Sida 1/10

K100 RGB

WEB: corsair.com

PHONE: (888) 222-43 46

SUPPORT: support.corsair.com

BLOG: corsair.com/blog

FORUM: forum.corsair.com

YOUTUBE: youtube.com/corsairhowto

logo are registered trademarks in the United States and/or other countries. All

other trademarks are the property of their respective owners. Product may vary

slightly from those pictured. 49-001877 AB

Optical-Mechanical Gaming Keyboard

K100 RGB

1 2

GETTING TO KNOW YOUR KEYBOARD

To clear the onboard memory, hold the ESC key while plugging in the USB keyboard connector (S then T),

then release the ESC key after two seconds. The keyboard will then power on normally and be reset to

factory defaults.

FACTORY RESET

SOFTWARE MODE

HARDWARE MODE

Install iCUE on a Windows

PC to connect all of your CORSAIR iCUE compatible

products together in a single interface, giving you complete control of everything from

lighting to powerful macros. Download iCUE from www.corsair.com/downloads.

Additionally, install the Stream Deck software to program the macro keys (A) to take

command of your stream through powerful integrations with OBS Studio, Twitch

™

Twitter, and more. Download Stream Deck from ww w.elgato.com/gaming/downloads.

With iCUE and the new dynamic prole system, you can create as many custom proles

as you want that t onto the 8MB of onboard storage. Each prole can store backlighting

effects (up to 20 layers), actions & macros, settings, and wheel modes.*

*The number of lighting effects layers per prole and number of proles that can be saved to

onboard storage and will vary based on complexity.

When iCUE is running the keyboard operates in software mode and is controlled by iCUE.

When iCUE is not running or the keyboard is connected to a device that does not support iCUE, the

keyboard operates in hardware mode which uses proles and settings saved to the onboard storage.

Connect both keyboard USB connectors (S, T) to available USB 3.0 or better Type-A ports on your Windows

PC, Apple Mac

, or Microsoft Xbox One

*www.corsair.com/xbox-one-suppor t

SETTING UP YOUR KEYBOARD

ENGLISHENGLISH

A — SIX PROGRAMMABLE MACRO G-KEYS

B — PROFILE SWITCH KEY

C — iCUE CONTROL WHEEL

D — WHEEL KEY

E — WINDOWS LOCK KEY

F — MACRO, MUTE, and WIN LOCK INDICATORS

G — NUM, CAPS, and SCROLL LOCK

INDICATORES

H — PBT DOUBLE-SHOT KEYCAP SET

I — MUTE KEY

J — VOLUME ROLLER

K — DEDICATED MULTIMEDIA KEYS

L — MAGNETIC DETACHABLE CUSHIONED

LEATHERETTE PALM REST

M — 11-ZONE RIGHT LIGHTEDGE

N — 22-ZONE REAR LIGHTEDGE

O — USB 2.0 PASS-THROUGH PORT

P — 11-ZONE LEFT LIGHTEDGE

Q — FPS AND MOBA KEYCAP SETS

R — KEYCAP PULLER

S — USB KEYBOARD CONNECTOR

T — USB PASS-THROUGH CONNECTOR

TSO

M PN

QF G H I J KB ECA D

3 4

ENGLISHENGLISH

With iCUE you can enable additional wheel modes or create your own with commands for

games, applications, other media players, and more, then save them to onboard storage.

With iCUE you can program vivid and dynamic custom lighting effects, then save them

to onboard storage.

With iCUE you can edit the macros you’ve recorded onboard or create more complex

macros with additional actions and functions, then save them to onboard storage.

Pressing the wheel key (D) cycles through available wheel modes with the color changing to indicate the

current mode. After selecting a mode, rotate the wheel (C) left and right to adjust mode settings.

Keyboard lighting effects can be controlled via the below onboard shortcuts without iCUE.

Macros can be recorded at any time via onboard commands. In hardware mode macros are recorded to the

onboard storage prole and in software mode macros are recorded to your iCUE prole.

To record a macro:

1) Go to the Macro Record wheel mode

2) Hold the wheel key (D) until the macro indicator (F) lights up

3) Press the macro G-key to be programmed

4) Press the keys you wish to record (recording starts after the rst key press)

5) Press the same macro G-key again from step 3 to save (or hold the wheel key to cancel)

When macro recording is completed or cancelled, the macro indicator will turn off.

iCUE CONTROL WHEEL ONBOARD LIGHTING

MACRO RECORDING

The following modes are available in hardware mode:

WHEEL MODE COLOR ROTATE WHEEL LEFT ROTATE WHEEL RIGHT

Brightness Decrease Brightness Increase BrightnessCyan

Track Jogging* RewindGreen Fast Forward

Track Selector White Last Track Next Track

Macro Recording Red See macro recording section below

*Track jogging works in Spotify

, Apple iTunes

, and select other media players when the application window is

in focus.

SHORTCUT LIGHTING EFFECT

Spiral Rainbow

Rain

Rainbow Wave

Visor

Type Lighting

(Per-key)

Type Lighting (Ripple)

Color Shift

Color Pulse

Color Wave

Static Color (Press to

cycle colors)

SHORTCUT FUNCTION

Reset to onboard

stored effect

Reduce effect speed*

Increase ef fect

speed*

Rotate effect left*

Rotate ef fect right*

*Functions supported on select effects.

Produktspecifikationer

Varumärke:	Corsair
Kategori:	Tangentbord
Modell:	K100 RGB
Gränssnitt:	USB
Material:	Gjuten aluminium
Typ av bakgrundsbelysning:	RGB LED
Rekommenderad användning:	Spela
Bakgrundsbelysning:	Ja
Inbyggd minneskapacitet:	8000 KB
Tangentbordslayout:	AZERTY
Programmerbara snabbtangenter:	Ja
Handledsstöd:	Ja
Inbyggt minne:	Ja
Anti-ghosting:	Ja
Produktens färg:	Svart
Antal produkter som medföljer:	1 styck
Numeriskt tangentbord:	Ja
Strömkälla av typen:	USB
Antal tangenter:	111
Tangentbordsspråk:	Fransk
Justerbar bakgrundsbelysning:	Ja
Manual:	Ja
Tangentbordets formfaktor:	Fullstor (100 %)
Tangentbordsstil:	Rak
Tangentbordsknapparnas livstid:	100 miljoner tecken
Tangentbordsvikt:	1350 g
Tangentteknik:	Mekaniska tangentbrytare
Snabbknappar:	Ja
Multimediatangenter:	Ja
Flertangentsregistrering (rollover):	N-tangent rollover
Tangentnedslagshöjd:	1.2 mm
Tangentbordstangentens switch-teknologi:	Cherry MX Speed
Antal kortkommandon:	6
