MODELS BWP1244SS • BWP1304SS • BWP1364SS • BWP2244SS •
BWP2304SS • BWP2364SS • BWP2306SS • BWP2366SS
Page 1
CHIMNEY
RANGE HOOD
! INTENDED FOR DOMESTIC COOKING ONLY . !
READ AND SAVE THESE INSTRUCTIONS
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSON(S) OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer.
If you have questions, contact the manufacturer at the
address or telephone number listed in the warranty.
2. Before servicing or cleaning unit, switch power off at service
panel and lock service disconnecting means to prevent
power from being switch on accidentally. When the service
disconnecting means cannot be locked, securely fasten a
prominent warning device, such as a tag, to the service
panel.
3. Installation work and electrical wiring must be done by
qualified personnel in accordance with all applicable codes
and standards, including fire-rated construction codes and
standards.
4. Sufficient air is needed for proper combustion and exhausting
of gases through the flue (chimney) of fuel burning equipment
to prevent backdrafting. Follow the heating equipment
manufacturer’s guidelines and safety standards such as
those published by the National Fire Protection Association
(NFPA), the American Society for Heating, Refrigeration
and Air Conditioning Engineers (ASHRAE) and the local
code authorities.
5. This product may have sharp edges. Be carefule to avoid
cuts and abrasions during installation or cleaning.
6. When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
7. Ducted fans must always be vented to the outdoors.
8. Do not use this unit with any other solid-state speed control
device.
9. Use only metal ductwork.
10. This unit must be grounded.
TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
a) Never leave surface units unattended at high settings.
Boilovers cause smoking and greasy spillovers that may
ignite. Heat oils slowly on low or medium settings.
b) Always turn hood ON when cooking at high heat or when
cooking flaming foods (i.e. Crêpes Suzette, Cherries Jubilee,
Peppercorn Beef Flambé).
c) Clean ventilating fans frequently. Grease should not be
allowed to accumulate on fan or filters.
d) Use proper pan size. Always use cookware appropriate for
the size of the surface element.
WARNING
TO REDUCE THE RISK OF INJURY TO PERSON(S) IN THE
EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE
FOLLOWING*:
1. SMOTHER FLAMES with a close-fitting lid, cookie sheet, or
metal tray, then turn off the burner. BE CAREFUL TO PREVENT
BURNS. IF THE FLAMES DO NOT GO OUT IMMEDIATELY,
EVACUATE AND CALL THE FIRE DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN – You may be burned.
3. DO NOT USE WATER, including wet dishcloths or towels –
This could cause a violent steam explosion.
4. Use an extinguisher ONLY if:
A. You know you have a Class ABC extinguisher and you
know how to operate it.
B. The fire is small and contained in the area where it
started.
C. The fire department has been called.
D. You can fight the fire with your back to an exit.
* Based on “Kitchen Fire Safety Tips” published by NFPA.
CAUTION !
1. For indoor use only.
2. For general ventilating use only. Do not use to exhaust
hazardous or explosive materials and vapors.
3. To avoid motor bearing damage and noisy and/or
unbalanced impeller, keep drywall spray, construction dust,
etc. off power unit.
4. Do not use over cooking equipment greater than 60,000
BTU/hr. as the blower motor will shut down intermittently.
5. Your hood motor has a thermal overload which will
automatically shut off the motor if it becomes overheated.
The motor will restart when it cools down. If the motor
continues to shut off and restart, have the hood serviced.
6. The bottom of the hood MUST NOT BE LESS than 26” and
at a maximum of 36” above cooktop for best capture of
cooking impurities.
7. Two installers are recommended because of the size of
this hood.
8. To reduce risk of fire and to properly exhaust air, be sure
to duct air outside. Do not exhaust air into spaces within
walls or ceilings or into attics, crawl spaces, or garages.
9. Be careful when installing the decorative flue and hood,
they may have sharp edges.
10. Please read specification label on product for further
information and requirements.
INSTALLER: LEAVE THIS GUIDE WITH THE HOMEOWNER.
HOMEOWNER: OPERATION AND MAINTENANCE INFORMATION ON PAGE 2.
WARNING
To register this product visit:
www.broan-nutone.com or
www.broan.ca
MODELS BWP1244SS • BWP1304SS • BWP1364SS • BWP2244SS •
BWP2304SS • BWP2364SS • BWP2306SS • BWP2366SS
Page 2
CLEANING & MAINTENANCE
Proper maintenance of the Range Hood will assure proper
performance of the unit.
MOTOR
The motor is permanently lubricated and never needs oiling. If
the motor bearings make excessive or unusual noise, replace
the blower with the exact service blower.
GREASE FILTERS
The grease filters should be cleaned frequently. Use a warm
dishwashing detergent solution. Grease filters are dishwasher
safe.
