Sense Single Oven
Instruction Manual
Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk
C2105,
C2105SS,
C2106GM
3
Instruction manual C2105, C2105SS, & C2106GM
Please keep this instruction manual for future reference
SAFETY INSTRUCTIONS
Read these instructions carefully and completely before using
your appliance, keep it in a convenient place for reference
when necessary.
- This appliance can be used by children aged from 8 years
and above.
- Persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge
must be supervised and given appropriate instruction
concerning the use of the appliance in a safe way and
understand the hazards involved.
- Children shall not play with the appliance.
- Cleaning and user maintenance should not be carried
out by children without supervision.
- The appliance is not intended to be operated by means
of an external timer or separate remote control system.
Instruction manual C2105, C2105SS, & C2106GM4
Please keep this instruction manual for future reference
WARNING:
- The appliance and its accessible parts become hot
during use. Care should be taken to avoid touching
heating elements.
- Children less than 8 years of age should be kept away
unless continuously supervised.
- To prevent fire hazards do not store items on the
cooking surfaces.
- During use, handles can get hot.
- Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass or any other
surface of the appliance as it can scratch the surface
which may result in the glass shattering or permanent
damage to the surface.
- Do not use steam cleaners for cleaning the appliance.
- Ensure the appliance is switched off before replacing the
lamp to avoid the possibility of electric shock.
5
Instruction manual C2105, C2105SS, & C2106GM
Please keep this instruction manual for future reference
CAUTION:
- Accessible parts may be hot when the cooking or grilling
is in use. Young children should be kept away.
- Your appliance is produced in accordance with all
applicable local and international standards and
regulations.
- Maintenance and repair work must be made only
by authorised Caple service technicians. Installation
and repair work that is carried out by unauthorised
technicians may endanger you.
- It is dangerous to alter or modify the specifications of the
appliance in any way.
- Prior to installation, ensure that the local distribution
conditions (electricity voltage and frequency) and the
requirements of the appliance are compatible. The
requirements for this appliance are stated on the rating
label.
- This appliance is designed only for cooking food and is
intended for indoor use.
Instruction manual C2105, C2105SS, & C2106GM6
Please keep this instruction manual for future reference
- This product is not designed for commercial use, it is
a household appliance only. It is not intended to be
used in:
• Staff kitchen areas in shops, offices and other working
environments.
• Bed and breakfast type environments.
• By clients in hotels, motels and other residential type
environments.
- Do not try to lift or move the appliance by pulling the
door handle.
- All possible security measures have been taken to ensure
your safety. Since the glass may break, you should be
careful while cleaning to avoid scratching.
- Avoid hitting or knocking on the glass with accessories.
- Ensure that the supply cord is not wedged or trapped
during the installation. If the supply cord is damaged,
it must be replaced by a Caple service technician or
similarly qualified persons in order to prevent a hazard.
- While the oven door is open, do not let children climb on
the door or sit on it.
7
Instruction manual C2105, C2105SS, & C2106GM
Please keep this instruction manual for future reference
INSTALLATION WARNINGS
- Do not operate the appliance before it is fully installed.
- The appliance must be installed by an authorised
technician.
- Caple is not responsible for any damage that may
be caused by defective placement and installation by
unauthorised persons.
- When unpacking the appliance, make sure that it is
not damaged during transportation. In the case of any
defect; do not use the appliance and contact your retailer
or Caple Service immediately.
- Materials used for packaging (nylon, staplers, styrofoam
etc) may cause harmful effects to children they should be
disposed of immediately.
- Protect your appliance against atmospheric effects. Do
not expose it to effects such as sun, rain, snow etc.
- The surrounding materials of the appliance (i.e. kitchen
cabinet or furniture) must be able to withstand a
minimum temperature of 120°C.
