Sida 1/12

R E L

A S /P S

12 I N T 3 R P T 4 R D M

MODE

ME NU

1 85

17161514131211

10 2

MCD 275

English

Short press Long press Short press Long press Short press Long press

1 Mute Power

2 Eject

4 Audio menu Menu Ok

5 Mode

6 Rotary volume

8 AF Regional on/off

10 PTY

11 AS PS

12 M1 Memory 1 Pause/play

13 M2 Memory 2 Scan Folder scan

14 M3 Memory 3

15 M4 Memory 4

Random

folder

16 M5 Memory 5 folder down

17 M6 Memory 6 folder up

18 Display Info

19 Loud / enter Band

20 Seek up Tune up File/track up Fast forward

21 Seek down Tune down File/track down Fast backward

Note! Do not operate the unit while driving.

Power

Eject

Panel release

Power function to activate or deactivate the unit. To deactive press and hold the power button for 3 seconds

Tune up/down

Band

Push this button to confirm the option you have selected.

Repeat

Seek up/down

TUNER

CD/MP3/WMA

SYSTEM

Mute

Repeat Off

Repeat track

Repeat disc

Panel release button

3.5mm AUX in Jack

Band selection allows you to select different reception bands, f.i. FM1, FM2, FM3 and AM

Push this button to turn off the sound, push again to return to the last volume level.

Fast forward/backward

KEY

M1-M6

Rotary volume

PTY

Menu (system)

Info

Audio menu

SD card input

USB input

Use a non-metallic pointed object to press and hold the reset button for 5 seconds. The unit will be set to factory default.

To connect an external audio system

reset (behind panel)

These are the preset stations where you can store your favorite radio stations if in tuner mode

This button allows you in CD, USB or SD mode to play or to pause the music.

3,5mm AUX in Jack

Pause/Play

File/track down/up

Random

Scan

Mode

When inserting a USB stick the unit will switch to USB mode. (Max 1000 tracks)

View played track information

The Audio menu button gives you the possibility to adjust your sound system with the following options Bass, Treble, Balance and Fader.

These options can be used to fine tune your sound.

Hold button for 3 seconds to open the menu. Press repeatedly to view menu items.

In MP3 mode press this button to go up or down one folder.

The mode button allows you to go from one source (f.i. CD) to another source (f.i. Tuner) by pushing the button as many times as

AS stands for Autostore; in tuner mode it will automatically store the 6 strongest stations (M1-M6). Note: all previous stored stations are

This knob allows you to adjust the volume from minimum to maximum level. NOTE high sound levels may cause damage to your ears

PS stands for Preset stations this means that when you push this button in tuner mode it will automatically switches to the first preset

(M1) if you push again it will go to the next and so on.

Remove the frontpanel to insert SD card. When inserting a SD card the unit will switch to SD mode. (Max 2GB card, max 1000 tracks)

AF stands for Alternative frequencies; the tuner will return to alternative frequencies whenever the reception signal is getting worse

Long press to move the radio frequency number up/down step by step.

The PTY function allows you to search for stations with a particular program type like NEWS group and POP group both of these groups

are divided in different subjects. PTY "POP", pop/rock, easy/light, classics/others, jazz/country, nation/oldies. PTY "NEWS", news/info,

sport/educatie, culture/science, weather/finance, social/religion

Scan will play 10 seconds of each song on the CD, USB or SD. If the preferred song is playing, push again and it will play that song

Short press to move to the next station automatically

Long press to fast forward to the CD, USB or SD

Shuffle will play all the songs random. Available in CD, USB and SD mode

Repeat will play a selected song or album continuously. Available in CD, USB and SD mode

TA stands for Traffic announcement which means that it will give you information about the traffic (if broadcasted) no matter what mode

you are in (CD,USB, etc.) it will automatically interrupt the cd and give the information, after that it automatically switches back to the

l t d d

USB port

Description of the functions

Push this button to eject the CD out of the unit.

Push this button to release the frontpanel

Produktspecifikationer

Varumärke:	Caliber
Kategori:	bilradio
Modell:	MCD 275
Ljudsystem:	CD
LED-bakgrundsbelysning:	Ja
Uteffekt:	300 W
Impedans:	4 Ω
Displaybelysning:	Ja
Ljudutgångskanaler:	4.0 kanaler
Filtyp:	MP3, WMA
Typ av minneskort:	MMC, SD
Skärmtyp:	LCD
MP3-uppspelning:	Ja
Inbyggd kortläsare:	Ja
Equalizer:	Ja
Frekvensområde:	5 - 20000 hz
Klocka:	Ja
Signal/brusförhållande (SNR):	70 dB
Automatisk digital kanalsökning:	Ja
Uppspelning av CD-R:	Ja
Uppspelning av CD-RW:	Ja
FM band:	87.5 - 108 MHz
AM band:	522 - 1620 kHz
Equalizer tonkontroller:	4
iPod-förberedd:	Nej
Maximal styrka per kanal:	75 W
Belysningsfärg på knapparna:	Blå
Tona in/ut (fade):	Ja
ISO anslutning:	Ja
Installationsvinkel:	30 °
