Sida 1/3
V750 GOLD - V2
MPY-750V-AFBAG
POWER UP
The V Gold - v2 offers the high quality user experience you’ve
always wanted. Enjoy an 80 Plus Gold efficiency rating, full-
modular cabling, semi-fanless operation, a 135mm FDB fan,
16AWG PCIe high efficiency cables, and a 10 year warranty.
Improvements and innovations from the components to the
cables deliver a power supply unit fit for any and every type of
PC. The 100% Japanese capacitors, half-bridge LLC resonant
convertor, and DC-DC circuitry deliver a product that even the
pros can respect, at 550, 650, 750, and 850 watt levels. Now
available with white casing and cables.
FEATURES
SPECIFICATIONS
80 PLUS Gold Certified : This certification guarantees a typical
efficiency of 90% under normal operating conditions.
Performance Driven Topology : The half-bridge LLC resonant
converter and DC-DC technology offer reliable and stable voltage
outputs for safer, more reliable performance and higher efficiency.
Semi-Fanless Mode with Hybrid Switch : The 135mm FDB fan is
semi-fanless up to 40% load and can be manually turned off with a
hardware based hybrid switch.
Full-Modular Cabling : Modular cables reduce clutter, increase airflow,
and improve overall efficiency and thermal performance.
16 AWG PCI-e Cables : The thicker 16 AWG PCI-e cables allow for
higher currents, thereby improving both efficiency and safety.
10 Year Warranty : This unit comes with a standard limited
manufacturing warranty of 10 years from the date of purchase.
PACKAGE INFORMATION
Cable Type
EAN
UPC
US
4719512091555
884102063978
UK
4719512091562
884102063985
EU
4719512091579
884102063992
ST
4719512091586
884102064005
AU
4719512091593
884102064012
BR
4719512091609
884102064029
KR
4719512091616
884102064036
TW
4719512091623
884102064043
JP
4719512091630
884102064050
IN
4719512091647
884102064067
WO
4719512091654
884102064074
Nett Weight
2.12 kg / 4.674 lb
Gross Weight
2.65 kg / 5.842 lb
Package Dimensions
303 x 202 x 125mm (11.93 x 7.95 x 4.92")
Carton Dimensions
520 x 318 x 238mm (20.47 x 12.52 x 9.37")
Unit / Carton
4 pcs
Carton / Pallet
24 pcs
Product Name
V750 Gold - v2
Item Code
MPY-750V-AFBAG
ATX Version
ATX 12V Ver. 2.52
PFC
Active PFC
Input Voltage
100-240V
Input Current
10-5A
Input Frequency
50-60Hz
Dimensions (L x W x H)
160 x 150 x 86mm
Fan Size
135mm
Fan Bearing
FDB
Fan Speed
1545 RPM
Noise @ 20%
0 dBA
Noise @ 50%
23.6 dBA
Noise @ 100%
32.5 dBA
Efficiency
90% @ Typical Load
80 PLUS Rating
80 PLUS Gold
ErP 2014 Lot 3
Yes
Power Good Signal
100-500ms
Hold Up Time
17ms
MTBF
>100,000 hours
Protections
OVP / OPP / SCP / OCP / UVP / OTP
Regulatory
CCC, CE, TUV-RH, RCM, EAC,
cTUVus, FCC, BSMI, KC, CB
Connectors
ATX 24 Pin
x1
1 × 650mm
EPS 4+4 Pin
x1
1 × 650mm
EPS 8 Pin
x1
1 × 650mm
SATA
x12
3 × 500(s)+120(s)+120(s)+120(s)
mm
Peripheral 4 Pin
x4
1 × 500(p)+120(p)+120(p)+120(p)
mm
PCI-e 6+2 Pin
x4
2 × 550+120mm
AC INPUT
100-240V~ 10-5A 50-60Hz
DC OUTPUT
+3.3V
+5V
+12V
-12V
+5Vstb
20A
20A
62A
0.3A
3A
TOTAL POWER
130W
744W
3.6W
15W
750W
FEATURES
This certification guarantees a typical
efficiency of 90% under normal operating
conditions.
The half-bridge LLC resonant converter
and DC-DC technology offer reliable and
stable voltage outputs for safer, more
reliable performance and higher efficiency.
The 135mm FDB fan is semi-fanless up to
40% load and can be manually turned off
with a hardware based hybrid switch.
Modular cables reduce clutter, increase
airflow, and improve overall efficiency and
thermal performance.
The thicker 16 AWG PCI-e cables allow
for higher currents, thereby improving both
efficiency and safety.
This unit comes with a standard limited
manufacturing warranty of 10 years from
the date of purchase.