Clean all-metal filters in the dishwasher using a non-phosphate
detergent. Discoloration of the filters may occur if using phosphate
detergents, or as a result of local water conditions - but this will
not affect filter performance. This discoloration is not covered by
the warranty.
Remove grease filters by pulling down on the metal latch tab. This
will disengage the filter from the hood. Tilt the filter downward
and remove.
NON-DUCTED RECIRCULATION FILTERS
The non-ducted recirculation filters should be changed every
6 months. Replace more often if your cooking style generates
extra grease, such as frying and wok cooking. Turn the filter
mounting tabs to remove filter and replace.
STAINLESS STEEL CLEANING
DO:
• Regularly wash with clean cloth or rag soaked with warm water
and mild soap or liquid dish detergent.
• Always clean in the direction of original polish lines.
• Always rinse well with clear water (2 or 3 times) after cleaning.
Wipe dry completely.
• You may also use a specialized household stainless steel
cleaner.
DON’T:
• Use any steel or stainless steel wool or any other scrapers to
remove stubborn dirt.
• Use any harsh or abrasive cleansers.
• Allow dirt to accumulate.
• Let plaster dust or any other construction residues reach the
hood. During construction/renovation, cover the range hood to
make sure no dust sticks to the stainless steel surface.
Avoid: When choosing a detergent
• Any cleaners that contain bleach will attack stainless steel
• Any products containing: chloride, fluoride, iodide, bromide
will deteriorate surfaces rapidly.
• Any combustible products used for cleaning such as acetone,
alcohol, ether, benzol, etc., are highly explosive and should
never be used close to a range.
OPERATION
The hood is operated using the push buttons on the front panel.
Push the light button to turn the lights on and off.
Push the blower controls to select low, medium, or high blower
speed (for each speed selected, its indicating light will beam).
Press on the current blower speed another time to stop it.
While the blower is activated, press the 5-minute delay button
once (its indicating light will beam) to get the hood running for
5 minutes and then turn off automatically.
When the 5-minute delay is activated, changing the blower
speed will cancel the 5-minute delay function.
To cancel the delay off function before the end of the 5-minute
cycle, press again on delay off push button or select an other
blower speed.
LIGHT
ON/OFF
LOW MED. HIGH
BLOWER CONTROLS
5-MINUTE
DELAY
MODELS BWP1244SS • BWP1304SS • BWP1364SS • BWP2244SS •
BWP2304SS • BWP2364SS • BWP2306SS • BWP2366SS
Page 3
INSTALL THE DUCTWORK
(Ducted Hoods Only)
1. Decide where
the ductwork
will run
between the
hood and the
outside.
2. A straight, short
duct run will
allow the hood
to perform most
efficiently.
3. Long duct
runs, elbows
and transitions
will reduce the
performance of
the hood. Use as few of them as possible. Larger ducting
may be required for best performance with longer duct runs.
4. Install wall cap or roof cap. Connect round metal ductwork
to cap and work back towards the hood location. Use duct
tape to seal the joints between ductwork sections.
MEASURE THE INSTALLATION
The minimum hood distance above cooktop MUST NOT BE
LESS than 26”.
A maximum of 36” above cooktop is highly recommended for
best capture of cooking impurities.
Distances over 36” are at the installer and users discretion;
providing that the ceiling height permits.
6"
ROUND DUCT
ROOF CAP
ROUND
ELBOW
26" MIN. ABOVE
COOKING SURFACE
WALL
CAP
HOOD
DECORATIVE
FLUE
9-3/4”
WALL CAP
26” - 36” ABOVE
COOKING SURFACE
HOOD
DECORATIVE FLUE
ROOF CAP
6” ROUND DUCT
ROUND ELBOW
10-5/8”
TO CENTER OF
BRACKET HOLES
HOOD
MOUNTING
BRACKET
3-3/8”
DUCT
CENTER
LINE
PREPARE THE HOOD
Unpack hood and check contents. You should receive:
1 - Hood
1 - Decorative Flue Assembly
2 - Damper Flaps
1 - Lower Flue Mounting Bracket
1 - Upper Flue Mounting Bracket
1 - Hood Mounting Bracket
2 - Aluminum Grease Filters for 24" and 30" wide hoods,
(BWP1 series, included packaged in a cardboard box)
3 - Aluminum Grease Filters for 36” wide hood
(BWP1 series, included packaged in a cardboard box)
2 - Hybrid Baffle Filters for 24” and 30” wide hoods,
(BWP2 series, included packaged in a cardboard box)
3 - Hybrid Baffle Filters for 36” wide hood
(BWP2 series, included packaged in a cardboard box)
1 - Installation Manual
1 - Parts Bag containing:
6 - Mounting Screws (no. 8 x 3/8” Pan Head)
7 - Mounting Screws (no. 8 x 1-1/2” Flat Head)
7 - Drywall Anchors
2 - Washers
7 MOUNTING
SCREWS
(no. 8 x 1½”
Flat Head)
7 DRYWALL
ANCHORS
6 MOUNTING
SCREWS
(no. 8 x 3/8”
Pan Head)
DECORATIVE FLUE
2 WASHERS
UPPER
FLUE MOUNTING
BRACKET
HOOD
MOUNTING
BRACKET
LOWER
FLUE MOUNTING
BRACKET
DAMPER
FLAPS
MODELS BWP1244SS • BWP1304SS • BWP1364SS • BWP2244SS •
BWP2304SS • BWP2364SS • BWP2306SS • BWP2366SS
Page 4
PREPARE THE HOOD (CONT D’ )
For ducted installation only:
Install both damper flaps inside the blower exhaust opening,
ensuring the pins are top oriented. See illustration below.
