used to circulate hot air or for evacuating

fumes from other appliances generated by other than

an electrical source.

2.3. MOUNTING THE COOKER HOOD TO THE WALL

Drill holes according to indications quoted in ABC- -

(g.1).

Use screws and screw anchors suitable for wall (e.g.

reinforced cement, plasterboard) for the mounting of

the cooker hood. Where screws and screw anchors

are supplied ensure that they are suitable for the type

of wall where the cooker hood is to be mounted.

Afx the bracket Z C to the wall via the drill holes

Hang the cooker hood on the wall using the drill holes

Fasten the cooker hood using the fastening drill holes

2.4. EXHAUST VERSION

Connect the ange Y to the discharge opening with

a connecting tube Fig.5 (do not carry out for lter

version) .

Thread the upper connector to the inside of the E

lower connector ; hang the two connectors inserting F

them vertically on the cooker hood, unthread the

upper connector E towards the top, locking it in with

the appropriate screws in the drill holes of the G

bracket Z (g. 7) previously afxed to the wall via the

drill holes C (g. 1).

2.5 RE-CIRCULATING VERSION

In order to transform your cooker hood from the

exhaust version to the re-circulating version, ask your

local retailer for active carbon lters and then carry

out the following instructions.

The lters must be applied to the suction kit located

inside the cooker hood (g. 6). The air is replaced

in the environment via the eyelets impressed on the

connector .E

2.6. OPERATING CHECKS

Check lights and motor start-up on all speeds.

USE AND MAINTENANCE

It is recommended to switch on the appliance before

cooking. It is also recommended to leave the appliance

in operation for 10 minutes after cooking is terminated

in order to completely eliminate cooking vapours and

odours.

The proper function of the cooker hood is

conditioned by the regularity of the maintenance

operations, in particular, the active carbon lter.

Clean the fan and other surfaces of the cooker hood

regularly using a cloth moistened with denatured

alcohol or non abrasive liquid detergent.

EN Use and maintenance instructions
