Sida 1/2

M A R S

G A M I N G D E S K

ASSEMBLY DRAWING

COUGAR MARS gaming desk provides ergonomic design and generous gaming space with dazzling

RGB lighting eﬀects for enhancing your superior gaming experiences.

Itʼs how we make your gaming dreams come true and present a unique gaming desk for you!

Enormous and Ergonomic Gaming Space

The spacious gaming surface with carbon ﬁber texture brings you plenty of space for your gaming

monitors, gaming keyboards, and other gaming gears. Highly ergonomic designs like curved edges

and rounded corners give you better and more comfort gaming experience.

Multifunction Designs

With control stands, you can easily control PC and connect USB/audio devices conveniently. COUGAR

Mars maximizes your gaming experience.

Dual-sided RGB Lighting Eﬀects

In order to increase more immersive feeling in your gaming atmosphere. MARS provides various RGB

lighting eﬀects. It is also compatible motherboardsʼ 5V connection with Asus Aura Sync, Gigabyte RGB

Fusion, MSI Mystic Light Sync, and ASRock Polychrome Sync for system-wide lighting synchronization.

High-strength Welded Steel Frame for Maximum Stability

COUGAR Mars is made of high-strength steel frame for maximum stability. The height of the gaming

desk is manually adjustable between three levels (75/80/85 CM) for the most comfortable position.

•DesignDiseño ergonómico de bordes curvos y esquinas redondeadas.

•Wing Ala lateral doble: RGB efectos de retroiluminación.

•Soporte para conexiones de placa madre de 5V RGB (ASUS, ASRock, Gigabyte o MSI).

•USB3.0 pass-through p1-x2 y conectores de audio.

•PowerEl poder de la PC, la función de restablecimiento son fácilmente accesibles en el panel de control.

•Adjustment Ajuste de altura de la mesa (75/80/85 CM).

•Diseño de superficie de carbono.

•Frame Bastidor de acero soldado de alta resistencia para una máxima estabilidad.

ESPAÑOL

•Edges Design de bordas curvas ergonómicas e cantos arredondados.

•SideA asa lateral dupla: RGB efeitos de luz de fundo.

•Suporte para conexões de placa-mãe de 5V RGB (ASUS, ASRock, Gigabyte ou MSI).

•USB3.0 pass-through p1-x2 e tomadas de áudio.

•PowerPC poder, função de reset são facilmente acessíveis no painel de controle.

•Adjustment Ajuste de altura do desktop (75/80/85 CM).

•Design de superfície de carbono.

•Estrutura de aço soldada de alta resistência para máxima estabilidade.

PORTUGUÊS

•Design ergonomico dei bordi curvi e angoli arrotondati.

•Ala laterale doppia: RGB effetti di retroilluminazione.

•Supporto per connessioni della scheda madre RGB 5V (ASUS, ASRock, Gigabyte o MSI).

•USB3.0 pass-through p1-x2 e prese audio.

•La potenza del PC, la funzione di reset sono facilmente accessibili sul pannello di controllo.

•Regolazione altezza del frontalino (75/80/85 CM).

•Carbonlike Surface Design.

•Telaio in acciaio saldato ad alta resistenza per la massima stabilità.

ITALIANO

•Ergonomic curved edges design and rounded corners.

•Dual side wing: RGB backlight effects.

•Support for 5V RGB motherboard connections (ASUS,ASRock,Gigabyte or MSI).

•USB3.0 pass-through p1-x2 & Audio Jacks.

•PC's power, reset function are easily accessible on control panel.

•Desktop height adjustment (75/80/85 CM).

•Carbonlike Surface Design.

•High-strength welded steel frame for maximum stability.

ENGLISH

ACCESSORY KIT

10 12

6 7 8

2 3 4

• Height Adjustment:

MARS gaming desk has three adjustment options: 75cm – 80cm – 85cm

(desktop to ground).

To strengthen the stability, please fasten TWO screws on each side.

80cm

85cm

75cm

C D

• Please follow this step to assemble two sets.

Desk Dimension

Desk Height

I/O Panel

Model No.

Product Name COUGAR MARS Gaming Desk

CGR-MARS

153.3 (W) x 77.1 (D) mm / 60.4 (W) x 30.4 (D) inch

Three adjustment :

75 / 80 / 85 (H) cm

29.5 / 31.5 / 33.5 (H) inch

USB 3.0 x 2 / Audio Jacks x 2 /

Power button / Reset button / RGB button

SPECIFICATIONS

год и месяц изготовления продукции указаны в серийном номере продукта.

(существует 2 способа определения даты изготовления, оба способа описаны ниже)

После S/N: первые две цифры означают год, вторые две – месяц изготовления.

Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702

После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,

и означают год, последующие две цифры – месяц изготовления.

Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02

●

Например, AG = 17 = 2017 год

ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ

A B C E F G H I JD

1 3 4 5 6 7 8 9 02

x44

Position and do not tighten

the screws.

When the control stands are uneven on the

gaming desk, they will be automatically

corrected when locking the screws.

To avoid the screw bosses are damaged,

please do not lock the screws too tight.

Position and do not tighten

the screws.

Make sure the 16 screws are positioned

and then lock solidly truly.

Spare parts :

1 2

x 2

16 Screws

POWER SW

RESET SW

Produktspecifikationer

Varumärke:	Cougar
Kategori:	Byrå
Modell:	Mars
Vikt:	40280 g
Bredd:	1533 mm
Djup:	771 mm
Höjd:	750 mm
Förpackningens bredd:	930 mm
Justerbara fötter:	Ja
LED-bakgrundsbelysning:	Ja
Korrekt användning:	Spela
Ramfärg:	Svart
Modell:	Rak
Ergonomisk design:	Ja
Förpackningsvolym:	45100 cm ^
Produktens färg:	Svart
Låddjup:	850 mm
mönster:	Kolfiber
Ram material:	Kolfiber
Höjdjustering:	Ja
Höjdjusteringsintervall:	750 - 850 mm
Bordsskiva form:	Rektangulär form
Material, bordsskiva:	Träfiberplatta
Bordsytans färg:	Svart
