User manual
BETSO SBOX-2RF
Highly accurate Time Code & Wordclock generator with RF transmission
1
© Copyright BETSO ELECTRONICS s.r.o.
User manual
BETSO SBOX-2RF
Contents
1. Product description................................................................................................4
2. Top features.......................................................................................................... 4
3. Control elements....................................................................................................5
4. Insertion of battery / accumulator...........................................................................6
5. External power supply.............................................................................................6
6. Turning ON/OFF..................................................................................................7
7. Menu control.........................................................................................................7
8. Setting of SBOX-2RF............................................................................................8
8.1 Time code....................................................................................................... 8
8.1.1 Frame rate - setting frame rate of generated Time Code..................................8
8.1.2 Amplitude - setting amplitude of generated Time Code...................................8
8.1.3 Default - setting of default Time Code start time/frame...................................9
8.1.4 Offset - setting of Time Code offset for jamming or RF transmission.................9
8.1.5 User bits - setting of User Bits of generated Time Code...................................9
8.1.6 Auto on - setting of automatic power on when TC source is connected............10
8.1.7 Jamming - setting of jamming to external TC source......................................10
8.1.8 Cross jamming - jamming SBOX-2RF with different TC frame rate.................11
8.1.9 Jamming calibration - calibration to TC source during jamming......................11
8.2 Word clock.....................................................................................................12
8.2.1 Sample rate - setting of WordClock frequency................................................12
8.2.2 Pull up/down - setting of word clock multiplication coefficient.........................12
8.3 Wireless.........................................................................................................13
8.3.1 Unit type - setting of wireless behaviour of SBOX-2RF...................................13
8.3.2 Channel - setting of RF time code system channel..........................................13
8.3.3 Location - setting of usage location for regulatory compliance.........................14
8.4 BNC function - setting of BNC connector behaviour..........................................14
8.5 Special...........................................................................................................15
8.5.1 Copy TX TC-IN to RX TC-OUT..................................................................15
8.5.2 Time and date.............................................................................................15
8.5.2.1 Time - setting of actual time.....................................................................16
8.5.2.2 Date - setting of actual date......................................................................16
8.5.3 Battery type – setting type of battery powering SBOX-2RF............................16
8.5.4 OLED brightness – setting of OLED display brightness...................................17
8.5.5 OLED power save mode – setting of OLED power save function.....................17
8.5.6 Display orientation – setting of OLED display orientation................................17
8.5.7 GPS time TC – generation time code with UTC time of GPS signal................18
8.5.8 GPS calibration – calibration of internal TCXO using GPS module...................18
8.6 System..........................................................................................................18
8.6.1 Serial number - serial number of SBOX-2RF..................................................19
8.6.2 HW version - version of hardware of SBOX-2RF.............................................19
8.6.3 SW version - version of software of SBOX-2RF..............................................19
8.6.4 Measured TC offset - actual measured offset between TC IN & OUT..............19
8.6.5 Contains FCC ID: 2AJWB-RFM1 - inbuilt transmitter module.........................20
© Copyright BETSO ELECTRONICS s.r.o.
2
