Sida 1/54
In the box
1
Extension piece ,
2
Stand,
3
Fan motor,
4
Grille attachment,
5
Rear grille,
6
Screws (4x),
7
Remote,
8
Fan blades,
9
Fan fastener,
10
Grille closure ring,
11
Front grille,
12
Hex key.
1 2
8
9
10
11
12
3
54
7
6
PEDESTAL FAN ASSEMBLY.
Stay cool.
10 minutes 2 people 4 beads of sweat
Push the fan blades
8
onto the motor axle
of the fan motor
3
as far as you can.
Make sure that the 2 pins of the motor axle
fit into the grooves of the fan blades
8
.
Remove the grille attachment
4
from the
motor axle by rotating it counter-clockwise.
Attach the fan blades
8
with the fan
fastener
9
by rotating it counter-
clockwise.
Check if the fan blades
8
can rotate freely
by rotating them manually.
Open the grille closure ring
10
by 3mm.
Place the grille closure ring
10
around the
rear grille
5
.
Put the front grille
11
on the rear grille
5
and fasten the closure ring
10
.
Place the rear grille
5
on the designated
pins on the fan motor
3
.
Attach it with the grille attachment
4
by
rotating it clockwise.
Place the extension piece
1
of the fan
motor onto the stand
2
and attach it to the
bottom with the 4 screws
6
.
Make sure the cutouts on the stand
2
and
the extension piece
1
fit together.
Rotate the fan motor
3
clockwise to attach
it to the extension piece
1
.
CBL1175/CBL1176
1. ASSEMBLING THE STAND
2. GRILLE ATTACHMENT 3. REAR GRILLE ATTACHMENT
4. FAN BLADES
5. FAN FASTENER
6. FRONT GRILLE ATTACHMENT
Need help?
Call 010 798 89 99
Coolblue.nl/en/customer-
service
Follow all instructions as described here and
only use the included parts. Always let experts
handle repairs, or the warranty will be voided
and we won’t be liable. at would be a waste
of your purchase. Coolblue isn’t liable for any
injury, damage, or bad hair days as a result of
incorrect installation.
Tip:
Don’t throw out the box
containing the fan, but use it
to store the fan at the end of
the season.
Make sure the connector isn’t
plugged into the socket.
CHECKLIST.
You’re 50% there.
