HPA 603BT & HPA 604BT
Manual
GB • F • D • I • E • P • SW • PL • GR • CZ/SK • NL
SPECIFICATIONS, REMOTE CONTROL
Bluetooth
®
version: 2.1
supportsA2DP&AVRCPprole
Bluetooth
®
range: up to 10 meters (without barrier)
Transmission: Bluetooth
®
: Freq range: 2402-2480 Mhz / Max e.r.p: <100mW/20dBm
Wireless mic.: Freq range: 863 MHz / Max e.r.p: <10mW/10dBm
Speakers HPA603BT: 1x subwoofer (12” / 30cm)
1x tweeter (1” / 2,5cm)
Speakers HPA604BT: 1x subwoofer (15” / 38cm)
1x tweeter (1” / 2,5cm)
Max. speaker power: 150W (HPA603BT)
210W (HPA604BT)
RMS Power: 60W (HPA603BT)
85W (HPA604BT)
Built-in connections: - USB
(max. size 32GB)
- SD (max. size 32GB)
- RCA connection (AUX-in & AUX-out)
- 2x Microphone-in 6.3mm jack connection
- UHF MIC “ready” (for wireless mic model: HPA-WMIC1)
FM frequency range: 87.5 - 108Mhz
Power supply: -
HPA603BT Built-in rechargeable battery 12V / 5A (up to 3,5 hours playtime)
- HPA604BT Built-in rechargeable battery 12V / 7A (up to 3,5 hours playtime)
110~240V ~ 50Hz / 60Hz (power and charger)
- DC Optional external 12V battery
Dimensions: 423(W) x 435(D) x 635(H) mm (HPA603BT)
485(W) x 400(D) x 745(H) mm (HPA604BT)
1. POWER BUTTON
only works the main power(25) is ON
2. MODE BUTTON
switch between audio sources
3. MUTE BUTTON
4. VOLUME INCREASE BUTTON
5. PREVIOUS BUTTON
6. VOLUME DECREASE BUTTON
7. RADIO STATION SCANNING BUTTON
Auto scan and store FM stations
8. DIGITS BUTTONS
9. EQ BUTTON
Normal, Rock, POP, Classic, Jazz, News
10. PLAY/PAUSE BUTTON
11. NEXT BUTTON
12. REPEAT BUTTON
(repeat one/random/repeat all)
Wireless microphone, sold separately
HPA-WMIC1 specially prepared for
caliber’s HPA series
(2x AA 1,5V batteries NOT incl.)
Wired microphone, sold separately
model: HPG-MIC1
1. SD CARD SLOT
supports up to 32 GB
2. PLAY / PAUSE BUTTON
Scan and store in FM mode
3. PREVIOUS BUTTON
4. DISPLAY
5. NEXT BUTTON
6. REPEAT BUTTON
repeat one, repeat all, random
7. MODE BUTTON
switch between audio sources
8. USB SLOT
supports up to 32 GB
9. MAIN VOLUME BUTTON
Adjust the main volume
10. TREBLE TONE CONTROL
Adjust high tones
11. BASS TONE CONTROL
Adjust low tones
12. MIC VOLUME
Adjust the volume of the MICROPHONE input
13. MIC TREBLE
Adjust the treble tone of the MIC inputs
14. MIC BASS
Adjust the bass tone of the MIC inputs
15. ECHO
Adjust the ECHO depth of the MIC input
16. MIC 1 INPUT
6,3mm jack input.
17. MIC 2 INPUT
6,3mm jack input.
18. CHARGING LED
19. POWER AND CLIP LED
When the power is ON the green LED is lit
When the clip LED lights up, overload occurs
20. AUX-IN
RCA Auxillary input
21. AUX-OUT
RCA Auxillary output
22. AC INPUT
AC 100 ~ 240V, 50 / 60Hz
23. DC 12V INPUT
External battery input.
This is NOT for external speakers!
24. MIC PRI
When active, the incoming MIC signal reduces all other audio signals.
25. POWER BUTTON
ON / OFF
VOLUME
TREBLE
BASS
MIC. VOL
MIC. TRE
MIC. BASS
ECHO
A U X
O U T
MIC 1
MIC 2
9
10
11
12
13
14
15
16
17
22
20
21
24
25
19
18
23
CONNECTIONS AND BUTTONS
