BZ-MVS4X4-4K
18Gbps 4x4 Seamless UHD Matrix
Contact
1.888.499.9906 | support@bzbgear.com | bzbgear.com
Thank you for purchasing this product
Surge protection device recommended
Table of Contents
For optimum performance and safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future reference.
This product contains sensitive electrical components that may be damaged by electrical
spikes, surges, electric se of surge shock, lighting strikes, etc. U protection systems is highly
recommended in order to protect and extend the life of your equipment.
1. Introduction.....................................................................................................................
2. Features...........................................................................................................................
3. Package Contents............................................................ ............................................
4. Specifications.................................................................. ..............................................
5. Operation Controls and Functions............................. .................................................
6. RS232/LAN Control Connection................................. ............................................. .....
6.1 RS232 Connector Connection............................................. ...................................
6.2 Network Control Connection.......................... ....................... ........................... .......
7. PC Tool User Guide............................................................ ....... .............................. ......
7.1 Account’s Authentication................................................................ ......................
7.2 Connect with PC Tool........................... ....................... ..................... .............. ....... ..
7.3 Matrix Switch Page................................................................ .................................
7.4 Advanced Switch Page........................... ....................... ................................. .......
7.5 Signal Setting Page............................................................. ...................................
7.6 FineTune Page........................... ....................... ................................................ .......
7.7 Video Wall Page............................................................... ......................................
7.7.1 Video Wall Context Menu............................................. ...............................
7.7.2 Layout Save/Load.......................... ....................... .................................. .......
7.8 CEC Control Page........................... ....................... .......................................... .......
8. Control via Web.................................................. ....... ............................................. .....
1
1
1
2
3
6
6
6
6
6
6
7
8
9
9
9
11
12
13
14
9. Tech Support........................ .............................. ......... .................. .......... ................ ... ....15
10.Warranty ............................ ............................... ......... .............................. ................ ... ....
15
11.
.................. ............................... ......... ...........................Mission Stat nteme .... ........... ...... 15
1. Introduction
The 18Gbps 4x4 seamless UHD Matrix can connect 4 HDMI sources to 4 HDMI displays.
Supported video resolution is up to 4K60 4:4:4. The product supports IR matrix and Audio
matrix. IR matrix routing follows the video routing. Audio extract and insert are supported.
The product supports CEC management and strong video wall processing.
☆HDMI 2.0 and HDCP 2.2 compliant
☆Support 18 Gbps video bandwidth
☆Support video resolution up to 4K60 4:4:4
☆Color space: RGB, YCbCr 4:4:4, YCbCr 4:2:2
☆Support seamless switching, video wall function
☆Support CEC management
☆Support audio matrix and IR matrix function
☆Support external L/R audio insert on HDMI stream
☆Support EDID management
☆Support front panel, RS232, TCP/IP (LAN 10M/100M) control
2. Features
3. Package Contents
①1 x 4x4 seamless UHD Matrix
②1 x AC Power Cord
③1 x Matrix IR Remote
④4 x IR Receiver cable (1.5 meters)
⑤4 x IR Blaster cable (1.5 meters)
⑥1 x 3-pin Phoenix Connector
⑦ CAT6 cable1×
⑧1× USB to RS232 Cable
⑨1× User Manual
- 1 / 1 -5
