Sida 1/2

FEATURES

Assembly Drawing

Power button / RGB button

2.5" HDD/SSD trays

USB 3.0 / USB 2.0 / HD audio ports

Slot covers

Front panel

Air filter for top panel

Tempered glass side panel

Air filter for front panel

Right side panel

Air filter for bottom panel

Specifications might vary depending on the country or region of sale.

Installing the Front I/O Connectors

Strength and Sturdy

MX440-G RGB s front panel features bold lines and rugged structures. It is the chassis that 

brings the new concept of strength and sturdy to the gaming world. Moreover, the tempered



Incredible RGB Lighting



that we have preset for you with the dedicated RGB button.

Massive Tempered Glass Left Panel

With the full-length PSU cover hides cables and a massive tempered glass left panel presents

a clean and tidy build, you can easily build a pro-level system.

Wider but More Compact and Powerful

MX440-G RGB s 215mm width allows much larger interior space with better cooling 

performance and cable management. However, its compact exterior dimension takes



320mm-length Graphic card, four 2.5 SSDs, and two 3.5 HDDs, which allow you to 

achieve the extreme operation and abundant storage space.

Sufficient for Multiple USB Devices



connect multiple peripheral devices and accessory charging. Not only optimize your processing

experiences, but also keep all USB devices without limitations.

Strong Cooling Performance



water cooling radiator, and high-end cooling components. It helps you to protect critical

components from overheating.

3.5" HDD cage (compatible for 2.5" HDD/SSD)

2 x 120mm fans for top panel (optional)

3 x 120mm / 2 x 140mm fans for front panel

(3 x 120mm ARGB Fans pre-installed)

120mm / 140mm fan for rear panel (optional)

• Included three ARGB fans at the front panel with variant RGB

lighting modes

• Massive tempered glass left panel

• Support for up to six fans and a 360mm radiator

• Support for up to 320mm long graphics cards

• Support for two 3.5" HDDs and four 2.5" SSDs

ENGLISH

• Enthält drei ARGB-Lüfter an der Vorderseite mit verschiedenen

RGB-Beleuchtungsmodi

• Linker Abdeckung aus massivem gehärtetem Glas

• Unterstützt bis zu sechs Lüfter und einen 360-mm-Kühlkörper

• Unterstützt Grafikkarten mit einer Länge von bis zu 320 mm

• Unterstützt 2 3,5" Zoll-Festplatten und 4 2,5" Zoll-SSDs

DEUTSCH

• Incluye tres ventiladores ARGB en el panel frontal con

diferentes modos de iluminación RGB

• Panel izquierdo de vidrio templado

• Soporta hasta 6 ventiladores y un radiador de 360mm

• Soporte para tarjetas gráficas de hasta 320mm de largo

• Soporte para 2 HDD de 3.5" y 4 SSD de 2.5"

ESPAÑOL

•

Zawiera trzy wentylatory ARGB na przednim panelu z różnymi

trybami oświetlenia RGB

•

Lewej pokrywie z litego szkła hartowanego

•

Obsługa maksymalnie 6 wentylatorów i radiatora do 360 mm

•

Możliwość montażu kart graficznych o długości do 320 mm

•

Obsługa 2 dysków twardych 3,5" i 4 SSD 2,5"

POLISH

• Inclui três ventoinhas ARGB no painel frontal com modos de

iluminação RGB variantes

• Painel lateral esquerdo em vidro temperado

• Suporta até 6 ventoinhas e radiador de 360mm

• Suporta placas gráficas de até 320mm

• Suporta até 2 HDDs de 3.5" e 4 SSDs de 2.5"

PORTUGUÊS

РУССКИЙ

• Включены три вентилятора ARGB на передней панели с

различными режимами освещения RGB

• массивной левой панелью из закаленного стекла

• Поддержка до шести вентиляторов и 360-мм радиатора

• Поддержка видеокарт длиной до 320 мм

• Поддержка двух 3.5-дюймовых жестких дисков и четыре

2.5-дюймовых SSD

• Inclus trois ventilateurs ARGB sur le panneau avant avec

différents modes d'éclairage RVB

• Un capot gauche en verre trempé massi

• Prend en charge jusqu'à 6 ventilateurs et un radiateur de 360 mm

• Prend en charge les cartes graphiques jusqu'à 320 mm de longueur

• Prise en charge de 2 disques durs 3,5" et 4 SSD 2,5"

