BY-DM20
90x120
深圳市长丰影像器材有限公司
品牌
子件名称 版本
材质
比例
审核 暂无
吴蒙蒙
2019-8-26 核准/日期 赵宏亮
单位1:1 mm尺寸
子件编号
设计/日期
长丰型号
8
变更日期 变更担当变更内容版本修改名称
7
1 2
BY-DM20说明书
BY-DM20说明书 第一页内容更改，封底加联系电话 吴蒙蒙V01 2019-8-26
BOYA BY-DM20
1F0300300202
V01
105g双铜纸 骑马钉 10p
吴蒙蒙
长丰影像
2019-8-26
技术要求:
1、表面无色差
2、无正负公差
3、包装标注尺寸为内尺寸
Dual-Channel Recording Kit
Instruction Manual
Thank you for purchasing the BY-DM20 dual-channel
recording kit!
● Main body x1
● Type-C to USB cable x1
● Type-C to Type-C cable x1
● Type-C to Lightning cable x1
● Lavalier mic x2
● Foam windscreen x2
● Clip for lavalier mic x2
● Belt clip x1
● Carrying case x1
● User guide x1
① Indicate light
1) “Blue light on” for recording
2) “Green light on” for replay
3) “Both lights on” for real-time playing by compatible App
② Mic/Line-in jack (Left channel)
③ Type-C port
④ Mic/Line-in jack (Right channel)
⑤ Volume control (Right channel)
⑥ Recording/Play switch
1 switch to “REC” for recording)
2) switch to “PLAY” for replay
⑦ Earphone jack
⑧ Stereo/Mono switch
1 switch to “S” for stereo)
2) switch to “M” for mono
⑨ Volume control (Left channel)
1. Install the clip and windscreen
3. Mount the microphone to your clothing 4. Connect BY-DM20 to your device
5. Settings
2. Connect lavalier mics and cables to main body
BY-DM20 is a multi-function recording kit with 2 mic-in/line-in
audio inputs and 1 audio output. It’s a professional sound
solution for iOS devices, Type-C Android devices and Laptop.
It can be used in a wide range applications include: interview,
news production, ENG/EFP, film production, music recording,
commercial and educational activities etc.
- Choose and connect the right cable with your device
- Open a compatible app and start recording
Please follow the instructions here if there’s any problems
- Adjust left/right channel volume from side wheel
- Select between Mono(M) or Stereo(S) mode from
side button
- Select between recording(REC) or replay(PLAY) mode
Problem
Low sound
Distortion
Unwanted sound
No sound
Reason
Didn’t switch to “Play” mode
Disability of cable connection
Disability of earphone connection
Improper sound setting
Improper sound setting
Mono earphone under stereo mode
Omni-directional polar pattern
Solution
Swicth to “Play”
Re-connect
Re-connect
Adjust sound wheel
Adjust sound wheel
Match the earphone
Adjust mic position
closer to sound source
Introduction
Troubleshooting
Frequency response:
Gain:
Sampling frequency:
Bitrate:
Power requirements:
Output connector:
Cable length:
Specifications
Instructions
Package contents
Operations
Features
20-25cm
(8-10 inches)
• Attach the microphone to the front of your clothing
with the clothing clip, about 20-25cm (8-10 inches)
from your face.
1) Attach the microphone upside down to reduce
excessive breath noises and tonal inconsistencies
due to head movements.
2) It is recommended that you use the foam wind
screen at all times to avoid wind noise, even when
recording inside.
www.boya-mic.com
SHENZHEN JIAYZ PHOTO INDUSTRIAL., LTD.
The BOYA logo is a trademark which is registered and owned by
Shenzhen Jiayz Photo Industrial., Ltd.
COPY RIGHT 2010-2020
TEL: 400 6131096
Email: sales@boya-mic.com
www.boya-mic.com / www.jiayz.com
1 2 3 4
567
- All-in-one recording solution
- Compact and easy to use
- Dual-channel audio inputs
- Ideal for interview or other demands for capturing two
subjects
- Stereo and Mono mode selectable
- Volume control for each channel separately
- 3.5mm Headphone output
- Compatible with iOS, Android(Type-C), Laptop
45Hz-20kHz
0-30dB
44.1kHz /48kHz
16Bit /24Bit
Powered from the device
Type-C to Lightning
Type-C to USB
Type-C to Type-C
Mic cable: 2.0m
Output cable: 0.3m