P INS ON TOP
1. GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock
by providing an escape wire for the electric current. This
appliance is equipped with a cord having a grounding wire
with a grounding plug. The plug must be plugged into an
outlet that is properly installed and grounded.
NOTE:
A recessed “clock” outlet is recommended.
2. Position the electrical outlet within the space covered by
the decorative flue and where it will not interfere with the
round duct. Make sure the outlet does not interfere with the
mounting bracket fastening area, ductwork, or where the
decorative flue touches the wall.
INSTALL THE WIRING
4”
22”
11”
LOCATE
ELECTRICAL
OUTLET
WITHIN THESE
AREAS.
(Verify location
will not interfere
with duct,
mounting
brackets,
and flue.)
MODELS BWP1244SS • BWP1304SS • BWP1364SS • BWP2244SS •
BWP2304SS • BWP2364SS • BWP2306SS • BWP2366SS
Page 6
INSTALL UPPER FLUE MOUNTING
BRACKET
1. If a framing member is not present, drill two 5/16” diameter
holes where shown. Insert drywall anchors into the holes.
2. Center the bracket over the hood location and flush with the
ceiling. Make sure that the slots of the upper flue bracket are
at the bottom. Secure the upper flue bracket to the wall using
(2) no. 8 x 1½” mounting screws.
3. Tighten the screws completely. Make sure that the bracket
is tight against the wall.
C
L
Flush with
the ceiling
Center of
installation
Upper flue mounting
bracket slots
C
L
4¼”
2⁄8”
1”
Recommended
distance between
screw holes
Ceiling
Ø 5/16” TYP.
Ceiling
Center of installation
INSTALL THE HOOD
(Horizontally Ducted Hoods Only)
1. DO NOT REMOVE the protective plastic film covering the
decorative flue and the hood at this time.
2. Lay the back side of the hood flat on a table. Use a piece of
cardboard to avoid damaging the table or the hood.
3. Remove the grease filters by pulling down the metal latch
tab and tilting filters downward to remove.
4. Carefully rotate hood upright.
INSIDE BACK OF HOOD
MOTOR/BLOWER
ASSEMBLY
HOLES LOCATION
SIDE VIEW
Ø 5/16” TYP.
5. To make sure there will be adequate clearance between top
of hood and lower flue mounting bracket for ductwork: Elbow
must be located below lower flue mounting bracket.
6. Align the hood and center it above the hood mounting
bracket. Gently lower the hood until it securely engages the
bracket.
7. With the hood hanging in place, drill through both holes
located in the inside lower back of hood using a 5/16” drill
bit. Insert the included drywall anchors into the drilled holes
(one for each hole). Install (2) washers and (2) no. 8 x 1½”
mounting screws through the hood back and into the drywall
anchors. Verify that the hood is centered and leveled.
Tighten all screws completely.
8. Reinstall grease filters by aligning rear filter tabs with slots
in the hood. Pull down the metal latch tab, push filter into
position and release. Make sure filters are securely engaged
after installation.
14¼”
MAX.
LOWER FLUE
MOUNTING BRACKET
Produktspecifikationer
| Varumärke: | Broan |
| Kategori: | Fläktkåpa |
| Modell: | BWP2244SS |
Behöver du hjälp?
Om du behöver hjälp med Broan BWP2244SS ställ en fråga nedan och andra användare kommer att svara dig
Fläktkåpa Broan Manualer
8 Januari 2025
6 Januari 2025
6 Januari 2025
27 Oktober 2024
21 September 2024
21 September 2024
21 September 2024
21 September 2024
21 September 2024
21 September 2024
Fläktkåpa Manualer
- Fläktkåpa Constructa
- Fläktkåpa Freggia
- Fläktkåpa Siku
- Fläktkåpa Rosieres
- Fläktkåpa Hisense
- Fläktkåpa Cobal
- Fläktkåpa Comfee
- Fläktkåpa Vox
- Fläktkåpa Foster
- Fläktkåpa Delonghi
- Fläktkåpa NuTone
- Fläktkåpa Dominox
- Fläktkåpa Zelmer
- Fläktkåpa Flama
- Fläktkåpa Indesit
Nyaste Fläktkåpa Manualer
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