Instruction manual C2105, C2105SS, & C2106GM10
Please keep this instruction manual for future reference
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
This appliance is marked according to the European directive on Waste Electrical and Electronic
Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health, which could otherwise
be caused by inappropriate waste handling of this product. The symbol on the product indicates
that this product may not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic equipment. Disposal must
be carried out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
TECHNICAL FICHE
This appliance conforms to all current and applicable energy regulations. To view the technical
fiche that supports the energy labelling data, please visit the product page on our website www.
caple.co.uk.
WARRANTY
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing,
you must provide the following information to your retailer in order to receive a replacement:
date of purchase, model and serial number. Registration can also be completed online by
visiting www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together with
proof of purchase.
If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.
Instruction manual C2105, C2105SS, & C2106GM14
Please keep this instruction manual for future reference
ELECTRICAL CONNECTION
WARNING: THIS APPLIANCE MUST BE EARTHED
Check that the power rating of the mains supply is suitable for the maximum power of the
appliance as indicated on the rating label.
The fuse rating for this appliance is 16amp.
The appliance is supplied with a mains lead it should be “Hard wired” as follows:
› The “yellow/green” earth wire, which must be connected to a terminal, and has to be about
10mm longer than the other wire.
› The neutral wire has to be connected to the terminal marked with a letter N.
› The Live wire should only be connected to the terminal marked L.
Mains connection can also be made by fitting a double pole switch with a minimum gap between
the contacts of 3mm, proportionate to the load and complying with the regulations in force.
THE YELLOW/GREEN EARTH WIRE SHOULD NOT BE CONTROLLED BY THE
SWITCH.
When a double pole switch is used for mains supply connection it should be easily accessed, once
the appliance is in position.
IMPORTANT:
The mains supply cable should be positioned so that it is never subjected to temperatures which
are more than 50ºC above ambient temperature.
The electrical safety of the appliance can only be guaranteed when it has been correctly
connected to a properly earthed mains electrical supply, as laid down in the current regulations for
electrical safety.
The manufacturer cannot be held responsible for any damage to persons or objects due to lack of
an earth connection.
The ovens are designed to operate with a mono-phase alternating current of
220-240V, 50Hz.
BEFORE THE INSTALLATION OF THE APPLIANCE, CHECK THE SPECIFICATIONS
ON THE RATING LABEL.
15
Instruction manual C2105, C2105SS, & C2106GM
Please keep this instruction manual for future reference
CONTROL PANEL AND DISPLAY
1
Control Panel and display
Button Description
1
○
Power
2
○
Programme
○
3 Timer
4
○
Temperature
5
○
Light
6
○
Up / Down (+/-)
○
7 Select
8
○
Boost
○
9 S tart
/ Pause
Display Description
10
○
Function / programme
11
○
Time r
12
○
Actual Temperature/Time
13
○
Set Temperature
14
○
Curr ent Time
15
○
Safety Lock
61
○
Boost
71
○
Cooking Dura tion Time
81
○
Rotisserie
91
○
Alarm
02
○
Heating Indicator
12
○
Light
22
○
Cooking End Time
1 2
4 3 10 11 13
12 16
14 15
6
5 19
17 18 21
20 22 7 8 9
1. Power
2. Programme
3. Timer
4. Temperature
5. Light
6. Up / Down (+/-)
7. Select
8. Boost
9. Start / Pause
10. Function / programme
11. Timer
12. Actual Temperature/Time
13. Set Temperature
14. Current Time
15. Safety Lock
16. Boost
17. Cooking Duration Time
18. Rotisserie
19. Alarm
20. Heating Indicator
21. Light
22. Cooking End Time
ACCESSORIES
2 x Chrome oven shelves
1 x Grill pan with rack and handle
2 x Telescopic runners (x2 pairs)
1 x Rotisserie
To purchase additional or replacement accessories, please visit www.caple.co.uk
BUTTON DESCRIPTION DISPLAY DESCRIPTION
17
Instruction manual C2105, C2105SS, & C2106GM
Please keep this instruction manual for future reference
TIMER BUTTON
SETTING THE TIME
Press for 3sec to set current time. Adjust time by pressing + / - .and press SELECT to
confirm setting.
