INSTALLATION, MAINTENANCE AND USE

INSTRUCTIONS FOR

FREE-STANDING COOKERS

61x64 cm (type M6V)

READ THE INSTRUCTION BOOKLET BEFORE INSTALLING AND USING

THE APPLIANCE.

The manufacturer will not be responsible for any damage to property or to persons

caused by incorrect installation or improper use of the appliance.

The manufacturer is not responsible for any inaccuracies, due to printing or transcription

errors, contained in this booklet. In addition, the appearance of the figures reported is also

purely indicative.

The manufacturer reserves the right to make changes to its products when considered

necessary and useful, without affecting the essential safety and operating characteristics.

CONTENTS:

INSTALLER TECHNICAL MANUAL ...............................................................................................................pg. 2

Installing the cooker - Installation information .................................................................................................pg. 2

Ventilation and aeration of rooms....................................................................................................................pg. 3

Height adjustable legs ....................................................................................................................................pg. 3

Backguard installation instruct ........................................................................................................................pg. 3

Gas connection ...............................................................................................................................................pg. 3

Adaptation to different types of Gas and burner adjustments..........................................................................pg. 3-4

Electric connection..........................................................................................................................................pg. 4

APPLIANCE MAINTENANCE - Replacing parts.............................................................................................pg. 5

USE AND MAINTENANCE MANUAL .............................................................................................................pg. 5

Description of control panel and control types.................................................................................................pg. 5

Using burners..................................................................................................................................................pg. 6

Using the electric thermostat...........................................................................................................................pg. 6

Using the 9+0 switch.......................................................................................................................................pg. 6-7

Using the natural conventional electric oven ..................................................................................................pg. 7

Using the ventilated electric oven....................................................................................................................pg. 8

Using the electric grill ......................................................................................................................................pg. 8

Using the ventilated electric grill .....................................................................................................................pg. 9

Using the self cleaning oven ..........................................................................................................................pg. 9

Cleaning the appliance....................................................................................................................................pg. 9

After-sales technical service and spare parts..................................................................................................pg. 9

THIS APPLIANCE HAS BEEN DESIGNED FOR NON-PROFESSIONAL DOMESTIC USE.

INSTALLER TECHNICAL MANUAL

This appliance is marked according to the European directive 2002/95/EC

This appliance is marked according to the European directive 2002/96/EC on Waste

Electrical and Electronic Equipment (WEEE).

This guideline is the frame of a European-wide validity of return and recycling on

Waste Electrical and Electronic Equipment.

INSTALLER INFORMATION

The installation, all adjustments, transformations and maintenance listed in this part of the manual must be

carried out only by skilled personnel.

Improper installation may cause damage to persons, animals or property, for which the manufacture will not be

held responsible.

The appliance safety or automatic adjustment devices may be changed during the service life of the system only

by the manufacturer or by the duly authorised supplier.

INSTALLING THE COOKER

After having removed the various loose parts from the internal and external packing, make sure that the cooker is not

damaged. In case of doubt, do not use the appliance and contact skilled personnel.

Keep all the dangerous packing parts (polystyrene foam, bags, cardboard, staples, etc.) away from children.

The appliance can be installed as a freestanding unit, next to a wall or inserted between two walls (Fig.1). A single

sidewall that exceeds the height of the work surface is possible. This must be at a minimum distance of 70 mm from the

edge of the cooker (Fig. 1)

Any walls of the adjacent furniture pieces and the wall behind the cooker must be made with heat-resistant material that

can withstand a minimum overtemperature of 65 K.

WARNING: the connection to the gas network must only use metal flexible pipes that conform with the national

standards in force.

IMPORTANT INFORMATION FOR INSTALLING THE APPLIANCE

The cooker can be installed separately, as a freestanding unit, or between kitchen units or between a kitchen

unit and the wall. The device must be installed in accordance with the regulations stated in UNI 7129 and UNI

7131 standards.

This appliance is not connected to devices which exhaust combustion products.

Special attention must be focused on the prescriptions described below regarding room aeration and

ventilation. Any hanging cabinets installed above the work surface must be located at a distance of no less than

700 mm.

Produktspecifikationer

Varumärke:	Bertazzoni
Kategori:	Spis
Modell:	X60 4 MFE GI
Produkttyp:	Fristående köksspis
Inbyggd display:	Nej
Bredd:	595 mm
Djup:	600 mm
Höjd:	885 mm
Grill:	Ja
Konvektionsmatlagning:	Ja
Elektronisk tändning:	Ja
Ugnens strömkälla:	Elektrisk
Antal ugnar:	1
Antal automatiska program:	9
Antal gasbrännare:	4
Produktens färg:	Gul
Kontrolltyp:	Rotations-
Ugnens bruttokapacitet:	59 l
Ugnens nettokapacitet:	59 l
AC-inspänning:	220 - 240 V
Växelström Frekvens:	50 - 60 hz
Ström:	12.6 A
Typ av spishäll:	Gas
Antal brännare / zoner matlagning:	4
Manöverplats:	Framsida
Effekt på platta/tillagningsyta 1:	480 W
Effekt på platta/tillagningsyta 2:	1000 W
Effekt på platta/tillagningsyta 3:	1750 W
Effekt på platta/tillagningsyta 4:	3000 W
Totalt ugn (er) invändig kapacitet:	59 l
Totalt ugn:	2900 W
Ugnström:	2900 W
Anslutningseffekt (elektrisk):	2900 W
Antal glaspaneler dörr:	3
