Christie D16HD-HS Bruksanvisning

Christie videostråle D16HD-HS

Läs gratis den bruksanvisning för Christie D16HD-HS (75 sidor) i kategorin videostråle. Guiden har ansetts hjälpsam av 3 personer och har ett genomsnittsbetyg på 3.5 stjärnor baserat på 2 recensioner. Har du en fråga om Christie D16HD-HS eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/75

Christie HS Series 2K

D13HD2-HS, D13WU2-HS, D16HD-HS

D16WU-HS, D20HD-HS, D20WU-HS

User Manual

020-001466-05

NOTICES

All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.

GENERAL

Every effort has been made to ensure accuracy, however in some cases changes in the products or availability could occur which may not be reflected in this

document. Christie reserves the right to make changes to specifications at any time without notice. Performance specifications are typical, but may vary

depending on conditions beyond Christie's control such as maintenance of the product in proper working conditions. Performance specifications are based on

information available at the time of printing. Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied warranties

of fitness for a particular purpose. Christie will not be liable for errors contained herein or for incidental or consequential damages in connection with the

performance or use of this material. Canadian manufacturing facility is ISO 9001 and 14001 certified.

WARRANTY

Products are warranted under Christie’s standard limited warranty, the complete details of which are available by contacting your Christie dealer or Christie. In

addition to the other limitations that may be specified in Christie’s standard limited warranty and, to the extent relevant or applicable to your product, the

warranty does not cover:

a. Problems or damage occurring during shipment, in either direction.

b. Problems or damage caused by combination of a product with non-Christie equipment, such as distribution systems, cameras, DVD players, etc., or use of

a product with any non-Christie interface device.

c. Problems or damage caused by misuse, improper power source, accident, fire, flood, lightning, earthquake, or other natural disaster.

d. Problems or damage caused by improper installation/alignment, or by equipment modification, if by other than Christie service personnel or a Christie

authorized repair service provider.

e. Problems or damage caused by use of a product on a motion platform or other movable device where such product has not been designed, modified or

approved by Christie for such use.

f. Except where the product is designed for outdoor use, problems or damage caused by use of the product outdoors unless such product is protected from

precipitation or other adverse weather or environmental conditions and the ambient temperature is within the recommended ambient temperature set

forth in the specifications for such product.

g. Defects caused by normal wear and tear or otherwise due to normal aging of a product.

The warranty does not apply to any product where the serial number has been removed or obliterated. The warranty also does not apply to any product sold by

a reseller to an end user outside of the country where the reseller is located unless (i) Christie has an office in the country where the end user is located or (ii) the

required international warranty fee has been paid.

The warranty does not obligate Christie to provide any on site warranty service at the product site location.

PREVENTATIVE MAINTENANCE

Preventative maintenance is an important part of the continued and proper operation of your product. Failure to perform maintenance as required, and in

accordance with the maintenance schedule specified by Christie, will void the warranty.

REGULATORY

The product has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the product is operated in a commercial environment. The product generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of the product in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at the user’s own expense.

CAN ICES-3 (A)/NMB-3 (A)

이 기기는 업무용 (A 급 ) 으로 전자파적합등록을 한 기기이오니 판매자 또는 사용자는 이점을 주의하시기 바라며 , 가정 외의 지역에서 사용하는 것을 목적으로 합니다 .

ENVIRONMENTAL

The product is designed and manufactured with high-quality materials and components that can be recycled and reused. This symbol means that electrical

and electronic equipment, at their end-of-life, should be disposed of separately from regular waste. Please dispose of the product appropriately and according

to local regulations. In the European Union, there are separate collection systems for used electrical and electronic products. Please help us to conserve the

environment we live in!

Produktspecifikationer

Varumärke:	Christie
Kategori:	videostråle
Modell:	D16HD-HS
Produkttyp:	Projektor för stora lokaler
Vikt:	42500 g
Bredd:	596 mm
Djup:	677 mm
Höjd:	203 mm
Förpackningens bredd:	843 mm
LED-indikatorer:	Ja
Placering:	Skrivbord
Zoomkapacitet:	Ja
Projektorns ljusstyrka:	14000 ANSI-lumen
Projektionsteknik:	DLP
Matrisstorlek:	0.96 "
Antal HDMI-portar:	2
DVI-port:	Ja
Ljuskällans livslängd:	20000 h
Typ av ljuskälla:	laser
Inbyggda högtalare:	Nej
Certifiering:	UL/CSA/IEC 60950-1\nFCC Class A\nCE\nFDA\nCCC\nKC\nPSE\nCU\nSABS\nBIS\nVCCI\nRCM\nUkr\nTER\nSASO\nREACH\nWEEE
Full HD:	Ja
HDMI-version:	1.4
Kontrastförhållande (dynamisk):	5000:1
BNC-ingångsportar:	1
Fjärrkontroll ingår:	Ja
HDBaseT-port:	Ja
Seriellt gränssnitt:	RS-232
3D-format som stöds:	Frame packing, Side by side, Top and bottom
Produktens färg:	Svart
bruksanvisning:	Ja
Typ av fjärrkontroll:	Trådlös/Kabel
Låddjup:	513 mm
Vikt inkl. förpackning:	54000 g
Inbyggd kortläsare:	Nej
Kompositvideo ut:	1
Datahastighet för Ethernet-LAN:	10, 100 Mbit/s
Antal LAN (RJ-45) anslutningar:	1
Strömförbrukning (vanlig):	1300 W
Temperatur vid drift:	0 - 40 ° C
Intervall för relativ operativ luftfuktighet:	0 - 85 %
Hållbarhetscertifiering:	RoHS
AC-inspänning:	100 - 240 V
3D kompatibilitet:	Ja
Kabel inkluderad:	AC
Brännviddsintervall:	- mm
Nätverksansluten (Ethernet):	Ja
Växelström Frekvens:	50 / 60 hz
Strömkälla:	AC
Ljudnivå Lc IEC:	45 dB
Antal USB 2.0 anslutningar:	1
Strömförbrukning i vänteläge:	- W
Kontrastförhållande (medel):	1200:1
Native bildförhållande:	16:9
Värmeavgivning:	4450 BTU/h
Positionering på marknaden:	Business
Kvalitet på VGA (D-Sub) porten:	1
Vertikalt sökområde:	24 - 85 hz
Horisontellt sökområde:	15 - 91 kHz
Ingående kompositvideo:	1
Projektorns naturliga upplösning:	1080p (1920x1080)
Skärmavstånd:	- m
Kompatibla skärmstorlekar:	- "
Ljudnivå (strömsparläge):	39 dB
matristyp:	DMD
Mini-USB 2.0 anslutningar:	1