SETTING TIMER
Press to bring up DURATION. The display will flash ”0:00”. Adjust time by pressing + / - and
then press SELECT to set the duration. Once the time is up, an alarm will sound and the oven will
switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds,
set time back to “0:00” to cancel.
AUTOMATIC COOKING
Once the DURATION time has been set, press the until the END time starts to flash. Adjust
the end time by pressing + / - and press SELECT to confirm. Oven start time = End time –
Duration time.
SAFETY LOCK
Pressing SELECT for 5 seconds to enter or cancel the safety lock function.
TEMPERATURE SETTING.
Once the function is selected, press ºC to set the temperature. Adjust temperature by pressing
+ / - and press SELECT to confirm. Press the button to then start cooking.
BOOST FUNCTION
If temperature is set to more than 100ºC, you can press this key to heat up oven faster. Once
activated the display will show
The Boost function will stop when the oven gets to the required temperature.
LIGHT FUNCTION .
Press the light button to turn the internal oven light on/off. The light will automatically turn off if
no operation in 3 minutes.
SETTING THE ALARM/MINUTE MINDER.
By pressing the button twice, this takes you to the minute minder function and the will
appear. Press the + / - button to select the time and press SELECT to confirm. Once the time runs
out an alarm will sound, press any button to turn the alarm off. The oven will continue to run.
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
2
Operation
1. Power button . To turn on/off the display panel. When turned on, the time of day will be shown.
2. Programme button . Press to shift between functions. When you shift to a new function, the
current function will stop and the cooking time must be reset. The Function list is as per the below order:
3. Start/Pause button . Once the required function has been selected, press to start cooking.
Once cooking has started the display will show the current oven temperature. For example;
when the oven is paused, the display will show the current time. For example;
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
Instruction manual
Please keep this instruction manual for future reference
17
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing + / - .
And press select to confirm setting.
Setting timer - Press to bring up Duration. The display will flash ”0:00”.
Adjust time by pressing + / - and then press Select to set the duration. Once the
time is up, an alarm will sound and the oven will switch off. Press any button to
cancel the alarm. If you wish to cancel the alarm before it sounds, set time back to
“0:00” to cancel.
Automatic cooking - Once the Duration time has been set, press the until the
End time starts to flash. Adjust the end time by pressing + / - and press Select to
confirm. Oven start time = End time – Duration time.
5. Safety Lock Pressing Select for 5 seconds to enter or cancel the safety
lock function.
6. Temperature Setting. Once the function is selected, press ºC to set the
temperature. Adjust temperature by pressing + / - and press Select to confirm.
Press the button to then start cooking.
7. Boost function BOOST If temperature is set to more than 100ºC, you can press
this key to heat up oven faster. Once activated the display will show
The Boost function will stop when the oven gets to the required
temperature.
8. Light function . Press the light button to turn the internal oven light on/off.
The light will automatically turn off if no operation in 3 minutes.
9.
button twice, this takes you to the
minute minder function and the
will appear. Press the ++ // -- buttons to select the time
Setting the alarm/minute minder
By pressing the
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
4. Timer button.
Setting the time - Press for 3sec to set current time. Adjust time by pressing / . And press
to confirm setting.
Setting timer/alarm. Press to bring up . The display will flash ”0:00”. Adjust time by
pressing / and then press to set the duration. Once the time is up, an alarm will sound and the oven
will switch off. Press any button to cancel the alarm. If you wish to cancel the alarm before it sounds, set time
back to “0:00” to cancel.
Automatic cooking - Once the time has been set, press the until the time starts to flash.
Adjust the end time by pressing / and press to confirm.
Oven start time = End time – Duration time.
5. Safety Lock . Pressing
for 5sec to enter or cancel the safety lock function.
6. Temperature Setting. Once the function is selected, press to set the temperature. Adjust temperature
by pressing / and press to confirm. Press the button to then start cooking.
7. Boost function . If temperature is set to more than 100°C, you can press this key to heat up
oven faster. Once activated the display will show . The Boost function will stop when the oven gets to
the required temperature.
