Cadel Mithos Plus 12 Ps Bruksanvisning

Cadel värmare Mithos Plus 12 Ps

Läs gratis den bruksanvisning för Cadel Mithos Plus 12 Ps (44 sidor) i kategorin värmare. Guiden har ansetts hjälpsam av 4 personer och har ett genomsnittsbetyg på 4.9 stjärnor baserat på 2.5 recensioner. Har du en fråga om Cadel Mithos Plus 12 Ps eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/44

INSTALLER MANUAL

Pellet Stove

ATENA

PLUS 12/14 - DUKE 12/14 AIRTIGHT- SABA 12/14

MITHOS

PLUS 12/14 - MITHOS PLUS 12/14 PS

New

ATENA - DUKE - SABA - MITHOS

SUMMARY

1 MANUAL SIMBOLOGY ....................................3

2 PACKAGING AND HANDLING ..........................3

2.1 PACKAGING .............................................................3

2.2 REMOVING THE STOVE FROM THE PALLET ..............3

2.3 STOVE HANDLING....................................................4

3 CHIMNEY FLUE .............................................4

3.1 PREPARING THE SMOKE EXPULSION SYSTEM .........4

3.2 CHIMNEY COMPONENTS .........................................4

3.3 SMOKE DUCT (SMOKE FITTING) ..............................5

3.4 FLUE (CHIMNEY OR PIPED DUCT) ...........................5

3.5 CHIMNEY POT ..........................................................6

3.6 MAINTENANCE ........................................................7

4 COMBUSTION AIR .........................................7

4.1 AIR INLET ................................................................7

4.2 COMBUSTIBLE AIR INLET FOR SEALED-CHAMBER

INSTALLATION ...................................................................8

5 EXAMPLES OF INSTALLATION (DIAMETERS AND

LENGTHS TO BE SIZED) ........................................9

6 INSTALLATION ............................................10

6.1 INTRODUCTION .....................................................10

6.2 MINIMUM DISTANCES ........................................... 11

6.3 OVERALL DIMENSIONS .........................................12

6.4 STOVE DOOR REMOVAL/INSTALLATION ................15

6.5 REMOVAL OF CAST IRON COVER AND CAPS (ATENA

PLUS 12/14 - DUKE 12/14 AIRTIGHT) ..............................15

6.6 REMOVAL/ASSEMBLY OF SIDE PANELS (DUKE 12/14

AIRTIGHT - SABA 12/14) .................................................. 16

6.7 REMOVAL/ASSEMBLY OF BACK PANELS (ATENA

PLUS

12/14) ..............................................................................17

6.8 REMOVAL/ASSEMBLY OF TILE PROFILES (ATENA

PLUS 12/14) .....................................................................17

6.9 REMOVAL/ASSEMBLY OF METAL PROFILES (ATENA

PLUS 12/14) .....................................................................18

6.10 TILES ASSEMBLY (ATENA

PLUS 12/14).................18

6.11 METAL FRAME ASSEMBLY (MITHOS

PLUS 12/14) 19

6.12 MOUNTING SERPENTINE STONE FRAME (MITHOS) 20

6.13 REMOVAL OF SIDE PANELS (MITHOS3 PLUS 12/14) 23

6.15 REAR OR UPPER FUME EXHAUST (ATENA PLUS 12/14

- DUKE 12/14 AIRTIGHT - SABA 12/14) ...........................23

6.16 CONCENTRIC PIPE-KIT ASSEMBLY (ATENA PLUS

12/14 - DUKE 12/14 AIRTIGHT - SABA 12/14) .................24

6.17 HOT AIR DUCTING SYSTEM (ATENA

PLUS 12/14 -

DUKE 12/14 AIRTIGHT - SABA 12/14) .............................. 25

6.18 HOT AIR DUCTING (MITHOS3 PLUS 12/14) ...........27

6.19 USING THE STOVE WITHOUT DUCTING (ATENA

PLUS

12/14 - DUKE 12/14 AIRTIGHT - SABA 12/14) .................30

6.20 ELECTRIC CONNECTION .........................................31

6.21 STOVE CALIBRATION AND DEPRESSION

MEASUREMENT ...............................................................31

6.22 CONNECTION TO THE EXTERNAL THERMOSTAT .....32

7 SPECIAL MAINTENANCE ..............................33

7.1 INTRODUCTION .....................................................33

7.2 FUME CHAMBER CLEANING ..................................33

7.3 FUME CONDUIT CLEANING .................................... 34

7.4 FUME PASSAGE CLEANING .................................... 34

7.5 FUME FAN CLEANING ............................................35

7.6 ROOM FAN CLEANING ...........................................36

8 IN CASE OF ANOMALY ..................................36

8.1 PROBLEM SOLVING ...............................................36

9 TECHNICAL DATAS ......................................39

9.1 REPAIR INFORMATION ..........................................39

10 FEATURES ..................................................40

Produktspecifikationer

Varumärke:	Cadel
Kategori:	värmare
Modell:	Mithos Plus 12 Ps
Bredd:	950 mm
Djup:	440 mm
Höjd:	1185 mm
Förpackningens bredd:	790 mm
Termostat:	Ja
Strömförbrukning (max):	151 W
Fjärrstyrd:	Ja
Programmeringsfunktion:	Ja
Pelletsförbrukning (min):	0.86 kg/h
Pelletsförbrukning (max):	3 kg/h
Rökgastemperatur:	185 ° C
Extern termostat:	Ja
Strömförbrukning (tändning):	360 W
Värmetillförsel (nominell):	12 kW
Värmetillförsel (reducerad):	3.8 kW
Produktens färg:	Black, Grey
Effekt:	- W
Låddjup:	1022 mm
AC-inspänning:	230 V
Material, hölje:	Cast iron, Steel, Stone
Apparatens placering:	Fristående
Växelström Frekvens:	50 hz
Antal spänningsnivåer:	3
Strömkälla:	AC
Lämplig för rumarea upp till:	127 m²
Exhaust plats:	Bak
Passar för rumsvolym upp till:	342 m³
Bräsnletyp:	Pellets
Inkluderad ugn:	Nej
Hob ingår:	Nej
Trattens kapacitet:	23 kg
Effektivitet (nominell):	90 %
Effektivitet (reducerad):	93.5 %
Rökgasdrag (max):	10 Pa
Kolmonoxidnivå (CO), nominell:	0.0142 %
Kolmonoxidnivå (CO), begränsad:	0.0149 %
Genomsnittligt damminnehåll:	19 mg/Nm³
Autonomiavstånd:	8 - 27 h
Pelletsdiameter som stöds (max):	6 mm
