Sida 1/16
26
28 29 30
27
a
d
c
b
h
k
i
j
f
e
g
l
12
10 11
30
24 25
5 6
7
8
9
4
2
3
1
19 20 21
17 18
13
15
14 16
22
23
110
116
122
128
134
140
146
152
158
164
170
176
182
193
199
205
8
14
20
26
32
38
44
50
56
62
68
74
80
86
92
98
104
USER MANUAL
Weight 15-36 kg
Group 2-3
Age 4-12 y
ECE R44-04
8 9
! Vital information
• For the correct usage of the airbag in combination with the seat; read
the vehicle handbook.
• For the suitable positions in the car, read the vehicle handbook.
• BeSafe recommends to install the seat in all vehicle seat positions
which are intended to be used and check installation, available
space in the vehcile and position of the child, to verify if the seat is
acceptable for your situation.
• iZi Flex S FIX can be installed forward-facing with the ISOFIX
anchorage in a vehicle equipped with ISOFIX anchorage points, in
combination with a 3-point belt, approved to UN/ECE Regulation
No.16 or other. When there is no ISOFIX anchorage available in the
vehicle position, iZi Flex S FIX can be installed forward-facing with a
3-point belt, approved to UN/ECE Regulation No.16 or other.
• iZi Flex S FIX is approved in group 2-3, forward-facing from 15-36 kg.
• When used for stature heights between 135 cm. and 150 cm iZi Flex
S FIX might not fit in all vehicles, due to a low position of the vehicle
roof at the side.
• Before every use, make sure that the 3-point belt is not damaged or
twisted and installed tight.
• When used without the isofix anchorages connected, the seat should
always be restrained by the vehicle belt when it is transported
without the child.
• When the child weighs over 36 kg or the shoulders exceed the
highest position of the shoulderbelt guiders, the child must change to
a seat suitable for children with a weight above 36 kg, normally the
vehicle seat.
• After an accident, the seat must be replaced. Although it may look
undamaged, if you were to have another accident, the seat may not
be able to protect your child to the level to which it was designed.
• Prevent the seat from becoming trapped or weighed down by
luggage, seats and/or slamming doors.
• DO NOT attempt to dismantle a part, which is not intented to be
removed, modify or add any part to the seat. Warranty will be void if
non-original parts or accessories are used.
• Never leave your child unattended in the seat.
• Make sure all passengers are informed about how to release your
child in case of emergency.
• Make sure luggage or other objects are properly secured. Unsecured
luggage may cause severe injuries to children and adults in case
of accidents.
• Never use the seat without the cover. The cover is a safety feature
and may only be replaced by an original BeSafe cover.
• Do not use any aggressive cleaning products; these may harm the
construction material of the seat.
• BeSafe advises that child seats should not be bought or sold
second-hand.
• KEEP this user manual with the seat for future use.
• DO NOT use the seat for longer than 8 years. Due to ageing, the
quality of the material may change.
• DO NOT use at home. It has not been designed for home use and can
only be used in a vehicle.
• When the child seat is installed in the car check all the areas where
the child seat might touch the interior. We recommend using a
(BeSafe) protection cover in these places to avoid cuts, marks or
discolouration to the interior of the vehicle, especially in vehicles with
leather or wooden interiors.
• If in doubt, consult either the car seat manufacturer or the retailer.
! It is important that you read this user manual BEFORE
installing your seat. Incorrect installation could endanger
your child.
Thank you for choosing BeSafe iZi Flex S FIX
26
28 29 30
27
a
d
c
b
h
k
i
j
f
e
g
l
12
10 11
30
24 25
5 6
7
8
9
4
2
3
1
19 20 21
17 18
13
15
14 16
22
23
10 11
• Adjustable headrest
• Shoulderbelt lock
• Shoulderbelt guider
• Backrest
• Base
• ISOfix release handle
• SIP bumper
• Height adjustment handles (2x)
• ISOfix connectors (2x)
• ISOfix release buttons (2x)
• ISOfix indicators (2x)
• ISOfix vehicle anchorage (2x)
(1a)
(1b)
(1c)
(1d)
(1e)
(1f)
(1g)
(1h)
(1i)
(1j)
(1k)
(1l)
Preparing to install
Installation
1. When installing the seat in the front vehicle seat make sure the
backrest of the vehicle seat is in an upright position.
2. Position the seat inside the vehicle.
3. Pull the ISOfix release handle to release the ISOfix connectors. A
button on top of the handle will keep the handle in the released
position and locks the ISOfix connectors from sliding back into the
base again. The ISOfix arms lock only in the position where they are
extended completely. In this locked position 2 red marks next to the
button on the handle will become visible. (2, 3)
4. Click the ISOfix connectors onto the ISOfix anchorage points in the
vehicle seat. Make sure that all ISOfix indicators are GREEN. (4, 5, 6)
5. Press the button down on top of the ISOfix release handle (located
between the red marks) and push the handle back into the base.
Push the seat back as far as possible towards the backrest of the
vehicle seat. (7, 8, 9)
6. Make sure the back of the seat is touching the backrest of the vehicle
seat. If the headrest of the vehicle is pushing the seat away from the
backrest, adjust the headrest. (9)
7. If the seat cannot be used in combination with ISOfix anchorage
points in the vehicle seat, the ISOfix connectors can be stowed inside
the seat and the seat can be used in combination with the 3-point
belt only.
8. Slide the shoulderbelt into the shoulderbelt guide. Make sure the belt
is not twisted and that the shoulderbelt guide is closed again to keep
the belt inside. (10, 11)
1. Adjust the headrest to the correct height by turning the height adjuster
handle. Make sure that the shoulder belt is level with your child’s
shoulder. (12, 13)
2. Position the vehicle belt in front of the child and lock the belt into the
buckle of the vehicle. (14, 15)
3. Remove slack in the belt by pulling the belt towards the retractor. (16)
Positioning of the child
1. Remove the shoulderbelt out of the shoulderbelt guide by pushing the
shoulderbelt lock in the guider up and slide the belt out. (17, 18)
2. Pull the ISOfix release handle to release the ISOfix connectors. In this
way the base of the seat can move forwards and the ISOfix release
buttons can be operated. (19, 20)
3. Release both ISOfix connectors, by pushing down the release buttons.
(21) Slide the arms with ISOfix connectors inside the seat before you
remove the seat from the vehicle. To be able to slide the arms with
ISOfix connectors inside the seat, press the button down (between the
red marks) on top of the ISOfix release handle. (22, 23)
4. Remove the seat from the vehicle.
Removing the seat
Installation of 3 car seats
1. The SIP bumper on the inner side of the vehicle can be removed from
the seat to create more space next to the seat for an additional car
seat in the middle position of the vehicle. Remove a side bumper only
on the inner side of the vehicle and never on the door side. (24, 25)
2. To remove a SIP bumper, push the button and move the bumper
sideways and to the back, to hook it out of the fabric hooks. Keep the
SIP bumper for later usage. (26, 27)
3. To install a SIP bumper, first hook in the lower hook, then hook in the
upper hook and finally secure the bumper in the middle by pushing
the button first and releasing it when it is positioned against the seat.
Check if the SIP bumper is connected correctly. Use the SIP bumper
only on the door side of the vehicle. (28, 29, 30)