8. Light function . Press the light button to turn the internal oven light on/off. The light will automatically
turn off if no operation in 3 minutes.
2
Operation
1. Power button .To turn on/off the display panel. When turned on, the time of day will be shown.
2. Programme button . Press to shift between functions. When you shift to a new function, the
current function will stop and the cooking time must be reset. The Function list is as per the below order:
3. Start/Pause button . Once the required function has been selected, press to start cooking.
Once cooking has started the display will show the current oven temperature. For example;
when the oven is paused, the display will show the current time. For example;
and press SSeelleecctt to confirm. Once the time runs out an alarm will sound, press any button
to turn the alarm off. The oven will continue to run.
1
Control Panel and display
Button Description
1
○
Power
2
○
Programme
○
3 Timer
4
○
Temperature
5
○
Light
6
○
Up / Down (+/-)
○
7 Select
8
○
Boost
○
9 S tart
/ Pause
Display Description
10
○
Function / programme
11
○
Time r
12
○
Actual Temperature/Time
13
○
Set Temperature
14
○
Curr ent Time
15
○
Safety Lock
61
○
Boost
71
○
Cooking Dura tion Time
81
○
Rotisserie
91
○
Alarm
02
○
Heating Indicator
12
○
Light
22
○
Cooking End Time
1 2
4 3 10 11 13
12 16
14 15
6
5 19
17 18 21
20 22 7 8 9
19
Instruction manual C2105, C2105SS, & C2106GM
Please keep this instruction manual for future reference
In demo mode, the normal operation of the cooling fan, circulation fan, and lighting work
normally, however all heating elements and other functions are disabled.
If the oven is turned off, it will remain in Demo mode when the oven is turned back on.
TO TURN OFF DEMO MODE
Press the button to enter standby mode, then press and hold the button for 5 seconds.
The alarm will beep 3 times, and the will disappear from the display to confirm the system
has exited Demo mode, and is ready for normal use.
DEMO MODE
TO TURN ON DEMO MODE:
Press the button to turn the oven on (in standby mode). Press and hold the button for
5 seconds. The alarm will beep 3 times, and will appear in the top right of the display to
confirm the oven has entered demo mode.
www.caple.co.uk
CC22110011 // CC22110055
DDEEMMOO MMOODDEE
TToo ttuurrnn oonn ddeemmoo mmooddee::
Press the button to turn the oven on (in standby mode). Press and hold the button for 5
seconds. The alarm will beep 3 times, and will appear in the top right of the display to
confirm the oven has entered demo mode.
In demo mode, the normal operation of the cooling fan, circulation fan, and lighting work normally,
however all heating elements and other functions are disabled.
If the oven is turned off, it will remain in Demo mode when the over is turned back on.
TToo ttuurrnn ooffff ddeemmoo mmooddee
Press the button to enter standby mode, then press and hold the button for 5 seconds. The
alarm will beep 3 times, and the will disappear from the display to confirm the system has
exited Demo mode, and is ready for normal use.
www.caple.co.uk
CC22110011 // CC22110055
DDEEMMOO MMOODDEE
TToo ttuurrnn oonn ddeemmoo mmooddee::
Press the button to turn the oven on (in standby mode). Press and hold the button for 5
seconds. The alarm will beep 3 times, and will appear in the top right of the display to
confirm the oven has entered demo mode.
In demo mode, the normal operation of the cooling fan, circulation fan, and lighting work normally,
however all heating elements and other functions are disabled.
If the oven is turned off, it will remain in Demo mode when the over is turned back on.
TToo ttuurrnn ooffff ddeemmoo mmooddee
Press the button to enter standby mode, then press and hold the button for 5 seconds. The
alarm will beep 3 times, and the will disappear from the display to confirm the system has
exited Demo mode, and is ready for normal use.
www.caple.co.uk
CC22110011 // CC22110055
DDEEMMOO MMOODDEE
TToo ttuurrnn oonn ddeemmoo mmooddee::
Press the button to turn the oven on (in standby mode). Press and hold the button for 5
seconds. The alarm will beep 3 times, and will appear in the top right of the display to
confirm the oven has entered demo mode.