FRANÇAIS

• ARGB前面板3个风扇预设多种灯效模式

• 全透钢化玻璃左侧盖

• 360mm最高可支援6个风扇与的水冷散热器

• 320mm支援长达的显示卡

• 支援2个 3.5" HDD硬碟与4个 2.5" SSD硬碟

中文

• ARGB RGB󴳞󴳶󴳼󴳑󴳚󴳖󴳴󴱶3󴱯󴱹 󴳞󴲪󴳼󴲝󴱢󴰾 󴳫󴴅󴳒󴲝

• PC󴲵󴳲󴳂󴲯󴲬󴳼󴳒󴲯󴱲 󴱹󴱗󴱓󴲖󴱹󴱲󴱹󴳚󴴅󴳍󴲝󴱘󴱱󴲉󴱤

• 6󴱹󴳞󴲪󴳼󴱳 󴱹󴳲󴳁󴲱󴴅󴳈󴴅󴲝󴱲󴱘󴰾󴲗󴱪󴲝360

󴱢󴲉󴱤

• 320mm 󴲹󴳲󴳞󴲬󴳌󴲸󴲴󴴅󴳒󴱶󴱲󴱘󴲉󴱤

• 2 2.5" SSD󴱯󴱹 󴱯󴱹3.5"󴱹HDD󴱳4󴲝󴱲󴱤

日本語

• 전면 패널에 다양한 RGB 조명 모드를 갖춘 3 개의 ARGB 팬 포함

• 강력한 강화 유리 좌측 덮개가 있는

• 최대 6 개의 팬 및 360mm 라디에이터 지원

• 최대 320mm의 긴 그래픽 카드를 지원

• 3.5" HDD 2개와 2.5" SSD 4개

한국어

Case Form Factor

Dimension

Motherboard Type

I/O P anel

Case Drive Bays

Expansion Slots

Model Name

Cooling Fan Support

Water Cooling Radiator Support

Maximum Number of Fans

Max. Graphics Card Length

Max. CPU Cooler Height

Max. PSU Length

320mm / 12.6inch

Transparent Left Panel 4mm Tempered Glass

170mm / 6.7inch

150mm / 5.9inch

MX440-G RGB

Model No.

CGR-56C2B-G-RGB

Mid Tower

215 (W) x 505 (H) x 424 (D) mm / 8.5 (W) x 19.9 (H) x 16.7 (D) inch

Mini ITX / Micro ATX / ATX

USB 3.0 x 2 , USB 2.0 x 1 , Mic x 1, Audio x 1 , RGB Button

3.5 " : 2

2.5 " : 4 + 1 (converted from 3.5" drive bays) / (2 SSD trays included)

Front : 120mm x 3 / 140mm x 2 (120mm ARGB Fans x 3 pre-installed)

Rear : 140mm / 120mm

Top : 240mm / 120mm

Front

: 360mm / 280mm / 240mm / 140mm / 120mm

6 Max.

Top : 120mm x 2

Rear : 120mm x 1 / 140mm x 1

MX440-G RGB s iconic sturdy and solid style. With 

included three ARGB fans, the tempered glass front panel showcases stunning lighting

view. Besides, it has wide and powerful interior spaces, which allows you to have

hardware expandability, high cooling per formance, and abundant storage space.

USB 3.0 HD AUDIO POWER SW

HD AUDIO

POWER SW

POWER LED

POWER LED +

POWER LED

USB3.0

USB 2.0

USB

H.D.D LED

RGB

M X 4 4 0

GLOBAL WARRANTY POLICY

WARRANTY PERIODS OF COUGAR GAMING DEVICES

Product : COUGAR MX440-G RGB

Warranty : 1 Year

●

This warranty gives you specific legal rights. You may also have other rights granted under local law. These rights may vary.

●

Only for electrical components.

ACCESSORY KIT

год и месяц изготовления продукции указаны в серийном номере продукта.

(существует 2 способа определения даты изготовления, оба способа описаны ниже)

После S/N: первые две цифры означают год, вторые две – месяц изготовления.

Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702

После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,

и означают год,

последующие две цифры – месяц изготовления.

Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02

●

Например,

AG = 17 = 2017 год

ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ

A B C D E F G H I J

123456 8907

БЪЛГАРИЯ

• Подробни инструкции за употреба изтеглете от: https://cougargaming.com/bg

България QR код

X 20Fan screws

X 82.5”HDD / SSD EVA washers

X 29Motherboard screws and 2.5" SSD screws

X 4Power supply screws

X 3Stand-off

3.5" HDD screws X 8

Cable ties X 5

Installing water cooling radiators & cooling fans

Installing the 2.5

SSDs

Removing side panels

2 31

Installing the 3.5

HDDs

Compucase Enterprise Co.,Ltd.

No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C

Tel:+886-6-356-0606

Service E-Mail:service@cougargaming.com

COUGAR USA Technical Service

Tel: (833) 256-3778

Mail: rma@compucaseusa.com

https://cougargaming.com/support/contact/upload/

For more information, please visit

Compucase Enterprise Co.,Ltd.

www. coug arga ming .com

Made in China

120140240280360

120

240

140

120140

120

140

(Top)

1(Front)

(Rear)

LEFT

RIGHT

LEFT

RIGHT

2 3

RIGHT

LEFT

Connectors

Installing PCI-E cards

Support for graphics card up to 320mm-long

RIGHT

A. Please lift up the tempered glass panel

from the bottom left notch.

B. When lifting up the tempered glass panel,

please hold it carefully with your other hand.

2.5" HDD / SSD EVA washers

X 8

※

Please stick EVA washers on SSD holes before

installing 2.5" SSD.
