Sida 1/12
WARNING
Please call 800-950-4458 or visit www.chapinmfg.com if you are
missing any parts, having trouble assembling, or have any questions
regarding the safe operation of this product.
DO NOT RETURN TO THE STORE.
MODEL 8700
Carefully Read These Instructions Before Use
014315 R1016
CHEST-MOUNTED SPREADER
1E
WARNING
IMPROPER USE OR FAILURE TO FOLLOW INSTRUCTIONS CAN RESULT IN
PRODUCT FAILURE OR INJURIES. FOR SAFE USE OF THIS PRODUCT YOU MUST
READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING.
ASSEMBLY INSTRUCTIONS
The Chapin 8700 Chest Spreader is preassembled at our factory, leaving only the crank handle for
you to attach. To attach, remove nut, slide handle through plastic base and fully tighten the nut.
Insert handle into gear and turn clockwise to tighten. Use a 14mm wrench to snug the nut against
the gear. (SEE FIGURE A)
WARNING:
is product contains chemicals, including lead, known to the state of California to
cause birth defects and other reproductive harm. Wash hands after handling.
FIGURE A
2E
OPERATING INSTRUCTIONS
1) Make sure the Gate is closed before lling hopper.
2) Fill hopper with material.
3) Place shoulder strap over shoulder. Place unit on chest and adjust the strap.
4) Select spreader setting 1-6 to set size of gate (Fig. B).
5) Crank the handle maintaining a steady clockwise motion and walk a consistent
pace to spread the material evenly. Squeeze handle to open the gate.
6) Adjust side bafe as needed (Fig. D).
7) Adjust Gate location as needed (Fig. D).
8) To close the Gate, simply release handle.
SPREADER SETTINGS:
Material Type
Spreader Setting*
Grass Seed
Fine 4
Coarse 5
* Due to the variables involved, these settings arre intended for reference only.
FIGURE D
(Gate Location)
FIGURE C
Side
Bafe
Gate
Control
FIGURE B
(Spreader Settings)