In demo mode, the normal operation of the cooling fan, circulation fan, and lighting work normally,
however all heating elements and other functions are disabled.
If the oven is turned off, it will remain in Demo mode when the over is turned back on.
TToo ttuurrnn ooffff ddeemmoo mmooddee
Press the button to enter standby mode, then press and hold the button for 5 seconds. The
alarm will beep 3 times, and the will disappear from the display to confirm the system has
exited Demo mode, and is ready for normal use.
www.caple.co.uk
CC22110011 // CC22110055
DDEEMMOO MMOODDEE
TToo ttuurrnn oonn ddeemmoo mmooddee::
Press the button to turn the oven on (in standby mode). Press and hold the button for 5
seconds. The alarm will beep 3 times, and will appear in the top right of the display to
confirm the oven has entered demo mode.
In demo mode, the normal operation of the cooling fan, circulation fan, and lighting work normally,
however all heating elements and other functions are disabled.
If the oven is turned off, it will remain in Demo mode when the over is turned back on.
TToo ttuurrnn ooffff ddeemmoo mmooddee
Press the button to enter standby mode, then press and hold the button for 5 seconds. The
alarm will beep 3 times, and the will disappear from the display to confirm the system has
exited Demo mode, and is ready for normal use.
www.caple.co.uk
CC22110011 // CC22110055
DDEEMMOO MMOODDEE
TToo ttuurrnn oonn ddeemmoo mmooddee::
Press the button to turn the oven on (in standby mode). Press and hold the button for 5
seconds. The alarm will beep 3 times, and will appear in the top right of the display to
confirm the oven has entered demo mode.
In demo mode, the normal operation of the cooling fan, circulation fan, and lighting work normally,
however all heating elements and other functions are disabled.
If the oven is turned off, it will remain in Demo mode when the over is turned back on.
TToo ttuurrnn ooffff ddeemmoo mmooddee
Press the button to enter standby mode, then press and hold the button for 5 seconds. The
alarm will beep 3 times, and the will disappear from the display to confirm the system has
exited Demo mode, and is ready for normal use.
www.caple.co.uk
CC22110011 // CC22110055
DDEEMMOO MMOODDEE
TToo ttuurrnn oonn ddeemmoo mmooddee::
Press the button to turn the oven on (in standby mode). Press and hold the button for 5
seconds. The alarm will beep 3 times, and will appear in the top right of the display to
confirm the oven has entered demo mode.
In demo mode, the normal operation of the cooling fan, circulation fan, and lighting work normally,
however all heating elements and other functions are disabled.
If the oven is turned off, it will remain in Demo mode when the over is turned back on.
TToo ttuurrnn ooffff ddeemmoo mmooddee
Press the button to enter standby mode, then press and hold the button for 5 seconds. The
alarm will beep 3 times, and the will disappear from the display to confirm the system has
exited Demo mode, and is ready for normal use.
www.caple.co.uk
CC22110011 // CC22110055
DDEEMMOO MMOODDEE
TToo ttuurrnn oonn ddeemmoo mmooddee::
Press the button to turn the oven on (in standby mode). Press and hold the button for 5
seconds. The alarm will beep 3 times, and will appear in the top right of the display to
confirm the oven has entered demo mode.
In demo mode, the normal operation of the cooling fan, circulation fan, and lighting work normally,
however all heating elements and other functions are disabled.
If the oven is turned off, it will remain in Demo mode when the over is turned back on.
TToo ttuurrnn ooffff ddeemmoo mmooddee
Press the button to enter standby mode, then press and hold the button for 5 seconds. The
alarm will beep 3 times, and the will disappear from the display to confirm the system has
exited Demo mode, and is ready for normal use.
23
Instruction manual C2105, C2105SS, & C2106GM
Please keep this instruction manual for future reference
› Remount the glass cover and reconnect the appliance to the power supply.
