Sida 1/7

and/or other countries. All other trademarks are the property of their respective owners. Product may vary slightly from those pictured. Document Number: 49-001273 rev AA

47100 Bayside Parkway • Fremont • California • 94538 • USA

USA and CANADA: (800) 205-7657 INTERNATIONAL: (510) 657-8747 | FAX: (510) 657-8748

corsair.com

FORUM: forum.corsair.com

TWITTER: twitter.com/corsairmemory

PSU PAGE: corsair.com/powersupplyunits

EMAIL: support@corsair.com

FACEBOOK: facebook.com/corsair

BLOG: blog.corsair.com

RMx User Manual

Part Number: 49-001273 Rev AA

Material: Stock100# Matrix Dull White Text

Date: May 26 2015

Final Spread Trimmed Size: W: 11 inches & H:8.5inches

Final Folded Size: W: 5.5 inches & H: 8.5inches

BLACK

HIGH PERFORMANCE ATX POWER SUPPLY

MANUAL • MANUEL • MANUALE • MANUELLE • MANUAL DE

РУКОВОДСТВО • MANUAL • 用户手册 • 取扱説明書 • 사용설명서

RM550x

RM750x

RM850x

RM1000x

RM650x

English 1

Français 17

Deutsch 33

Italiano 49

Español 65

Россию 81

Português 97

中国 113

日本の 129

한국어 145

corsair.com

1 2

RMx SERIES

™

RMx SERIES

™

Product Speciﬁcations

RMx ........................ 

RMx .......................... 

RMx .......................... 

RMx .......................... 

RMx ........................ 

Installation .................. 

Warranty ..................... 

SafetyandAgency

Approvals .................... 

Congratulations on the purchase of your new Corsair

RMx Series High Performance ATX power supply.

Corsair RMx Series enthusiast power supplies are optimized for silence,

with a custom fan design and Zero RPM Fan Mode. 80 PLUS Gold rated

eciency ensures low-cost operation, and the fully modular black

cables allow for fast, neat builds. All Japanese 105°C capacitors make

it a great choice for high performance PCs where reliability is essential.

Safety and protection

• Over-voltage protection (OVP)

Over-voltage protection for the 12V, 5V and 3.3V DC outputs

is required to comply with the ATX speciﬁcation. OVP shuts

down the PSU in the event that the DC outputs exceed a set

level, determined by the PSU manufacturer. The minimum

voltage levels required for compliance are 13.4V for the

+12V rail(s), 5.74V for the +5V rail and 3.76V for the 3.3V rail.

• Over-current protection (OCP)

The RMx Series features OCP on the 3.3V, 5V and 12V rails.

OCP ensures that the output of the DC voltage rails remains

within safe operating limits.

• Over-temperature protection (OTP)

OTP ensures that the PSU will shut down when the internal

temperature reaches a set point. This is usually as a result

of internal current overloading or a fan failure.

• Short-circuit protection (SCP)

A short-circuit is deﬁned as any output impedance of less than

0.1 ohms. Amongst other things, SCP ensures that the PSU shuts

down should the 3.3V, 5V and 12V rails short to any other rail, or to

ground. It also ensures that no damage should occur to the unit, or

your PC’s components in the event of a short.

Produktspecifikationer

Varumärke:	Corsair
Kategori:	Dator strömförsörjning
Modell:	RM1000x
Typ av operation:	Draaiknop
Färg på produkten:	Wit
Vikt:	2003 g
Bredd:	38 mm
Djup:	54 mm
Höjd:	105 mm
Kraftkälla:	AC
Beeldscherm:	Nee
Korrekt användning:	Room
Gränssnitt:	AC
Minnesfunktion:	Nee
Medeltid mellan fel (MTBF):	100000 h
Internt kylsystem:	Ja
Fjärrkontroll ingår:	Nee
AC-ingångsspänning:	230 V
AC-ingångsfrekvens:	50 Hz
Antal enheter som stöds:	1
Smart termostat:	Nee
Temperaturbörvärdesområde:	0 - 90 °C
Manuell temperaturkontroll:	Ja
Kombinerad effekt (-12V):	9.6 W
EPS-version:	2.92
Maximal kopplingsspänning:	230 V
Maximal kopplingsström:	16 A
Produktens färg:	Svart
Förpackningstyp:	Låda
Hållbarhetscertifiering:	RoHS
AC-inspänning:	100 - 240 V
Fläktdiameter:	135 mm
Växelström Frekvens:	47 - 63 hz
ATX-version:	2.4
Antal fläktar:	1 fläkt/-ar
Ändamål:	PC
Total effekt:	1000 W
Periferiska (Molex) strömkontakter (4-pin):	12
Antalet SATA strömkontakter:	11
Kombinerad effekt (+3,3 V):	150 W
Kombinerad effekt (+12 V):	1000 W
Kombinerad effekt (+5 V):	150 W
Max utström (+3,3 V):	25 A
Max utström (+12 V):	83.3 A
Max utström (+5 V):	25 A
Max utström (-12V):	0.8 A
Max utström (+5 VSB):	3 A
Strömförsörjningsenhet formfaktor:	ATX
Moderkort strömkontakt:	24-pin ATX
CPU strömkontakt (4 +4 pin):	Ja
Typ av kablage:	Helt modulär
80 plus-certifiering:	80 PLUS Gold
Kullagertyp:	Rifle
Fan plats:	Övre
Kombinerad effekt (+5 VSB):	15 W
Diskettenhet strömkontakt:	1
