GETTING STARTED GUIDE

Cisco Aironet 1600 Series Access Points

First Published: December, 2012

Last Updated: March 31, 2015

1 About this Guide

2 Introduction to the Access Point

3 Safety Instructions

4 Unpacking

5 Configurations

6 Access Point Ports and Connectors

7 Configuring the Access Point

8 Mounting the Access Point

9 Deploying the Access Point on the Wireless Network

10 Troubleshooting

11 Declarations of Conformity and Regulatory Information

12 Access Point Specifications

1 About this Guide

This Guide provides instructions on how to install and configure your Cisco Aironet 1600 Series

Access Point. The 1600 Series Access Point is referred to as the 1600 series or the access point in this

document.

2 Introduction to the Access Point

The 1600 series offers dual-band radios (2.4 GHz and 5 GHz) with integrated and external antenna

options. The access points support full interoperability with leading 802.11n clients, and support a

mixed deployment with other access points and controllers.

The 1600 series access point is available in controller-based mode and supports:

• Simultaneous single-band or dual-band (2.4 GHz/5 GHz) radios

• Integrated antennas on 1602I access point models (AIR-CAP1602I-x-K9, AIR-AP1602I-UXK9)

• External antennas on 1602E access point models (AIR-CAP1602E-x-K9, AIR-AP1602E-UXK9)

Note The ‘x’ in the model numbers represents the regulatory domain. Model numbers

containing -UX, support the universal regulatory domain. For information on supported

regulatory domains, see “Regulatory Domains” section on page 6.

The features of the 1600 series are:

• Processing sub-systems (including CPUs and memory) and radio hardware which supports:

–

Network management

–

ClientLink 2.0—BeamForming to 802.11n clients as well as legacy 802.11a/g OFDM clients

–

VideoStream

–

Location

–

WIDS/WIPS

–

Security

–

Radio Resource Management (RRM)

–

Rogue detection

–

Management Frame Protection (MFP)

• 32 MB flash size

• 802.11af/at

–

CDP (Cisco Discovery Protocol)

• 2.4 GHz and 5 GHz 802.11n radios with the following features:

–

3TX x 3RX

–

2 spatial streams, 300 Mbps PHY rate

–

DPD (Digital Pre-Distortion) technology

–

Radio hardware is capable of explicit compressed beamforming (ECBF) per 802.11n standard

3 Safety Instructions

Translated versions of the following safety warnings are provided in the translated safety warnings

document that is shipped with your access point. The translated warnings are also in the Translated

Safety Warnings for Cisco Aironet Access Points, which is available on Cisco.com.

Warning

IMPORTANT SAFETY INSTRUCTIONS

This warning symbol means danger. You are in a situation that could cause bodily injury.

Before you work on any equipment, be aware of the hazards involved with electrical

circuitry and be familiar with standard practices for preventing accidents. Use the

statement number provided at the end of each warning to locate its translation in the

translated safety warnings that accompanied this device.

Statement 1071

SAVE THESE INSTRUCTIONS

Warning

Read the installation instructions before you connect the system to its power source.

Statement 1004

Warning

Installation of the equipment must comply with local and national electrical codes.

Statement 1074

Warning

This product relies on the building’s installation for short-circuit (overcurrent)

protection. Ensure that the protective device is rated not greater than:

20A.

Statement 1005