DO NOT TOUCH the light bulb directly with your hands.
WARNING:
Ensure that the appliance is disconnected from the mains before replacing the lamp to avoid the
possibility of electric shock.
Inner Lamp in Oven Cavity
Glass Cover
Lamp
Halogen lamp characteristics
› Voltage: AC220V-240V
› Wattage: 25W
› Cap: G9
REPLACING THE OVEN LAMPS
› Switch off your oven at the mains.
› Remove the glass cover of the lamp-holder
› Remove the light bulb and replace it with a similar one
25
Instruction manual C2105, C2105SS, & C2106GM
Please keep this instruction manual for future reference
REMOVING THE OVEN DOOR
To make it easier to clean the inside of your oven, the oven door can be easily removed, by
proceeding as follows (fig. 11):
› Open the door completely and lift the 2 levers “B” (fig.11-1);
› Now, shutting the door slightly, you can lift it out by pulling out the hooks “A” as shown in fig 2.
TO REASSEMBLE THE DOOR
› With the door in a vertical position, insert the two hooks “A” into the slots;
› Ensure that seat “D” is hooked perfectly onto the edge of the slot (move the oven door
backwards and forward slightly);
› Keep the oven door open fully, unhook the 2 levers “B” downwards and then
shut the door again.
43
Disassembling/assembling the oven door
To make it easier to clean the inside of your oven, the oven door can be easily removed, by proceeding as
follows (fig. 11):
ƽ Open the door completely and lift the 2 levers “B” (fig.11-1);
ƽ Now, shutting the door slightly, you can lift it out by pulling out the hooks “A” as shown in figure 2.
To reassemble the door:
ƽ With the door in a vertical position, insert the two hooks “A” into the slots;
ƽ Ensure that seat “D” is hooked perfectly onto the edge of the slot (move the oven door backwards and forward
slightly);
ƽ Keep the oven door open fully, unhook the 2 levers “B” downwards and then shut the door again.
Removable the glass panels
The oven door is made up of 3 panes of glass and has vents at the top and bottom. When the oven
is operating,
air is circulated through the door to keep the outer pane cool. If condensation has worked its way
in between the
glass panes, the door can be dismantled in order to clean in between the panes.
Remove the door as per above instruction and place it on a protective surface (e.g. on a table cloth)
to prevent it
getting scratched. The door handle should line up with the edge of the table. Make sure the glass
lies flat to avoid
breakage of glass during cleaning.
Clean the glass panes
and other parts with a damp
microfibre cloth.
or a clean sponge and a solution of hot water with a little washing-up liquid. Wipe dry using a soft
cloth.
Fig.11-1
Fig.11-2
1. Press the button on left and right side of door, take out top rail. (Fig.1)
2. Take out inner glass slowly (Fig.2)
3. Loose clips by unscrewing. (Fig.3)
4. Take out middle glass. (Fig.4)
43
Disassembling/assembling the oven door
To make it easier to clean the inside of your oven, the oven door can be easily removed, by proceeding as
follows (fig. 11):
ƽ Open the door completely and lift the 2 levers “B” (fig.11-1);
ƽ Now, shutting the door slightly, you can lift it out by pulling out the hooks “A” as shown in figure 2.
To reassemble the door:
ƽ With the door in a vertical position, insert the two hooks “A” into the slots;
ƽ Ensure that seat “D” is hooked perfectly onto the edge of the slot (move the oven door backwards and forward
slightly);
ƽ Keep the oven door open fully, unhook the 2 levers “B” downwards and then shut the door again.
Removable the glass panels
The oven door is made up of 3 panes of glass and has vents at the top and bottom. When the oven
is operating,
air is circulated through the door to keep the outer pane cool. If condensation has worked its way
in between the
glass panes, the door can be dismantled in order to clean in between the panes.
