Minx Air100/200 Wireless music system

Wi-fi set-up

Go to your computer and click on the

WiFi/network logo and select Minx Air_XXX.

Mac

iPad

Open a new page in your internet browser (Internet Explorer, Safari,

Chrome etc). In the address bar of your browser, type 192.168.1.1

followed by ‘enter’ and the Minx Air setup page will be displayed.

If you are happy that you have entered your details correctly, click

‘OK’ to finish.

The Minx Air set-up page may now display an ‘error’ or ‘no data

received’ type message. Don’t worry, this is normal. You can now

close your internet browser.

Select your home Wi-Fi network from the ‘Service Set ID (SSID)’

drop-down list of choices.

Made a mistake?

To reset the Minx Air, press and hold the power button

and WPS button on the rear panel for 10 - 15 seconds

until the Minx Air switches off. Then start again at Step 1.

You can also watch the Minx Air connection videos on

the Cambridge Audio website for further explanation.

Type your home Wi-Fi/Network password into the red box,

and click the ‘Apply’ button.

(Don’t know your Wi-Fi password key? It’s commonly found on

a label on your internet modem/router)

After a few seconds, the Minx Air will be connected to your

network (successful connection is indicated by a solid green light

on the rear of the product). This can take up to 30 seconds.

(If your computer/tablet has not already done so automatically, change the

Wi-Fi/network setting on your computer/tablet back to your home network).

Connect the Minx Air to the mains power and press the power

button on top of the unit. Wait for up to 20 seconds for the

flashing light on the rear panel to flash green and orange

iTunes

iPad

iPhone

To enjoy Airplay and internet radio, you must first

connect your Minx Air to your home network.

If you have a laptop computer, tablet, or any

other wi-fi enabled internet browser go to Step 1

below to connect to your home network.

If you have no wi-fi enabled internet browser

(such as a desktop computer) then please see the

online user manual for wired set-up instructions.

Airplay

Congratulations! You are now ready to stream music via Airplay.

When you open iTunes or your Music you will see the

Airplay logo allowing you to select your Minx Air as the

playback device.

Note – when Minx Air is selected, it will take a few seconds

to connect.

Wait for the music to start playing before adjusting the volume.
