Computerized Sewing Machine
Operation Manual
CPS5XV[Y
GETTING READY
SEWING BASICS
UTILITY STITCHES
APPENDIX
F3dash-BrotherE_sgml.book Page 1 Friday, September 5, 2003 5:46 PM
Cover A
Enclosed Accessories
After opening the box, check that the following accessories are enclosed. If any item is missing or
damaged, contact your retailer.
Accessories
The following items should also be enclosed in the box.
Note
(For U.S.A. only)
z Foot controller: Model N5V This foot controller can be
used on this machine model NX-600.
z Screw of the presser foot holder (Part code: XA4813-
051).
z Organized accessory tray (Part code: XC4489-051)
1. 2. 3. 4.
5.
6. 7.
8.
9.
10. 11. 12. 13. 14.
15.
16. 17. 18. 19.*
20.
21. 22. 23. 24. 25. 26. 27.
28.
29.
30.
31.
32.
33.
34.
35.
*75/11 2 needles
90/14 2 needles
90/14 2 needles: Ball point needle (gold colored)
No. Part Name
Part Code
No. Part Name
Part Code
U.S.A. Others U.S.A. Others
1 Buttonhole foot "A" XC2691-051 19 Needle set X58358-051
2 Overcasting foot "G" XC3098-051 20 Twin needle X59296-051
3 Monogramming foot "N" X53840-351 21 Cleaning brush X59476-051
4 Zipper foot "I" X59370-051 22 Eyelet punch 135793-001
5 Zigzag foot "J" (on machine) XC3021-051 23 Screwdriver (large) X55467-051
6 Blind stitch foot "R" X56409-051 24 Screwdriver (small) X55468-051
7 Button fitting foot "M" 130489-001 25 Spool cap (large) 130012-054
8 Walking foot SA140 F033N (XC2214-002) 26 Spool cap (medium)(2) X55260-153
9 Quilting foot SA129 F005N (XC1948-002) 27 Spool cap (small) 130013-154
10 Stitch guide foot "P" SA160 F035 (XA8839-002) 28 Extra spool pin XC4654-051
11 Adjustable zipper/piping foot SA161 F036N (XC1970-002) 29 Spool net XA5523-050
12 Non stick foot SA114 F007N (XC1949-002) 30 Foot controller XC1154-051
13 Open toe foot SA147 F027N (XC1964-002) 31 Grid sheet set SA527 GS4 (XC4549-051)
14 1/4 inch quilting foot SA125 F001N (XC1944-002) 32 Knee lifter XA6941-052
15 Side cutter SA177 F054 (XC3879-002) 33 Operation manual XC5427-051
16 Quilting guide SA132 F016N (XC2215-002) 34 Quick reference guide
XC4546-151,
XC5434-051
17 Seam ripper X54243-001 35 Hard case XC2360-152
18 Bobbin (4) SA156 SFB (XA5539-151)
F3dash-BrotherE_sgml.book Page A Friday, September 5, 2003 5:46 PM
Cover B
Names of Machine Parts and Their Functions
The names of the various parts of the sewing machine and their functions are described below. Before
using the sewing machine, carefully read these descriptions to learn the names of the machine parts.
Front view
a Thread guide plate
b Thread guide cover
Pass the thread around the thread guide plate when
threading the upper thread.
c Spool pin
Place the spool on the spool pin.
d Thread guide for bobbin winding
Pass the thread around this thread guide when winding
the bobbin thread.
e Upper cover
Open the upper cover to place the spool of thread on
the spool pin.
f Bobbin winder
Use the bobbin winder when winding the bobbin.
g Operation panel
Select a stitch from those that appear in the operation
panel. (page Cover E)
h Sewing speed controller
Use the sewing speed controller to adjust the sewing
speed.
i Knee lifter mounting slot
Plug the knee lifter into the knee lifter mounting slot.
j Operation buttons
Use the operation buttons to start the sewing machine
and automatically cut the thread. (page Cover D)
k Flat bed attachment with accessory compartment
Store presser feet and bobbins in the accessory
compartment of the flat bed attachment. When sewing
cylindrical pieces, remove the flat bed attachment.
l Thread cutter
Pass the threads through the thread cutter to cut them.
m Needle threader lever
Use the needle threader to thread the needle.
5
3
4
6
2
1
7
0
8
C
B
A
9
F3dash-BrotherE_sgml.book Page B Friday, September 5, 2003 5:46 PM
