Sida 1/9
Scan for Specications
USER
GUIDE
CUBE
Keep this manual for future reference © 2024 Coastal Source
1
Features & Benets
2
Specications
1
Cabling Rules
1
Subwoofer Placement
4
Connect the Plug+Play™ Connector
6
Top Installation
7
Placement
1
Wiring Installation
1
Sound Tuning
2
Warranty Information
1
Connecting the Plug+Play™ Connector
1
Setup & Installation Guidelines
5
Phase Inversion
TABLE OF
CONTENTS
INSTALLATION INSTRUCTIONS
CUBE Subwoofer User Guide | coastalsource.com 1
FEATURES & BENEFITS
• Coastal quality powerful and extended bass from a compact, 17” cube.
• Designer-friendly conguration that allows for customization with a selection of drop-in natural stone tops or the ability to have our
contractor make a drop in that matches your decking or other desired nish.
• Proprietary 10” high-power down-ring subwoofer driver.
• (2) Stone Top options (Crosscut Travertine or Brown Granite).
• Rotomold composite weather resistant color-through enclosure.
• Integrated rubber feet for vibration isolation.
CUBE
WIRING INSTALLATION
All Coastal Source speakers feature our patented Coastal
Connector™ for a waterproof direct burial connection. For
connecting to a Coastal Source amplier, just select the
appropriate Uni-Connect 8C 16AWG cable lengths and Plug+Play™
the speakers to the amplier. For situations where 3rd party
speaker wire must be used, Coastal Source splice kits are
available to adapt the Uni-Connect 8C 16AWG connections on the
speaker to more conventional speaker wire.
CABLING RULES
This speaker is designed for use with Uni-Connect 8C 16AWG
cables and has (1) Uni-Connect 8C input connection.
Uni-Connect 16 AWG cables can be run a maximum distance of
300’ total without any signicant degradation of performance.
If longer lengths are required, please contact Coastal Source.
Coastal Source systems ship preset for typical applications.
Adjustments should only be made by certied dealers.
CONNECTING THE PLUG+PLAY™
CONNECTOR
Align key-way of cable to key-way of connector and fully insert
cable into connector. Carefully rotate the covering nut until nger
tight.
If covering nut is cross-threaded, reverse rotation and carefully
align the nut to re-thread.
SOUND TUNING
Note that optimal sound tuning is subjective and specic to
each listener so there are no hard and fast rules for optimizing
the sound of a Coastal Source system. We have designed with
exibility to allow you to shape the sound to your personal
preferences. The following information is offered as a brief guide.
It is highly recommended to take the time to experiment and tune
the system to achieve your desired sound.
NOTE: Coastal Source outdoor audio systems are the clearest
and most efcient on the market, but they are not designed to
run at 100% volume full-time. If the system is going to be played
at loud volumes for an extended period of time, Coastal Source
recommends setting the volume to 75-80%.
SUBWOOFER PLACEMENT
For hardscape applications, the integrated rubber feet
provide isolation to prevent rattling.
Since very low frequencies are omni-directional placement
is less critical, but experimenting with placement is still
recommended since proximity to walls and corners will
have a signicant effect on the bass output.
Open area
Less bass response
Near a wall surface
Heavy bass response. Low frequencies gather in corners
and travel better though surfaces like the ground or walls
than the air.
SETUP & INSTALLATION GUIDELINES
Spacing Guidelines
Maximum distance between speakers: 40’
Minimum distance between speakers: 12’
Speaker Coverage Guidelines
Each CUBE subwoofer can cover 100-400 sqft of
listening space.
Phase Inversion
The CUBE comes with a phase inversion switch (see
below). Once the speaker is placed in its intended location,
experiment with the Phase Inverter and listen to the sound
in both settings. Choose the setting that sounds best.
