Sida 1/7
127
SoundwebTM
SoundwebSoundweb
SoundwebSoundweb
Soundweb
TMTM
TMTM
TM
9088 9088
9088 9088
9088
Installation Guide
128
SoundwebTM
Regulatory Information
An example of this equipment has been tested and found to comply with the following European
and international Standards for Electromagnetic Compatibility and Electrical Safety:
Radiated Emissions (EU): EN55013 (1990) Associated
Equipment
Immunity (EU): EN50082/1 (1992) RF Immunity, Fast
Transients ESD
Mains Disturbance (EU): EN61000/3/2 (1995)
Electrical Safety (EU): EN60065 (1993)
Radiated Emissions (USA): FCC part 15 Class B
Electrical safety (USA): UL813
Mechanical Installation
v1.2 JK 4th June 1998
Important user information
Do not remove covers. No user serviceable parts inside, refer servicing to qualified service
personnel. For continued compliance with international EMC regulations, it is important that all
cables be screened, and connected as follows: Audio cable screens to their 9088 connector
ground. Control cable screens to the ground screws adjacent to the connector. Network cables
should be of type CAT.5, fitted with a clip-on ferrite sleeve (STEWART TYPE 28A2029-0A0) near
the network socket end. This equipment must be earthed. It should not be necessary to remove any
protective earth or signal cable shield connections to prevent ground loops. Any such
disconnections are outside the recommended practice of BSS Audio, and will render the EMC or
safety certificate void.
If the unit is likely to undergo extreme vibration through extensive road trucking and touring, the
unit must be supported at the rear and/or sides to lessen the stress on the front mounting flange.
The necessary support can generally be bought ready-built as a rack tray, or the 9088 unit can be
mounted between other units. Damage caused by insufficient support is not covered by the
warranty. To prevent cosmetic damage to the front panel finish, use protective plastic cups under
the rack mounting bolts.
129
SoundwebTM
Front panel LED functions
Input monitoringInput monitoring
Input monitoringInput monitoring
Input monitoring
Each channel has 3 LED indicators showing:
ClipClip
ClipClip
Clip
Illuminated - Excessive signal level, close to clip.
SignalSignal
SignalSignal
Signal
Illuminated - A signal is present on this channel input.
PhantomPhantom
PhantomPhantom
Phantom
Illuminated - Phantom power is active for this mic channel.
ALL flashing - Unit selected in Soundweb designer/Network view.
DSP ClipDSP Clip
DSP ClipDSP Clip
DSP Clip
Illuminated - Indicates that the signal is clipping internally.
NetworkNetwork
NetworkNetwork
Network
MasterMaster
MasterMaster
Master
Flashing - The network is initialising. If it continues to flash for more than a few seconds,
there is a cabling faul
t - either a double ring error or a problem with one of the cable
connectors.
Steady - This unit has become the clock master for the network.
Off - This unit is to the master'sclienting clock.
Sync
Sync
Sync
Sync
Sync
Steady - This indicates the presence of one or more valid network connections.
Flashing - There is a problem with the incoming network signal - possibly the maximum
cable length has been exceeded.
Activity
Activity
Activity
Activity
Activity
Flashing - This LED indicates data transfe . The flashing is not regula , but dependant onr r
the rate of transfe .r
Power
Power
Power
Power
Power
Steady - This indicates that the power supply is functioning.
