Start Here

Quick Setup Guide

USA/CAN Version 0

ADS-2500W

Thank you for choosing Brother, your support is important to us and we value your business. Your Brother product

is engineered and manufactured to the highest standards to deliver reliable performance, day-in and day-out.

Please read the Product Safety Guide first before you set up your machine. Then, please read this Quick Setup

Guide for the correct setup and installation.

Unpack the machine and check the components

 The components included in the box may differ depending on your country.

WARNING

• This product was packaged in a plastic bag. To avoid suffocation, keep such plastic bag away from

babies and children. Do not use the bag in cribs, beds, carriages or play pens. The bag is not a toy.

• Only use the power cord supplied with this product.

a Remove the protective tape and film covering the machine and the LCD.

b Make sure you have all the components.

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided, could result in death

or serious injuries.

AC Power Cord

USB Interface Cable

Carrier Sheet/

Plastic Card Carrier Sheet

Quick Setup Guide

Product Safety Guide

Product Registration Sheet (USA only)

Warranty Card (USA only)

DVD-ROM

Note

• We recommend that you save the original packaging in case you must ship your machine.

• Please use the supplied USB cable if you wish to connect the machine to a computer.

USB cable

It is recommended to use a USB 2.0 cable (Type A/B) that is no more than 6 feet (2 meters) long.

Network cable

Use a straight-through Category5 (or greater) twisted-pair cable for 10BASE-T or 100BASE-TX Fast Ethernet

Network.

Connect the power cord

a Connect the power cord.

WARNING

The machine must be fitted with a three prong

grounded plug.

b Open the Top Cover a.

c Pull the Output Tray out of the machine a and

then unfold the Document Stopper b.

Choose your language

(if needed)

a Press .

b Swipe up or down, or press a or b to display

Initial Setup.

Press Initial Setup.

c Press Local Language.

d Swipe up or down, or press a or b to display

your language.

Press your language.

e Press .

Important

DO NOT connect the USB cable yet.

Set the date and time

The machine displays the date and time.

a Press .

b Swipe up or down, or press a or b to display

Initial Setup.

Press Initial Setup.

c Press Date & Time.

d Press Date.

e Enter the last two digits of the year on the

Touchscreen, and then press OK.

f Enter the two digits for the month on the

Touchscreen, and then press OK.

g Enter the two digits for the day on the

Touchscreen, and then press OK.

h Press Clock Type.

i Press 12h Clock or 24h Clock.

j Press Time.

k Enter the time on the Touchscreen.

(12h Clock only)

Press to cycle AM and PM.

l Press OK, and then press .

Automatic Daylight

Savings Time

You can set the machine to change automatically for

daylight savings time. It will reset itself forward one

hour in the spring and backward one hour in the fall.

a Press .

b Swipe up or down, or press a or b to display

Initial Setup.

Press Initial Setup.

c Press Date & Time.

d Press Auto Daylight.

e Press On (or Off).

f Press .
