123456

Programme selector / OffDisplay panel / Buttons

Display panel and settings

ʑ

Display panel (status indicators)

p

(Fluff filter/

Exhaust air duct)

Clean the fluff filter apage 4/11

or

check the exhaust air duct a page 8.

H|]+

-Æ->

(Programme

sequence)

These indicators show the programme progress in the next steps

of the drying cycle:

H Drying;

|] Iron Dry;

+Cupboard Dry;

-Æ-Programme pause aif required;

>Programme end.

(

(Childproof lock)

You can lock the dryer to prevent the functions you have set from being

changed inadvertently. To activate/deactivate ((Childproof lock) start

the programme or set the Finished in option and then press and hold

the$Start/Pause button for 5 seconds until a long acoustic signal is

heard. The option activated/deactivated a((Childproof lock) indicator

light on/off.

[h:min]

(Remaining time)

When a programme is selected, the anticipated drying time (remaining

time) for the recommended load is displayed. While drying, the moisture

sensors detect the actual load and correct the programme length. This is

shown by jumps in the remaining time in the display panel.

ʑ

Settings (indicators lights and buttons)



Drying time

Drying time, available only for timed programmes, can be selected

from min. 0:20 h to max. 3:00 h, in 10-minute steps.

y

Fine adjust

The dryness levels can be increased in three levels.

The laundry is made drier. Default = 0. Selectable values: 0, 1, 2, 3.

After setting the level of the fine adjustment for a programme, it is also

retained for other programmes, until yFine adjust is changed again.

³¤-¤

Finished in

The time when the programme has to end can be set by selecting the

Finished in time. The Finished in time can be selected in one-hour

steps, up to a maximum of 24 hours. Select the Finished inbutton

repeatedly until the required number of hours is displayed. Then press the

$Start/Pause button to activate the Finished in option. The

programme ends after the selected number of hours.

Several minutes after activating Finished inoption the display switches

off to save energy. To switch it on select any button, close/open the door

or turn the programme selector.

V

Low Heat

Reduced temperature for delicate fabrics, e.g. polyacrylic, polyamide

or elastane, with a longer drying time.

4

Wrinkle Guard

Plus

After the programme finishes, the drum moves at regular intervals

to prevent creases. Laundry remains loose and fluffy.

The standard setting for each programme is 60 min. Automatic

anti-crease function can be extended by up to 60 min.

&ü

Signal

For switching the buzzer on and off. &üSignalindicates program end

if it is activated. Other sounds are not influenced by this option.

Programmes / Fabrics

Detailed overview of the programmes and fabrics

aProgramme overview, page 7.

Observe the care instructions on the care label.

LCottonsHard-wearing fabrics.

ISyntheticsFabrics made from synthetic

or blended fabrics.

Dryness levels to select with the LCottons and ISynthetics programmes:

+: Cupboard Dry PlusThick and multi-layered fabrics.

+. Cupboard DrySingle-layered laundry.

|Iron Dry Laundry suitable for ironing after drying.

$÷SportswearFunctional clothing made of microfibre.

ØTowelsTerry-towelling laundry e.g. towels

and bathrobes.

1÷MixA mixed load of fabrics made of cotton

and synthetic fabrics.

Timed program

warm

All types of fabric

except for wool and silk.

Timed program

cold

cShirts/BlousesCotton or linen fabrics that are still damp

and easy-care fabrics.

cSuper 40’Synthetics, cotton or blended fabrics.

®÷Wool FinishWoollen fabrics that are suitable for use

in washers.

cDelicatesLingerie made of synthetic fibres, cotton

or blended fabric.

Your new dryer

Congratulations - You have chosen to buy a modern, high-quality

Bosch domestic appliance.

A distinctive feature of your dryer is its low energy consumption.

Every dryer which leaves our factory is carefully checked to ensure

that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will be

pleased to help.

Environmentally responsible disposal

Dispose of packaging in an environmentally-responsible manner.

This appliance is designated according to European directive 

2002/96/EC which governs waste electrical and electronic

equipment (WEEE).

