Sida 1/2
Installing the Front I/O Connectors
FEATURES
Assembly Drawing
●
Подробни инструкции за употреба
изтеглете от:https://cougargaming.com/bg
БЪЛГАРИЯ
България QR код
ENGLISH
●
Transparent acrylic front panel
●
Massive tempered glass left side panel
●
Support for up to E-ATX motherboard
●
Support for up to a 360mm water cooling radiator and eight fans
●
Support for up to 410mm graphics cards
●
Support for vertical GPU
●
Support for two 3.5" HDDs and five 2.5" SSDs or seven
2.5" SSDs.
POLISH
●
Przezroczysty, akrylowy panel przedni
●
Lewy panel ze szkła hartowanego
●
Obsługa płyt głównych do E-ATX
●
Obsługa chodnicy wodnej o szerokości do 360 mm i ośmiu wentylatorów
●
Obsługa kart graficznych o długości do 410 mm
●
Obsługa procesora graficznego montowanego pionowo
●
Obsługa dwóch dysków twardych 3.5" HDD i pięciu dysków
2.5" SSD lub siedmiu dysków 2.5" SSD
ITALIA
●
Pannello anteriore in acrilico trasparente
●
Pannello sinistro in vetro temperato massiccio
●
Supporto fino a una scheda madre E-ATX
●
Supporto per un radiatore per raffreddamento ad acqua fino
a 360 mm e otto ventole
●
Supporto per schede grafiche fino a 410 mm
●
Supporto per GPU verticale
●
Supporto per due HDD da 3,5" e cinque SSD da 2,5" o sette
SSD da 2,5"
PORTUGUÊS
●
Painel frontal em acrílico transparente
●
Painel esquerdo em vidro maciço temperado
●
Apoio até à placa-mãe E-ATX
●
Suporte para um radiador de arrefecimento a água até 360mm
e oito ventiladores
●
Suporte para placas gráficas até 410mm
●
Suporte para GPU vertical
●
Suporte para dois HDD de 3,5" e cinco SSD de 2,5" ou sete
SSD de 2,5"
РУССКИЙ
●
Прозрачная акриловая передняя панель
●
Массивная боковая панель из закаленного стекла
●
Поддержка всех материнских плат до формата E-ATX
●
Поддержка водяного охлаждения радиатора размером до
360 мм и восьми вентиляторов
●
Поддержка всех видеокарт размером до 410 мм
●
Поддержка вертик ального графического процессора
●
Поддержка двух 3.5-дюймовых HDD и пяти 2.5-дюймовых
SSD или семи 2.5-дюймовых SSD.
DEUTSCH
●
Transparente Acrylfrontblende
●
Linke Blende aus massivem Hartglas
●
Unterstützt Motherboards bis E-ATX
●
Unterstützt einen Wasserkühlkörper bis 360 mm und acht
Lüfterherboard
●
Unterstützt Grafikkarten bis 410 mm
●
Unterstützt vertikale GPU
●
Unterstützt zwei 3,5-Zoll-Festplatten und fünf 2,5-Zoll-SSDs
oder sieben 2,5-Zoll-SSDs
ESPAÑOL
●
Panel frontal de acrílico transparente
●
Panel izquierdo de cristal templado masivo
●
Soporte para la placa madre de hasta E-ATX
●
Soporte para un radiador de refrigeración de agua de hasta
360 mm y ocho ventiladores
●
Soporte para tarjetas gráficas de hasta 410 mm
●
Soporte para la GPU vertical
●
Soporte para dos discos duros de 3,5" y cinco SSD de 2,5"
o siete SSD de 2,5"
FRANÇAIS
●
Panneau frontal en acrylique transparent
●
Panneau gauche en verre trempé massif
●
Prise en charge des cartes mères jusqu'à E-ATX
●
Prise en charge d'un radiateur de refroidissement à eau de
360 mm et de huit ventilateurs
●
Prise en charge des cartes graphiques jusqu'à 410 mm
●
Compatible avec les GPU verticaux
●
Compatible avec deux disques durs de 3,5" et cinq disques durs
de 2,5" ou sept disques durs de 2,5"
●
透明压克力面板
●
全景透视钢化玻璃左侧盖
●
最高支援E-ATX主机板
●
最高支援360mm水冷排与8个风扇
●
最高可安装410mm显卡
●
支援显卡垂直安装
●
支援2个 3.5英寸 HDD硬盘(可转换为2个2.5英寸SSD硬盘)
与5个 2.5 英寸SSD硬盘
中 文
●
투명 아크릴 전면 패널
●
좌측 패널의 크고 단단한 대형 강화유리
●
최대 E-ATX 마더보드 지원
●
최대 360mm 수랭식 라디에이터 및 팬 8개 지원
●
최대 410mm 그래픽 카드 지원
●
수직 GPU 지원
●
3.5" HDD 2개 및 2.5" SSD 5개 또는 2.5" SSD 7개 지원
한국어
●
透明アクリルパネルを装備
●
強化ガラスウィンドウでPCの内部が見えるので内部のパーツを引き立てます
●
E-ATXマザーボードに対応
●
8個のファンと360ｍｍの水冷ラジエーターを装着でき、優
れた放熱効果を確保します
●
最大410mmグラフィックカードに対応できます
●
グラフィックカードを垂直に取付可能
●
3.5"のHDDを2個と2.5" SSDを5個もしくは2.5"SSDを7個搭載可能
日本語
MX660-T
CGR-5BMSB-T
Mid-Tower
213 (W) x 495 (H) x 474 (D) mm
8.4 (W) x 19.5 (H) x 19 (D) in.
