Sida 1/7
CDM10:4
19” 4 Channel USB Mixer
Item ref: 171.135UK
User Manual
Version 1.1
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
171.135UK User Manual
Introduction
Thank you for purchasing the Citronic CDM :4 USB Rackmount DJ Mixer. 10
This product is intended to give long term, reliable service in normal usage.
Please read these instructions before use to avoid incorrect operation and to help outline the
functions and controls.
Maintenance
No user serviceable parts inside, refer all servicing issues to qualified service personnel. Clean with
a lint-free dry or damp cloth.
To replace cross-fader, disconnect mains and undo the 2 securing screws slightly, lift the cross-
fader and disconnect from the in-line connector (noting the correct orientation). Connect the new
cross-fader, reposition and secure with the 2 screws. Channel, Master and Booth faders may be
serviced or replaced by removing the plate that they are fitted to.
Packing Contents
• IEC Mains cable
• CDM8:4 USB 19” DJ Mixer
• Instruction Manual
171.135UK User Manual
Layout
Microphone Section
Stereo Section:
1.
Combo inputs
Inputs for microphone on jack or XLR
2.
GAIN controls
Mic input sensitivity adjustment
3.
HI controls
Mic EQ high frequency adjustment
4.
MID controls
Mic EQ mid frequency adjustment
5.
LO controls
Mic EQ low frequency adjustment
6.
PAN controls
Mic left/right stereo positioning
7.
ON AIR button
Press in to activate mic channel
8.
MIC O’RIDE button
Select mics to override audio playback
9.
O’RIDE SENS control
Adjust override sensitivity to mic input
10.
O’RIDE DEPTH control
Adjust audio playback reduction amount
1 1.
Input selector
Select between rear inputs
1 2.
AUX input
3.5mm input & select switch
1 3.
GAIN controls
input sensitivity adjustment
1 4.
HI controls
EQ high freq. adjustment
1 5.
MID controls
EQ mid freq. adjustment
1 6.
LO controls
EQ low freq. adjustment
1 7.
CUE buttons
Select channel to monitor
1 8.
Channel faders
Channel level to master
19.
ASSIGN rotary
Crossfader channel select
20.
PUNCH buttons
Momentary crossfade defeat
21.
CROSSFADER
Mix between 2 channels
