Sida 1/33

Cisco Small Business

WBPN Wireless-N Bridge for Phone Adapters

USER GUIDE

December 2011

Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found

at www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply

a partnership relationship between Cisco and any other company. (1005R)

Cisco WBPN User Guide 3

Contents

Chapter 1: Installing the WBPN Wireless-N Bridge for Phone Adapters 5

Before You Begin 5

Using the WBPN With the Cisco SPA525G/525G2 5

Getting to Know the WBPN 6

Connecting the WBPN Using WPS 8

Using the WPS Push Button Method 8

Using the WPS PIN Method 9

Connecting the WBPN Using a PC 9

Using the Setup Wizard 10

Choosing a Username and Password 10

Configuring Local Area Network Settings 10

Configuring the Wireless Connection 10

Setting a Static IP Address on Your PC 11

Installing the WBPN Into the SPA Phone Stand 16

Chapter 2: Using the WBPN Wireless-N Bridge for Phone Adapters

Configuration Utility 19

Logging in to the Configuration Utility 19

Navigating through the Pages 20

Viewing Status Information 21

Configuring Wired Parameters 23

Configuring LAN Settings 23

Configuring Date and Time Settings 24

Configuring Wireless Parameters 24

Configuring Basic Settings 24

Configuring Advanced Settings 26

Discovering Available Wireless Networks 28

Using Wi-Fi Protected Setup (WPS) 29

Performing Administrative Tasks 30

Viewing Logs 30

Upgrading Firmware 31

Saving and Reloading Your Configuration 31

Produktspecifikationer

Varumärke:	Cisco
Kategori:	Wifi-repeater
Modell:	WBPN
Vikt:	70 g
Certifiering:	FCC 15C B, CE, VCCI, C, LVD
Maximal dataöverföringshastighet:	130 Mbit/s
Strömförbrukning (vanlig):	3 W
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
Fuktighet (förvaring):	5 - 90 %
Kryptering/säkerhet:	WEP, WPA, WPA2
Modulator:	16-QAM, 64-QAM, BPSK, OFDM, QPSK
