RIFLESCOPE OWNER’S GUIDE
3-9x40
Rimfire
4-12x40
Rimfire
YOU’VE MADE THE RIGHT DECISION BY CHOOSING THE BUSHNELL R3 RIFLESCOPE!
TABLE OF CONTENTS
KEY ELEMENTS OF A RIFLESCOPE 3
MOUNTING YOUR RIFLESCOPE 4
PRELIMINARY SCOPE ADJUSTMENTS - SETTING THE DIOPTER 4
ATTACHING A MOUNT, RINGS AND SCOPE TO YOUR RIFLE 4
PARALLAX 5
PRELIMINARY SIGHTING-IN 5
FINAL SIGHTING-IN 5
RESETTING THE TURRET KNOBS 5
DROP ZONE 22 RETICLE 6
TECHNICAL SPECIFICATIONS 6
STORAGE 6
CARING FOR YOUR RIFLESCOPE 6
GLOSSARY OF COMMON RIFLESCOPE TERMS 7
WARRANTY 8
MAINTENANCE 8
LANGUAGE
FRANÇAIS 9
ESPAÑOL 14
DEUTSCH 19
ITALIANO 24
Click on each topic in the Table of Contents to go directly to it.
Bushnell® is constantly at the forefront of quality and value, and R3 Series riflescopes are no exception. Bushnell R3
riflescopes are built with premium technology. Multi-coated lenses and dry nitrogen purged IPX7 construction offer
crisp, bright images in any environment.
All exterior lens surfaces have our EXO Barrier™ coating (in addition to multi-coating). EXO Barrier,
quite simply, is the best protective lens coating technology Bushnell has ever developed. Added at
the end of the coating process, EXO Barrier molecularly bonds to the lens and fills the microscopic
pores in the glass. The result is an ultra-slick coating that repels water, oil, fog, dust and debris -
rain, snow, fingerprints and dirt will not stick. EXO Barrier is built to last: the bonded coating will not
fade with the passage of time or normal wear and tear.
Scan the code to download the free Bushnell Ballistics App. The Bushnell Ballistics App is a full-
featured ballistics solver to use with your Bushnell rangefinders and riflescopes to calculate firing
solutions. It allows you to use current atmospherics to calculate the holds and display the ranges
at each subtension on your reticle. Many more features to enhance your shooting experience.
3
Click to return to the Table of Contents.
WARNING: NEVER LOOK AT THE SUN THROUGH THE RIFLESCOPE (OR ANY OTHER OPTICAL INSTRUMENT). IT
MAY PERMANENTLY DAMAGE YOUR EYES.
KEY ELEMENTS OF A RIFLESCOPE
1. Objective Lens: This lens has three functions. First, it permits light to pass into the scope. Second, it determines resolution.
Generally, larger lenses allow more light to enter the scope and resolve details better than smaller ones. Finally, it forms an
image for the other lenses to magnify to a usable size. The image formed by this lens is upside down.
2. Erector System: The erector system serves several functions. Its primary function is to erect the image (that is, flips the
image right-side up) and align it to the reticle. During this process, primary magnification of the image takes place. These two
functions are the result of lens action.
3. Windage & Elevation Controls: The erector lenses are housed in a tube that is fixed at one end, while the other end of the tube
is free to move and respond to adjustments. By moving the erector system, the point-of-aim of the scope is adjusted to match
the point-of-impact of the bullet.
4. Reticle: In simple terms, the aiming device around which the scope is built. This element replaces the iron sight system of non-
scoped rifles.
5. Ocular or Eye Lens: This element provides the secondary and final magnification of the image.
PARTS GUIDE
Diopter - Reticle Focus
Windage Adjustment
Magnification Ring
Elevation Adjustment
Objective Lens
*Model 3-9x40 shown below
Accessories Included:
› Lens Covers
› Cleaning Cloth
