1. GETTING STARTED

What’s In The Box?

• 1 x Aria™ Prole RGBW

• 1 x Gel Frame Holder

• 1 x Gobo Holder

• 1 x Ever-So-Handy Power Cord

• This Lovely User Manual

Getting It Out Of The Box

Congratulations on your purchase of the fresh and y Aria™ Prole RGBW! Now that

you’ve got your Aria™ Prole (or hopefully, ), you should carefully unpack the Proles!

box and check the contents to ensure that all parts are present and in good condition.

If anything looks as if it has been damaged in transit, notify the shipper immediately

and keep the packing material for inspection. Again, please save the carton and all

packing materials. If a xture must be returned to the factory, it’s important that it be

returned in the original factory box and packing.

Powering Up!

All xtures must be powered directly o a switched circuit and cannot be run o a

rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer

channel is used solely for a 0% to 100% switch.

AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that

the xture you receive is suitable for your local power supply. See the label on the

xture or refer to the xture’s specications chart for more information. A xture’s

listed current rating is its average current draw under normal conditions. Check the

xture or device carefully to make sure that if a voltage selection switch exists that it is

set to the correct line voltage you will use.

Warning! Verify that the voltage select switch on your unit matches the line

voltage applied. Damage to your xture may result if the line voltage applied

does not match the voltage indicated on the voltage selector switch. All

xtures must be connected to circuits with a suitable Ground (Earthing).

Getting A Hold Of Us

If something is wrong, please open a support ticket on our website at www.

blizzardlighting.com/support. We’ll be happy to help, honest.

Disclaimer: The information and specications contained in this document are subject

to change without notice. Blizzard Lighting™ assumes no responsibility or liability

for any errors or omissions that may appear in this user manual. Blizzard Lighting™

reserves the right to update the existing document or to create a new document to

correct any errors or omissions at any time. You can download the latest version of this

document from www.blizzardlighting.com.

Author: Date: Last Edited: Date:

J. Thomas J. Thomas12/1/2017 12/1/2017

Produktspecifikationer

Varumärke:	Blizzard Lighting
Kategori:	Effektmaskin
Modell:	Aria 26° Lens
Produkttyp:	Discobelysning, stroboskop
Vikt:	2404.04 g
Bredd:	444.5 mm
Djup:	482.6 mm
Höjd:	177.8 mm
Förpackningens bredd:	- mm
LED-indikatorer:	Ja
Certifiering:	ETL, CE, RoHS
Lämplig för inomhusbruk:	Ja
Färgåtergivningsindex (CRI):	90
Spänning:	100 - 240 V
Förpackningsvolym:	- cm ^
Ljuslägen:	DMX
DMX-ingång:	Ja
DMX-utgång:	Ja
Antal stift:	5
Antal DMX-kanaler:	9 kanaler
Garantiperiod:	- År
Produktens färg:	Svart
Låddjup:	- mm
Vikt inkl. förpackning:	- g
Lastpallens totalvolym:	- dm³
Lastpallens nettobredd:	- mm
Lastpallens nettodjup:	- mm
Lastpallens nettohöjd:	- mm
Ingångsfrekvens:	50 - 60 hz
Strömförbrukning (vanlig):	156 W
Lamptyp:	LED
Strömkälla:	AC
Lampor:	200 W
Antal:	1
Kuldiameter:	- "
Pallens nettovikt:	- g
Flimmerfri användning:	Ja
Integrerat handtag:	Ja
Minsta antalet DMX-kanaler:	6 kanaler
