Sida 1/125

Network Attached Storage

TeraStation

User Manual

Please make sure to read this manual before using and follow the procedures. If you have any inquiries about

the product, contact the number on the warranty statement or the packing box. Do not discard this manual, the

warranty statement, or the packing box.

www.buffaloamericas.com

35021815-02

February 2021

Notice

Regulatory Compliance Information

For Customers in the United States

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

Warning Symbols and Graphical Icons on the Product

Warning symbols are used on the product for safety operation and prevention of injury to you and damage to the

unit. The following explains the meanings of symbols used on the product.

This symbol indicates important warnings or cautions for operation and maintenance.

Additional information will follow this symbol.

This symbol indicates the presence of an alternating current.

This symbol indicates that the rack-mounted equipment should not be used for a shelf or a work

space.

This symbol indicates that the equipment may carry risk of electric shock.

This symbol indicates danger of hazardous high voltage.

This symbol indicates a protective earthing terminal.

This symbol indicates that the protective conductor should be connected first to the protective

earthing terminal.

Safety Precautions

Before using your device, basic safety instructions should always be followed.

(1) Read these instructions.

(2) Keep these instructions.

(3) Heed all warnings and follow all instructions.

(4) The socket-outlet shall be installed near the equipment and shall be easily accessible.

Notice

Produktspecifikationer

Varumärke:	Buffalo
Kategori:	Server
Modell:	TeraStation WS5220DN
Processorfrekvens:	1.5 GHz
Processorfamilj:	Intel Atom®
Wi-Fi:	Nej
Strömförbrukning (max):	100 W
Internminne:	8 GB
Modell:	SAN
Processor:	C3338
Processorns driftlägen:	64-bit
Processorns cache:	4 MB
Intel® Hyper Threading Technology (Intel® HT Technology):	Nej
Intel® AES nya instruktioner (Intel® AES-NI):	Ja
Intel® Secure Key:	Ja
Intel® OS Guard:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Processorkod:	SR36E
Lagringsenheter installerade:	Ja
Total installerad lagringskapacitet:	4 TB
Minnestyper som stöds av processorn:	DDR3L, DDR4-SDRAM
Tcase:	89 ° C
Serveroperativsystem som stöds:	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
RAID-stöd:	Ja
Enhetsklass:	Små och Medelstora Företag
Antal lagringsenheter som stöds:	2
Typer av lagringsenheter som stöds:	HDD
Produktens färg:	Svart
processortillverkare:	Intel
Windows-operativsystem som stöds:	Windows 10, Windows 7, Windows 8
Mac-operativsystem som stöds:	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Installerat operativsystem:	Windows Storage Server 2016
Datahastighet för Ethernet-LAN:	10,100,1000,10000 Mbit/s
Antal LAN (RJ-45) anslutningar:	3
processorsockel:	BGA 1310
Processorns kodnamn:	Denverton
Minneskanaler som stöds av processorn:	Single
Typ av internminne:	DDR4
Nätverksansluten (Ethernet):	Ja
Typ av installerad lagringsenhet:	HDD
På / av-knapp:	Ja
USB-port:	Ja
RAID-nivåer:	0, 1,JBOD
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	3
Processorkärnor:	2
Processorboostfrekvens:	2.2 GHz
Antal fläktar:	1 fläkt/-ar
Mac-kompatibel:	Ja
Systembuss, hastighet:	- GT/s
Processortrådar:	2
Processorlitografi:	14 nm
Stegning:	B0
Processor med ECC-stöd:	Ja
Värmeavledningseffekt (TDP):	9 W
Högsta antal PCI Express-platser:	10
PCI Express-kortplatser version:	3.0
PCI Express konfigurationer:	1x2, 1x4, 1x8
T-junction:	100 ° C
Intel® Turbo Boost Technology:	2.0
Intel® VT-x med utökad Sida Tabeller (EPT):	Ja
Execute Disable Bit-säkerhet:	Ja
Processorns förpackningsstorlek:	34 x 28 mm
CPU konfiguration (max):	1
Inbäddade alternativ:	Ja
Intel Secure Key Technology-version:	1.00
Intel Virtualization Technology (VT-x):	Ja
Etisk processor (Conflict Free):	Ja
ARK-ID för processor:	97928
Högsta internminne som stöds av processorn:	64 GB
Antal installerade lagringsenheter:	2
Kylning typ:	Aktiv
Lagringsenhetsgränssnitt som stöds:	Serial ATA II, Serial ATA III
Lagringsenhetens kapacitet:	2000 GB
Hårddiskplatser med hotswap-funktion:	Ja
Chassityp:	Skrivbord
Strömförsörjning plats:	Inbyggd
Lagringsenhetens storlek:	3.5 "
Säkerhetskopieringsfunktion:	Ja
Typer av säkerhetskopiering:	Cloud
Network Time Protocol (NTP)-klient:	Ja
Intel® QuickAssist Technology:	Nej
Intel Secure Boot:	Ja
Intel Secure Boot Technology-version:	1.00
Datahastighet för Ethernet LAN som stöds (max):	10000 Mbit/s