Remove the door as per above instruction and place it on a protective surface (e.g. on a table cloth)
to prevent it
getting scratched. The door handle should line up with the edge of the table. Make sure the glass
lies flat to avoid
breakage of glass during cleaning.
Clean the glass panes
and other parts with a damp
microfibre cloth.
or a clean sponge and a solution of hot water with a little washing-up liquid. Wipe dry using a soft
cloth.
Fig.11-1
Fig.11-2
1. Press the button on left and right side of door, take out top rail. (Fig.1)
2. Take out inner glass slowly (Fig.2)
3. Loose clips by unscrewing. (Fig.3)
4. Take out middle glass. (Fig.4)
Fig.11-1 Fig.11-2
Scan the QR code below to access the ‘How to video’.
Produktspecifikationer
| Varumärke: | Caple |
| Kategori: | Ugn |
| Modell: | C2106GM |
| Inbyggd display: | Ja |
| Vikt: | 37950 g |
| Bredd: | 600 mm |
| Djup: | 540 mm |
| Höjd: | 593 mm |
| Grill: | Ja |
| Typ av klocka: | Elektronisk |
| Rotisserie: | Ja |
| Antal lampor: | 2 lamp(or) |
| Antal ugnar: | 1 |
| Energiförbrukning (konventionell): | 0.86 kWh |
| Energieffektivitetsindex (EEI): | 103.4 |
| Ugnsstorlek: | Medium |
| Självrengörande: | Ja |
| Färgnamn: | Gunmetal |
| Timerlägen: | Timer |
| Snabbstart: | Ja |
| Skärmtyp: | LED |
| Kontrolltyp: | Röra |
| Ugnstyp: | Elektrisk ugn |
| Eco-läge: | Ja |
| Ugnens nettokapacitet: | 67 l |
| Rengöringstyp: | Katalytisk |
| Dörrmaterial: | Glas |
| Apparatens placering: | Inbyggd |
| Gångjärnssida: | Ned |
| Hyllor material: | Krom |
| Energieffektivitetsskalning: | A+++ till D |
| Ström: | 16 A |
| Installationsfack, bredd: | 560 mm |
| Installationsfack, djup: | 550 mm |
| Installationsfack, höjd: | 589 mm |
| Ansluten effekt: | 3220 W |
| Inbyggd lampa: | Ja |
| Klocka: | Ja |
| Typ av timer: | Digital |
| Totalt ugn (er) invändig kapacitet: | 67 l |
| Totalt ugn: | 3220 W |
| Upptiningsfunktion i ugnen: | Ja |
| Normalkokning: | Ja |
| Interiör material: | Emalj |
| Energiförbrukning (påtvingad konvektion): | 0.79 kWh |
| Wi-Fi-styrning: | Ja |
| Antal tillagningsprogram: | 13 |
| Ugnens dörröppning: | Nedfällbar öppning |
| Mjukstängande lucka: | Ja |
| Grill, hela ytan: | Ja |
| Brödbakningsförmåga: | Nej |
| Kontrollpanelens material: | Glas |
| Kylfläkt för ugnslucka: | Ja |
| Katalytiska höljen på sidoväggar: | Ja |
| Grillning med stängd lucka: | Ja |
Behöver du hjälp?
Om du behöver hjälp med Caple C2106GM ställ en fråga nedan och andra användare kommer att svara dig
Ugn Caple Manualer
22 September 2025
22 September 2025
22 September 2025
22 September 2025
22 September 2025
22 September 2025
22 September 2025
22 September 2025
22 September 2025
22 September 2025
Ugn Manualer
- AENO
- Becken
- Hansa
- Fratelli
- Vedette
- KitchenAid
- OK
- Delonghi
- Pegasus
- Forge Adour
- Marynen
- Limit
- Alpina
- Brother
- Atosa
Nyaste Ugn Manualer
21 Oktober 2025
20 Oktober 2025
20 Oktober 2025
20 Oktober 2025
19 Oktober 2025
19 Oktober 2025
18 Oktober 2025
18 Oktober 2025
18 Oktober 2025
17 Oktober 2025
