Unpack the machine and check the components

Read the Product Safety Guide first, then read this Quick Setup Guide for the correct

installation procedure.

NOTE:

•The components included in the box and the AC power plug may differ depending on your

country.

•The illustrations in this Quick Setup Guide are based on the MFC‑L2700DW.

•You must purchase the correct interface cable for the interface you want to use.

USB cable

We recommend using a USB 2.0 cable (Type A/B) that is no more than 2 metres long.

Network cable

Use a straight‑through Category 5 (or greater) twisted‑pair cable for 10BASE‑T or

100BASE‑TX Fast Ethernet Network.

Remove the packing materials and install the toner cartridge

Load paper in the paper tray

Connect the machine to your computer/mobile device

Connect the power cord and turn on the machine

Select your language (If needed)

(Only for certain models)

Drum Unit

(Pre‑installed)

AC Power Cord

(only for certain

models)

Quick Setup Guide CD‑ROM

(For U.K.) (For Others)

Inbox Toner

Cartridge

Telephone Line Cord

(For MFC models)

Product Safety Guide Basic User's Guide

(only for certain

models)

1. (DCP model)

a. Press Menu.

b.Press▲or▼todisplayGeneral Setup, and then press OK.

c.Press▲or▼todisplayLocal Language, and then press OK.

(MFC model) Press Menu, 0, 0.

2. Press▲or▼toselectyourlanguage,andthenpressOK.

3. Press Stop/Exit.

• Windows

PC with a CD‑ROM drive, go to step 6A

• Windows

PC without a CD‑ROM drive, go to step 6B

• Macintosh, go to step 6B

• Mobile device users with a WPS/AOSS™‑supported access point/router, go to step 6C

Back Front

Select your country/language

(Initial setup only)

After turning on the machine, you may be required to set your

country or language (depending on your machine).

If required, follow the on‑screen instructions.

Remove the orange part. Remove the orange part.

Adjust the paper guides.

Secure Network Access

Your machine’s default password is on the label on the back of the machine (preceded by

“Pwd”).

We strongly recommend you change it to protect your machine from unauthorised

access.

Quick Setup Guide

DCP‑L2500D / DCP‑L2520D / DCP‑L2520DW / DCP‑L2540DN /

DCP‑L2540DW / DCP‑L2541DW / MFC‑L2700D / MFC‑L2700DN /

MFC‑L2700DW / MFC‑L2701D / MFC‑L2701DW / MFC‑L2703DW

Not all models are available in all countries.

The latest manuals are available at the Brother

Solutions Center: solutions.brother.com/manuals.

Watch our FAQ Videos for help with setting up your

Brother machine: solutions.brother.com/videos.

D01JBT001‑01

Version D

Configuration using the CD‑ROM (Windows

)

Follow the on‑screen instructions

to continue installation until either

the Connect the machine or the

Connection Type screen appears.

Finish

Download the full driver and software package from the Brother Solutions Center.

(For Windows

) solutions.brother.com/windows

(For Macintosh) solutions.brother.com/mac

After you download the driver and software package, follow the on‑screen instructions until the Connection Type screen appears. Refer to 6A Configuration using the CD-ROM

(Windows

If your wireless LAN access point/router supports automatic wireless (one‑push) setup (WPS/AOSS™), you can set up your machine without using a computer.

Connection Type

Print and scan using your mobile device

For USB Connection

For Wired Network Connection

Connect a network cable first.

For Wireless Network Connection

We recommend preparing a USB cable

to use temporarily during the wireless

setup.

Follow the on‑screen

instructions to continue

installation.

NOTE:

If connection is unsuccessful, repeat this step.

One‑push wireless setup for mobile devices (Wireless models only)

Wireless Network Connection

[Recommended]

Select this option if you have a USB cable to

use temporarily for wireless setup.

Select this option if you do not have a USB cable.

Follow the on‑screen

instructions to continue

installation.

NOTE:

If connection is unsuccessful, repeat this step.

Configuration without using the CD‑ROM (Windows

without CD‑ROM drive or Macintosh)

Finish

Press the WPS or AOSS™ button on your

wireless LAN access point/router.

Press the WiFi button on your machine.

Download “Brother iPrint&Scan” to start using your machine with mobile devices.

solutions.brother.com/ips

Wireless setup is now complete.

NOTE:

Before you can use your machine with your mobile device, download

“Brother iPrint&Scan.”

NOTE:

If the Brother screen does not appear

automatically, go to Computer (My Computer).

(For Windows

8: click the (File Explorer)

icon on the taskbar, and then go to Computer.)

Double‑click the CD‑ROM icon, and then

double‑click start.exe.

Finish

 Connect the machine: Follow

the on‑screen instructions to

continue installation.

 Connection Type:

Produktspecifikationer

Varumärke:	Brother
Kategori:	Skrivare
Modell:	MFC-L2700DN
Vikt:	11400 g
Bredd:	409 mm
Djup:	398.5 mm
Höjd:	316.5 mm
Förpackningens bredd:	567 mm
Maximal upplösning:	2400 x 600 DPI
Internminne:	32 MB
Kabelteknik:	10/100Base-T(X)
Antal bläckpatroner:	1
Standardgränssnitt:	Ethernet, USB 2.0
Maximal kopieringsupplösning:	600 x 600 DPI
Modemhastighet:	33.6 Kbit/s
Fax:	Svartvit faxning
Mobil utskriftsteknik:	Apple AirPrint, Google Cloud Print
Pappersfackets mediavikt:	60 - 105 g/m ^
Serveroperativsystem som stöds:	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Automatisk dokumentmatare (ADF):	Ja
Ljudtrycksnivå (tyst läge):	45 dB
Produktens färg:	Grå
Låddjup:	517 mm
Vikt inkl. förpackning:	14400 g
Mac-operativsystem som stöds:	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Utskrift:	Svartvit utskrift
Dubbelsidig utskrift:	Ja
Kopiering:	Svartvit kopiering
Datahastighet för Ethernet-LAN:	10, 100 Mbit/s
Hållbarhetscertifiering:	Blue Angel, ENERGY STAR
Kryptering/säkerhet:	SMTP-AUTH, SNMP
Textrader:	2 linjer
Nätverksansluten (Ethernet):	Ja
Skanningstyp:	Flatbädds- och ADF-scanner
Visa antalet tecken:	16
Antal USB 2.0 anslutningar:	1
USB-port:	Ja
Linux operativsystem som stöds:	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3, SuSE Linux 11, SuSE Linux 11.1, SuSE Linux 11.2, SuSE Linux 12.0
Positionering på marknaden:	Hem och kontor
Utskriftsteknologi:	laser
Utskriftshastighet (Svart, normalkvalitet, A4/US Brev):	24 ppm
Dubbelsidigt utskriftsläge:	Automatisk
Driftcykel per månad:	- sidor per månad
Total inmatningskapacitet:	250 ark
Total utmatningskapacitet:	100 ark
Högsta ISO A-seriestorlek:	A4
ISO A-serie storlek (A0...A9):	A4, A5, A6
Anpassad mediebredd:	76.2 - 215.9 mm
Anpassad medielängd:	127 - 355.6 mm
Maximal skannerupplösning:	19200 x 19200 DPI
Optisk skanningsupplösning:	600 x 2400 DPI
Skanning:	Färgscanning
Ljudtrycksnivå (utskrivning):	49 dB
Skanningsteknik:	CIS
Rekommenderad arbetscykel:	250 - 2000 sidor per månad
Kapacitet för automatisk dokumentmatare:	35 ark