This directive provides the framework for the EU-wide collection

and reuse of used appliances.

For further information about our products, accessories,

spare parts and services, please visit: www.bosch-home.com

Intended use

Preparation

Set and adjust the

programme individually

1

2

Drying

ʋexclusively for domestic use,

ʋonly for drying fabrics which have been washed using

water.

Do not leave children unsupervised near the dryer.

Keep pets away from the dryer.

The dryer may be operated by children from

8 years of age, by persons who have limited

physical, sensory or mental abilities and by

persons who have inadequate experience

or knowledge, provided they are supervised

or have been instructed by a responsible person.

Drying

Close the door

3

ContentsPage

ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋControl panel . . . . . . . . . . . . . . . . . . . . . 2

ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . .3/4

ʋDisplay panel and settings. . . . . . . . . . . 5

ʋNotes on laundry . . . . . . . . . . . . . . . . . . 6

ʋOverview of programmes. . . . . . . . . . . . 7

ʋCare and cleaning . . . . . . . . . . . . . . . . . 8

ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 9

ʋOptional accessories . . . . . . . . . . . . . . 10

ʋTechnical data . . . . . . . . . . . . . . . . . . . 10

ʋConsumption rates. . . . . . . . . . . . . . . . 10

ʋAfter-sales service . . . . . . . . . . . . . . . 11

ʋWhat to do if .... . . . . . . . . . . . . . . . 11/12

ʋSafety instructions. . . . . . . . . . . . . . . . . 13

Never start the dryer if it is damaged!

Inform your after-sales service!

Inspect the dryer

Sort the laundry

Remove all items from pockets,

especially cigarette lighters.

The drum must be empty prior to loading.

Make sure your hands are dry.

Only grasp the plug by the plug

body.

Connect the

mains plug

Clean the fluff filter

Do not operate the dryer without a fluff filter

or with a defective fluff filter. A clean fluff filter

minimises energy consumption.

Clean the fluff filter after each drying cycle:

1.Open the door. Remove any fluff from

the door/around the door and pull out

the fluff filter.

2.Remove the fluff from the shaft of the

fluff filter.

3.Remove the fluff (sweep your hand over

the fluff filter). If the fluff filter is very dirty

or blocked, rinse with warm water and

dry thoroughly.

4.Insert the fluff filter so that you hear

it engage.

6

End of the programme...

Interrupt the programme

1.Open the door or press the $Start/Pauseübutton;

the drying cycle is interrupted.

2.Add or remove laundry and close the door.

3.If required, select a new programme and additional

functions. Select the $Start/Pause button. The

remaining time is updated after a few minutes.

The drum and door may be hot!

Notes on laundry ...

Labelling of fabrics

Follow the manufacturer's care instructions.

hcSuitable for tumble drying.

(cDry at normal temperature.

'cDry at low temperature a in addition, select VLow Heat.

)cDo not tumble dry.

Do not tumble dry the following fabrics:

–Non-breathable fabrics (e.g. rubber-coated).

–Delicate materials (silk, curtains made from synthetic material) a these may crease.

–Oil-stained laundry.

Before drying for the first time

–Do not put any laundry in the machine. Turn the programme selector to Timed program

(a page 7) and select $Start/Pause. At the end of the programme, turn the programme

selector to Off.

Drying tips

–To ensure a consistent drying result, sort the laundry by fabric type and drying programme.

–Always dry very small fabrics (e.g. baby socks) together with large items of laundry

(e.g. towels).

–Close zips, hooks and eyelets, and button up covers.

Tie cloth belts, apron strings, etc. together or use a laundry bag.

–Do not over-dry easy-care laundry a risk of creasing.

Allow laundry to finish drying in the air.

–Do not dry woollens in the dryer. They may, however, be refreshed in the dryer

apage 7, O÷Wool Finish programme (depending on model).

–Do not iron laundry immediately after drying; fold items up and leave for a while

a residual moisture will then be distributed evenly.

–Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.

a Do not use the +: Cupboard Dry Plus programme.

