HS-300

Physician Scale

 300 kg / 660 lb Capacity

 Height Gauge to 210 cm / 7'

 Rollers Included for Easy Transport

 Easy to Read Digital LCD Display

 Measures in Kilograms and Pounds

 Durable Construction

 Accuracy at +/- 3 Divisions

 Large 521 mm x 521 mm / 20.5" x 20.5"

Weighing Platform

HS-300 Physician Scale

Speci

Speciﬁ

ﬁ

cations

cations Speciﬁ cations

Features

Features Features

The HS-300 is used where either weight or height

measurements are necessary.

The scale provides accurate weight or height

measurements on easy to read LCD back light display.

It has a large weighing range and can measure height

from 60cm to 210cm x 0.1cm (2' to 7' x 0.125").

Constructed of mild steel with a durable powder coated

white finish, this scale will provide years of service in

normal applications.

2/17 HS-300_L_500790.indd AWT35-500790

Platform DImension: 521 mm (L) x 521 mm (W)

20.5" L x 20.5" W

Handrail Height: 406 mm (W) x 1245 mm (H)

16" W x 49" L

Scale Capacity & Height Rod Range:

300 kg x 0.1 g (660 lb x 0.2 lb)

60 cm to 210 cm x 0.1 cm (2' to 7' x 0.125")

Display: 17 mm (0.625") high backlite LCD

Indicator: 165 mm (L) x 30 mm (W) x 81 mm (H)

6.5" L x 1.2 W x 3.2" H

Serial Port: One (1) full duplex RS232 with cable

Function Keys: Hold/Print, Units, Tare, On/Off/Zero

Unit: lb, kg, lb/oz

Power: 6 VDC, 500mA US power adapter (included)

Optional UK Power Adapter: 816965002887

Optional EU Power Adapter: 816965002870

DC Power: (4) AAA batteries (included)

Battery Life: Approximately 20 hours continuous

Operating Temperature: 5° C to 35° C (41° F to 95° F)

RS-232: Supplied complete with 10' cable (9 pin to 9 pin

type connector, bi-directional full duplex)

Certiﬁ cations: Full FCC compliance, UL/CUL power

adapter

Product Code: 816965004812

Shipping Weight: 24 kg (54 lb)

Package Dimension:

775 mm (W) x 1384 mm (L) x 230 mm (H)

30.5 W x 54.5 L x 9 H″ ″ ″

Packaging Contents: Platform, Indicator, Handrail,

Manual, Height Gauge, RS-232 Cable, Power Supply

and Miscellaneous Hardware

Brecknell

1000 Armstrong Dr., Fairmont, MN 56031

Toll free: 800-637-0529, Tel: 507-238-8702

Fax: 507-238-8271

e-mail: sales@brecknellscales.com

www.brecknellscales.com

Brecknell

Foundry Lane, Smethwick

West Midlands B66 2LP UK

Tel: +44 (0) 845 246 6717

Fax: +44 (0) 845 246 6718

Email: sales@brecknellscales.co.uk

www.brecknellscales.co.uk

a division of Avery Weigh-Tronix, LLC
