SWEET 22
™
RIFLE SCOPE
Sweet 22™ Scopes are designed for specifi c bullet weight
compensation for .36gr., .38gr., and .40gr. ammunition.
The Sweet 22™ Rifl e Scopes are designed for the serious hunter. The main
features of the Sweet 22™ are their ability to compensate for bullet trajectory
by specifi c grain weight. The elevation drum will compensate for .22cal grain
weights of 36, 38, and 40.
The Windage and Elevation turrets have zero reset with “Allen” screw. Each
model in the Sweet 22™ series have an adjustable side parallax setting of 7.5
to . (With the exception of the model S22-618x40SP which is 10 to )∞ ∞
Models available in the sweet series:
S22-27x32SP, S22-39x40SP, and S22-618x40SP.
Each Sweet 22™ model scope includes:
Hex Wrench, 3” Sun Shade and Micro Fiber Lens Cloth.
CONTENTS:
1. FOCUSING YOUR SCOPE
2. MOUNTING
3. PRE-ZEROING
4. ZEROING
5. BULLET COMPENSATION
6. PARALLAX CORRECTION
7. MAINTENANCE
---------------------------------
CAUTION: DIRECT VIEWING OF THE SUN CAN CAUSE PERMANENT
EYE DAMAGE. DO NOT ATTEMPT TO VIEW THE SUN WITH EITHER THIS
PRODUCT OR THE NAKED EYE.
1.) FOCUSING YOUR SCOPE
Sweet 22™ scopes are “fast focus” and the standard eye relief on the Sweet
22™ is 4”. The zoom ring has an inner drum with markings, and a fi xed inner
ring with a window cutout. Only the outer ring and markings will turn when
adjusted. The window is always facing the shooter.
2
KEY:
A.) Ocular Bell
B.) Zoom Ring Window
C.) Zoom Ring
D.) Fast Focus
E.) Elevation Adjustment
F.1) Windage Adjustment
F.2) Side Parallax
G.) Objective Bell
H.) Objextive End Ring
A
B
F.2
F.1
E
C
H
G
D
Hold the scope and look through the eye piece at a fl at, featureless well lit
area. The reticle should appear sharp and well defi ned. To make adjustments
rotate the ocular bell focus in either direction. Look through the scope again.
If the focus of the reticle has improved but is not perfect, continue to rotate in
the same direction. If the condition has worsened you will need to rotate the
bell in the opposite direction.
CAUTION: BE SURE THAT THE FIREARM IS NOT LOADED.
PRACTICE SAFE FIREARM HANDLING AT ALL TIMES.
2.) MOUNTING
The Sweet 22™ scopes have a one-inch tube diameter. Depending on your
rifl e you will need to purchase the correct base diameter to insure fi tment of
mount and rail. Using a rest or gun vise is highly recommended. (One piece or
two piece mounting rings can be used.)
• Separate the upper and lower halves of your ring(s).
• Install the lower half of your ring(s) on the rifl e rail.
• Set the scope in the cradle.
• Replace the tops loosely (do not tighten).
Position the scope as far forward as possible and rotate the elevation turret
to be vertical. Slowly pull the scope backward until your full FOV (fi eld of
view) is visible, check to make sure the reticle is aligned both vertically and
horizontally with the bore axes of the fi rearm.
Once properly positioned, tighten the top halves of your ring(s) mount using a
non-permanent thread lock.
CAUTION: BE SURE THAT THE FIREARM IS NOT LOADED.
PRACTICE SAFE FIREARM HANDLING AT ALL TIMES.
3.) PRE-ZEROING
Locate an appropriate location to fi re your rifl e and set up a target at
a distance of 100 yards from your shooting location. You should use a
comfortable gun rest to eliminate as much human error as possible. Make
certain the rifl e is empty with no cartridge in the chamber and the breech
open. Rotate the parallax ring to 100 yards.
3
