Start Here

DCP-J172W

Quick Setup Guide

ARL/NZ Version 0

Please read the Product Safety Guide first before you set up your machine. Then, please read this Quick Setup

Guide for the correct setup and installation.

Unpack the machine and check the components

 The components included in the box may differ depending on your country.

* If your computer does not have a CD-ROM drive, the supplied CD-ROM does not contain drivers for your

operating system, or you want to download manuals and utilities, visit your model page at

http://solutions.brother.com/

WARNING

• Plastic bags are used in the packing of your machine. To avoid the danger of suffocation, keep these

plastic bags away from babies and children. Plastic bags are not toys.

• To ensure safe operation the supplied plug must be inserted only into a standard power outlet that is

properly grounded through the standard electrical wiring. Non grounded equipment may cause an

electrical shock hazard, and may cause excessive electrical noise radiation.

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided, could result in death

or serious injuries.

CAUTION

CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor

or moderate injuries.

IMPORTANT

IMPORTANT indicates a potentially hazardous situation which, if not avoided, may result in

damage to property or loss of product functionality.

NOTE

Notes tell you how to respond to a situation that may arise or give tips about how the operation

works with other features.

Starter Ink Cartridges

Black

Yellow

Cyan

Magenta

Quick Setup Guide

USB Interface Cable

Basic User’s Guide Product Safety Guide CD-ROM* Power Cord

NOTE

Save all packing materials and the box in case for any reason you must ship your machine.

USB cable

Please use the supplied USB cable for a USB connection.

We recommend using a USB 2.0 cable (Type A/B) that is no more than two metres long.

a Remove the protective tape and film covering

the machine, and also from the Touchscreen.

Remove

the plastic bag a containing the ink

cartridges from on top of the paper tray.

c Make sure you have all the components.

Connect the power cord

WARNING

The machine must be fitted with an earthed

plug.

a Connect the power cord.

Choose your language

a Choose your language.

b Press Yes or No.

NOTE

DO NOT connect the USB cable yet (if you are

using a USB cable).

(Example for Australia)

NOTE

• The Warning LED on the control panel will stay

on until you have installed the ink cartridges.

• To prolong the life of the print head, provide the

best ink cartridge economy and maintain print

quality, we do not recommend unplugging the

machine frequently and/or leaving the machine

unplugged for extended periods of time. Each

time you plug the machine in, it automatically

cleans the print head, which uses some of your

ink.

We recommend using to power down the

machine. Using allows minimal power to

the machine, resulting in periodic, but less

frequent, cleaning of the print head.

NOTE

If you set the wrong language, you can change it

after setting the date and time. (uuAdvanced

User’s Guide: Changing the Touchscreen

language)

Produktspecifikationer

Varumärke:	Brother
Kategori:	Skrivare
Modell:	DCP-J172W
Inbyggd display:	Ja
Vikt:	6900 g
Bredd:	410 mm
Djup:	374 mm
Höjd:	161 mm
Förpackningens bredd:	478 mm
Processorfrekvens:	288 MHz
Processorfamilj:	RISC
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Maximal upplösning:	1200 x 6000 DPI
Internminne:	64 MB
Energisparläge:	Ja
Antal bläckpatroner:	4
Standardgränssnitt:	USB 1.1, USB 2.0, Wireless LAN
Digital avsändare:	Nej
Maximal kopieringsupplösning:	1200 x 1200 DPI
Fax:	Nej
Mobil utskriftsteknik:	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Maximalt antal kopior:	99 kopior
Dubbelsidig kopiering:	Nej
Dubbelsidig faxning:	Nej
Serveroperativsystem som stöds:	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Skanningshastighet:	3.37 sek/sida
Produktens färg:	Svart
Låddjup:	229 mm
Vikt inkl. förpackning:	8400 g
Mac-operativsystem som stöds:	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Utskrift:	Färgutskrift
Dubbelsidig utskrift:	Nej
Kopiering:	Färgkopiering
Hållbarhetscertifiering:	Blue Angel, ENERGY STAR
Nätverksansluten (Ethernet):	Nej
Bildkomprimeringsformat:	BMP, JPG, PNG, TIF
Displaytyp:	LCD
Antal USB 2.0 anslutningar:	1
USB-port:	Ja
Strömförbrukning i vänteläge:	3.5 W
Strömförbrukning i avslaget läge:	0.2 W
Positionering på marknaden:	Hem och kontor
Strömförbrukning i PowerSave läge:	0.7 W
Dokument som stöds:	PDF
Utskriftsteknologi:	Bläckstråleskrivare
Utskriftshastighet (Svart, normalkvalitet, A4/US Brev):	27 ppm
Utskriftshastighet (färg, normal kvalitet, A4/US Letter):	10 ppm
Driftcykel per månad:	- sidor per månad
Total inmatningskapacitet:	100 ark
Total utmatningskapacitet:	50 ark
Högsta ISO A-seriestorlek:	A4
Pappersfackets typ av media:	Glossy paper, Plain paper, Transparencies
ISO A-serie storlek (A0...A9):	A4, A5, A6
Icke-ISO utskriftsmaterial av olika storlek:	2L, Executive (184 x 267mm), Index card, L,Letter (media size)
Maximal utskriftstorlek:	210 x 297 mm
Maximal skannerupplösning:	19200 x 19200 DPI
Optisk skanningsupplösning:	1200 x 2400 DPI
Skanning:	Färgscanning
Kopieringshastighet (normalkvalitet, svart, A4):	4.4 kopior per minut
Kopieringshastighet (färg, normalkvalitet, A4):	2.7 kopior per minut
Storleksändring kopieringsmaskin:	25 - 400 %
Ljudtrycksnivå (utskrivning):	50 dB
Kuvertstorlek:	10, C5, DL, Monarch
Strömförbrukning (genomsnittligt operativt):	16 W
Kopiering utan dator:	Ja
Skanningsteknik:	CIS
Maximalt skanningsområde:	A4 (210 x 297) mm
Skanning till:	Cloud, E-mail, File, Image
Skrivarfäger:	Black, Cyan, Magenta, Yellow
Foto-pappersstorlekar:	10x15 cm
Dubbelsidig skanning:	Nej
Utskriftshastighet (ISO / IEC 24734), mono:	11 IPM
Utskriftshastighet (ISO / IEC 24734), färg:	6 IPM
Tillgängliga onlinetjänster:	Dropbox, Evernote, Facebook, Flickr, Google Drive, Picasa, Sky Drive
Antal USB 1.1 anslutningar:	1
