Sida 1/3
58D1U BLA58ULD02BCCI-55
Figure(This is for your reference only)
KTC Model Name: Base Model: Customer Model Name:
Platform Model:
LCD TV Product Specification
Brand: BLAUPUNKTM-2874T8-ISDB
1.Panel spec (The panel parameters will be somewhat different between different OC, please refer to
the corresponding panel specification.)
Size
58" diagonal
Backlight
DLED direct Type
Maximum resolution
3840×2160
Contrast ratio (Typ)
5000:1
Response time(Typ)
9.5ms
Display scale
16:09
Viewing angle(CR>10)
Typ(H:178°,V:178°)
Display Colors
1.07 B
Color Gamut(NTSC)
≥NTSC 62%
LCM Center Luminance of White
Min:250cd/m2;Typ:300cd/m2
Local dimming
Nonsupport
Uniformity of Luminance
≥65%
2.Hardware Information
ATV
PAL M/N；NTSC
DTV
ISDB-T
CPU Frame
ARM Cortex-CA55*4
GPU
Mail G31 MP2 -High speed
RAM(DDR)
1.5GB
ROM(Flash)
8GB
Audio power(Output)
8W+8W
WIFI(Type)
2T2R
HDMI 1.4 (HDCP 1.4)
-
Tuner type
3
USB 2.0
2
USB 3.0
-
VGA
-
AV In
1
YPbPr In
-(CVBS in instead)
CI
-
Page 1 of 3
PC Audio
-
RJ-45
1
Earphone
1
Audio In
-
Audio Out
-
Video Out
-
SPDIF Out
1(optical)
Bluetooth(Version)
YES(V5.0/4.2/4.1/4.0/3.0/2.1)
HDMI 2.0 (HDCP 2.2)
Screw-thread
3.Software Function
Channel list
YES
Channel edit
YES
Picture freezing
NO
MTS/NICAM
MTS
Sleep time setting
YES
Teletext
NO
PVR
YES
EPG
YES
V_CHIP/Parental Guidance
Parental Guidance
CC(Closed caption)
YES
AD(Audio description)
YES
TTS(Text to Speech)
NO
CI+
NO
DOLBY
YES
HDMI-ARC
HDMI-2
HDMI-CEC
YES
HDMI-MHL
NO
Operation system
webOS 5.0
OTA
YES
Hotel mode
NO
4.Structure Information
Base model name
BCCI-55 I shaped Fixed metal base
Size (without stand) L×W×H
1300x74x760mm
Size (with stand) L×W×H
1300x243x790mm
Size (carton) L×W×H
1411x142x871mm
Net Weight (without stand)
14kg
Net Weight (with stand)
14.1kg
Gross Weight (without stand)
17.7kg
Gross Weight (with stand)
17.8kg
Size (Wall hanging)
300x200mm
Page 2 of 3
5.Power Management&Safety&Certificate
Power input
100-240VAc
Fire rating
UL94-HB75
Standby power
≤0.5W
Rated power
155W
Working condition
Temperature：5℃～40℃ humidity：20%～80% atmosphere：86KPa～106KPa
Storage condition
Temperature：-20℃～55℃ humidity：20%～80% atmosphere：86kPa～106kPa
6.Accessory
Stand(Optional)
1PCS
Remote control
1PCS
Instruction
1PCS
Warranty card(Optional)
1PCS
Battery(Optional)
2PCS
Remark 1: The panel parameters will be somewhat different between different panel, please refer to the corresponding panel.
Remark 2: This SPEC is confirmed by KTC and Customer, it will be effective from the dated signed. KTC will control the mass
production according to this SPEC and in case all disputes arising from the execution of this agreemen , this SPEC should be prevail.
Signed by PM: Signed by sales Manager:
Signed by customer: Date:
Page 3 of 3