–Starched laundry is not always suitable for dryers a starch leaves behind a coating that

reduces the drying effect.

–When washing laundry that is to be tumble dried afterwards, use the correct amount of

fabric softener as specified in the manufacturer's instructions.

–For pre-dried, multi-layered fabrics or small, individual items of laundry, use the timed

programme. Also suitable for subsequent drying.

Environmental protection / Energy-saving tips

–Before drying, spin the laundry in the washing machine a higher spin speeds minimise

the drying time and reduce energy consumption.

–Use the maximum recommended capacity, but do not exceed it

a Programme overview, page 7.

–Make sure the room is well ventilated during drying.

–Clean the fluff filter after every drying cycle a Clean the fluff filter,page 4/11.

Remove the laundry and switch off

the dryer

5

4

Control panel

Fluff filter

Select

$Start/Pause

Door

Installationapage 9

and Exhaust air duct installation instruction.

Observe the safety instructions on page 13.

Read these instructions, the Installation

Instructions and the separate Energy-saving

mode instructions before operating the dryer.

Selected option activated/deactivated aindicator light on/off.

See the separate Energy-saving mode instructions.

Before using the dryer for the first time

run the drying cycle without any laundryapage 6.

Programme selector for setting

the programme and switching the appliance

on/off. Can be turned in both directions.

`

Programme sequenceH|]+



-Æ->

 Drying TimeSetting the drying time available only for timed programmes.

yFine adjustFine adjustment of dryness level.

Childproof lock

(

³¤-¤

Finished inSetting the programme end.

Fluff filter/Exhaust air ductpVLow HeatLow-heat drying  reduced temperature.

4Wrinkle Guard PlusExtends the anti-crease function.

&

SignalBuzzer on/off.

$Start/PauseStarts, pauses and continues the programme;

activates or deactivates ((Childproof lock).

Further information

can be found

on page 5

7

Programme overview see also page 6.

Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying.

After drying, laundry is to be ...

cironedlightly ironed@cnot ironed cmangled

PROGRAMMESTEXTILE TYPE AND INFORMATION

*LCottons

max. 7 kg

Hard-wearing fabrics, boil-proof fabrics made of cotton or linen.

*ISynthetics

max. 3.5 kg

Non-iron laundry made of synthetic fibres and mixed fabric, easy-care cotton.

|Iron Dry

c÷@c

The condition of the laundry means it is suitable for ironing (iron clothes in order to avoid creases).

+.Cupboard Dry

@

Single-layered laundry.

+:Cupboard Dry Plus

@

Laundry with thick, multi-layered parts.

$÷Sportswear

max. 1.5 kg

Fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics (dry jackets/trousers with

removable internal lining separately).

ØTowels

max. 6 kg

Terry-towelling laundry e.g. towels and bathrobes.

1÷Mix

max. 3 kg

Mixed items of laundry made of cotton and synthetics (Mix).

Timed program warm

max. 3 kg

Pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry.

Also for subsequent drying.

Timed program cold

max. 3 kg

All types of fabrics. For freshening up or airing of items of laundry that have been worn for a short period of time.

cShirts/Blouses

max. 3 kg

Cotton or linen fabrics that are still damp and easy-care fabrics. Creasing in fabrics is reduced. Fabrics are not dried

completely. Hang up fabrics!

ASuper 40’

max. 2 kg

Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may

differ from the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the fabric

and loading capacity.

®÷Wool Finish

max. 3 kg

Woollen fabrics suitable for washers. Fabrics become fluffier but not dry.

Remove fabrics once the programme has ended and allow to dry.

cDelicates

max. 1 kg

Lingerie made of synthetic fibres, cotton or blended fabric.

*Dryness levels can be selected individually a+:Cupboard Dry Plus, +.Cupboard Dry and |Iron Dry (depending on the model).

Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing.

Recommendation: Dry separately.

9309 / 9000811321

*811321*

Robert Bosch Hausgeräte GmbH

Carl-Wery-Str. 34

81739 München/Deutschland

WTA74201IL

Produktspecifikationer
