Sida 1/28

Your music + our passion

551R V2

azur

ENGLISH

AV receiver

User's manual

The process of setting up the 551R V2 is rst to make all the connections

to your speakers and source equipment and then set the unit up via its

On-Screen Display (OSD) as there are various settings and adjustments that

need to be made before the 551R V2 can be used.

However before you actually decide which connections to make or perform

any adjustments it is strongly advised that you read through the '551R V2

setup' section of this manual rst, starting on page 12.

A lot of explanation is included that will help you to choose the right

connection types for both your sources and TV.

Before connecting

Contents

Make sure you register your purchase.

Visit: www.cambridge-audio.com/sts

By registering, you'll be the rst to know about:

Future product releases

Software upgrades

News, events and exclusive offers plus

competitions!

This guide is designed to make installing and using this product

as easy as possible. Information in this document has been

carefully checked for accuracy at the time of printing; however,

Cambridge Audio's policy is one of continuous improvement,

therefore design and specications are subject to change

without prior notice.

This document contains proprietary information protected by

reproduced by any mechanical, electronic or other means, in

any form, without prior written permission of the manufacturer.

All trademarks and registered trademarks are the property of

their respective owners.

Manufactured under license from Dolby Laboratories. "Dolby"

and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent #'s: 5,451,942;

5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535;

7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S.

and worldwide patents issued & pending. DTS is a registered

trademark and the DTS logos, Symbol, DTS-HD and DTS-HD

"HDMI","HDMI logo" and "High-Denition Multimedia Interface"

are trademarks or registered trademarks of HDMI Licensing

LLC.

Important safety instructions .............................................................................3

Limited warranty .................................................................................................4

Front panel controls ............................................................................................5

Rear panel connections .....................................................................................6

Remote control ....................................................................................................7

Apple device compatibility ..................................................................................7

Front panel display .............................................................................................8

Loudspeaker connections ..................................................................................8

Analogue audio connections ..............................................................................9

Digital audio connections ...................................................................................9

HDMI input connections .................................................................................. 10

5.1/7.1 Direct in .............................................................................................. 10

4K video resolution .......................................................................................... 10

Video output connection (HDMI)..................................................................... 11

7.1 Preamp out ................................................................................................ 11

Front input connections .................................................................................. 12

Aerial connections ........................................................................................... 12

551R V2 setup ................................................................................................. 12

1. Speaker conguration ............................................................................. 12

2. Speaker setup ......................................................................................... 13

Level calibration .......................................................................................... 14

Auto speaker setup for Distance/Level ..................................................... 14

3. Assigning Video inputs ............................................................................ 15

4. Source setup ........................................................................................... 16

Audio connection type ................................................................................ 16

Surround sound modes ................................................................................... 16

Operating instructions ..................................................................................... 18

Using the Tuner ........................................................................................... 21

Lip sync ........................................................................................................ 21

Audio Return Channel ................................................................................. 22

Audio split mode .......................................................................................... 22

Advanced setup................................................................................................ 22

Sub crossovers and bass management .................................................... 22

Bi-amping ..................................................................................................... 23

Tone/Sub conguration .............................................................................. 23

OSD setup .................................................................................................... 23

Advanced setup ........................................................................................... 24

DTS-HD speaker re-map ............................................................................. 24

Dynamic range control ................................................................................ 25

HDMI preview ................................................................................................... 25

Custom installation (C.I.) use .......................................................................... 26

Reset/Back-up memory ................................................................................... 26

Troubleshooting ............................................................................................... 26

Technical specications .................................................................................. 27

Produktspecifikationer

Varumärke:	Cambridge
Kategori:	hi-fi system
Modell:	Azur 551R V2
Vikt:	10000 g
Bredd:	430 mm
Djup:	340 mm
Höjd:	110 mm
Frekvensband:	AM, FM
Hörlursutgångar:	1
Ljudutgångskanaler:	7.1 kanaler
Antal HDMI-utgångar:	2
Fjärrkontroll ingår:	Nej
Produktens färg:	Svart
Inbyggd kortläsare:	Nej
3D kompatibilitet:	Ja
Nätverksansluten (Ethernet):	Nej
Effekt per kanal (20-20KHz @ 8 ohm):	60 W
Mottagartyp:	Surround
Högtalare anslutning typ:	RCA
Optisk enhet ingår:	Nej
Apple-kompatibel dockningsmöjlighet:	Stöds inte
Digital audio optisk, ingående:	4
Digital koaxialingång för ljud:	4
HDMI-in:	6