Mini ITX / Micro ATX / ATX / CEB / E-ATX
120mm x 1 (RGB fan x 1 pre-installed)
2
120mm x 1 (for HDD Cooling)
8 Max.
*360mm / 280mm / 240mm / 140mm / 120 mm
*360mm / 280mm / 240mm / 140mm / 120 mm
120mm
200 (mm) / 7.9 in.
5+2 (converted from 3.5" drive bays) / (2 SSD trays included)
7+2
*120mm x 3 / 140mm x 2
120mm x 3 / 140mm x 2
USB3.0 x 1, USB2.0 x 2, Mic x 1 / Audio x 1, Reset Button
Model Name
Model No.
Case Form Factor
Motherboard Type
Dimensions (WxHxD)
I/O Panel
3.5" Drive Bay
2.5" Drive Bay
Expansion Slots
Cooling Fan
Support
Water Cooling
Support
Maximum Number of Fans
Max. Graphics Card Length
Max. CPU Cooler Height
Max. PSU Length
* Please choose either of front or top to install a 360mm radiator.
* Top 360mm radiator supports within 30mm thickness.
* Please choose either of a TOP 360mm radiator or FRONT 120mm x 3 fans to install.
Specifications might vary depending on the country or region of sale.
410 (mm) / 16.1 in.
165 (mm) / 6.5 in.
Rear
PSU cover
Front
Top
Rear
Front
Top
C
A
B
P
F
N
I
J
O
H
G
M
K
L
D
E
E
Power button
/ Reset button
A
Removable front panel
C
USB3.0 ,USB2.0
Mic , Audio
B
F
Right side panel
Thumb screws
E
D
Tempered glass
left panel
Slot covers
G
1 x 120mm fan on PSU cover
for HDD Cooling
O
2.5" HDD/SSD trays
H
Air filter at the front
P
3.5" HDD trays (compatible
for 2.5" HDD/SSD)
I
Air filter at the bottom
J
Air filter on the top
L
120mm fan for rear panel
(pre-installed)
M
2 x 140mm / 3 x 120mm fans
K
N
USB 3.0 HD Audio
HD AUDIO
POWER SW
RESET SW
USB3.0
USB 2.0
USB
Power SW Reset SWPower LED
POWER LED
POWER LED
+
-
MX660-T is an upgraded mid-tower case, which continues COUGAR’s iconic style.
The transparent front panel features minimalist style with folding angles. With a crystal
clear tempered glass left panel, you are freely to create a clear view of your computer’s
internal components.
ADVANCED MID-TOWER CASE WITH
COUGAR’S ICONIC DNA
Made in China
For more information, please visit
ww w. co ug argaming.co m
Compucase Enterprise Co.,Ltd.
All rights reserved.
Compucase Enterprise Co.,Ltd.
No. 225, Lane 54, An Ho Road Sec. 2 Tainan,
Taiwan, R.O.C
Tel:+886-6-356-0606
Service E-Mail:service@cougargaming.com
COUGAR USA Technical Service
Tel: (833) 256-3778
Mail: rma@compucaseusa.com
https://cougargaming.com/support/contact/upload/
GLOBAL WARRANT Y POLICY
WARRANTY PERIODS OF COUGAR GAMING DEVICES
Product : COUGAR PC Case
Warranty : 1 Year
This warranty gives you specific legal rights.
You may also have other rights
granted under local law.
These rights may vary.
*only for electrical components
MX660
-
T
Accessory kit
X 5
X 12
Power supply screws
2.5"
HDD
/ SSD EVA washers
X 17
Motherboard
/ SSD screws
Fan screws
(on PSU cover for
HDD cooling)
X 4
X 5
Cable ties
X 5
Stand-off
for motherboard
X 2
Stand-off
for VGA riser cable
