INSTALLER MANUAL
Pellet Stove
EN ©2024 CADEL srl | All rights reserved - Tutti i diritti riservati
ZEFIRO - ZEN - PONENTE - ZENITH
ZEFIRO - ZEN - PONENTE - ZENITH
2
SUMMARY
1 MANUAL SIMBOLOGY ....................................3
2 PACKAGING AND HANDLING ..........................3
2.1 PACKAGING .............................................................3
2.2 REMOVING THE STOVE FROM THE PALLET ..............3
2.3 STOVE HANDLING....................................................4
3 CHIMNEY FLUE .............................................4
3.1 PREPARING THE SMOKE EXPULSION SYSTEM .........4
3.2 CHIMNEY COMPONENTS .........................................4
3.3 SMOKE DUCT (SMOKE FITTING) ..............................5
3.4 FLUE (CHIMNEY OR PIPED DUCT) ...........................5
3.5 CHIMNEY POT ..........................................................6
3.6 MAINTENANCE ........................................................7
4 COMBUSTION AIR .........................................7
4.1 AIR INLET ................................................................7
4.2 COMBUSTIBLE AIR INLET FOR SEALED-CHAMBER
INSTALLATION ...................................................................8
5 EXAMPLES OF INSTALLATION (DIAMETERS AND
LENGTHS TO BE SIZED) ........................................9
6 INSTALLATION ............................................10
6.1 INTRODUCTION .....................................................10
6.2 MINIMUM DISTANCES ...........................................11
6.3 INSULATING MATERIAL .........................................12
6.4 OVERALL DIMENSIONS .........................................13
6.5 INSERT EXTRACTION .............................................17
6.6 INSERT REMOVAL ..................................................17
6.7 INSTALLATION WITH EXTERNAL COVER ................18
6.8 INSTALLATION ON EXISTING FIREPLACE ...............20
6.9 DOOR ADJUSTMENT (ZEN - ZEFIRO) ....................22
6.10 DOOR ADJUSTMENT (PONENTE - ZENITH) ............22
6.11 CONNECTION TO THE EXTERNAL THERMOSTAT .....22
6.12 ELECTRIC CONNECTION .........................................23
6.13 AIR REGULATOR ....................................................23
6.14 INSERT LEGS INSTALLATION (OPTIONAL) .............24
6.15 HOT AIR DUCTING (OPTIONAL ONLY FOR ZEFIRO) 25
6.16 PELLET DRAWER INSTALLATION (OPTIONAL) .......27
6.17 TRAPDOOR INSTALLATION (OPTIONAL) ................29
6.18 FRAME INSTALLATION (OPTIONAL) ......................31
6.19 CONCENTRIC PIPE INSTALLATION .........................32
6.20 DISPLAY ROTATION ...............................................32
7 WI-FI KIT INSTALLATION .............................33
8 SPECIAL MAINTENANCE ..............................34
8.1 INTRODUCTION .....................................................34
8.2 FEED SCREW MAINTENANCE.................................34
8.3 ROOM FAN CLEANING ...........................................35
8.4 FLUE GAS EXTRACTOR CLEANING..........................36
8.5 FUME PASSAGES CLEANING ..................................36
8.6 FUME CHAMBER CLEANING ..................................37
8.7 SMOKE DUCT CLEANING .......................................38
8.8 GLASS REPLACEMENT ...........................................39
9 IN CASE OF ANOMALY ..................................39
9.1 PROBLEM SOLVING ...............................................39
10 TECHNICAL DATAS ......................................41
10.1 FUSE REPLACEMENT .............................................41
11 FEATURES ..................................................42
ZEFIRO - ZEN - PONENTE - ZENITH
3
1 MANUAL SIMBOLOGY
USER
AUTHORISED TECHNICIAN
(ONLY to interpret or the Stove-manufacturer or the Authorized Technician of
Technical Assistance Service approved by the Stove-manufacturer)
SPECIALIZED STOVE-REPAIRER
CAUTION:
READ CAREFULLY THE NOTE
CAUTION:
DANGER OR IRREVERSIBLE DAMAGE POSSIBILITY
• The icons with the stylized figures indicates whom the subject dealt in the paragraph is addressed to (between the User and/
or the Authorized Technician and/or the Specialized Stove-repairer).
• WARNING symbols indicates an important note.
2 PACKAGING AND HANDLING
2.1 PACKAGING
• The packaging is made up of recyclable cardboard boxes according to RESY standards, recyclable expanded polystyrene inserts
and wooden pallets.
• All packaging materials can be re-used for a similar use or eventually discharged as waste assimilable to the municipal solid
ones, in accordance with current regulations.
• After having removed the packaging please assure you about the integrity of the product.
2.2 REMOVING THE STOVE FROM THE PALLET
Proceed as follows to remove the stove from the pallet:
Fig. 1 - Screw removal
• Slightly pull out the machine body from the structure (see INSERT EXTRACTION a pag. 17)
• Remove the screws fixed to the base of the insert (see ) and then remove it from the pallet.Fig. 1
