Crux Interfacing Solutions • 21541 Nordhoff St Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.230201
SWRSU-38D
Radio Replacement with
Select Amplied 2017 - Up Subaru Vehicles
Steering Wheel Control Retention for
1 of 2
RAD IO EPL A NT R CE ME
SW RET TIO NC EN
+
R
INTERFACING SOLUTIONS
PRODUCT FEATURES:
PARTS INCLUDED:
SWRSU-38D Module SU-38D Harness Antenna Adapter SWC Cable
INSTALLATION DIAGRAM:
AFTERMARKET
RADIO
4-Pin
Connector
Cap or insulate if
not being used
Kenwood/JVC (BLUE / YELLOW)
Insulate with tape
if not being used
3.5MM SWC CABLE
Plug in the 3.5MM SWC cable to the 4-pin port
on the module. See “DIP SWITCH SETTINGS” section.
ON RADIO VEHICLE
1 2 3 4 5 6 7 8
+12V Constant Yellow
+12V ACC Red
Ground Black
Illuminaon on (+) Orange
Antenna Turn on Blue
Reverse Trigger Purple/White
Right Fron rayt (+) G
Right Fron ray/Blackt (-) G
Le Front (+) White
Le Front (-) White/Black
Right R etear (+) Viol
Right R et/Blackear (-) Viol
Le Rear (+) Green
Le Rear (-) Green/Black
TO FACTORY
HARNESS
12-Pin Black
Connector
Ground
AFTERMARKET
RADIO SELECTOR
(See Page 2)
SUBARU
SWC SETTING
(See Page 2)
ON RADIO VEHICLE
1 2 3 4 5 6 7 8
Rear View Camera Signal Yellow RCA
(Retain OE Camera)
Audio Input Red/White RCA
(Retains Factory AUX Input)
28 PIN
10 PIN
6 PIN
5 PIN
ANTENNA ADAPTOR
(Included in Kit)
5 -Pin OEM
Camera
Connector*
*NOTE: If the factory radio does not
have a 5 pin camera connector, plug
these connectors together to retain
the factory backup camera.
Connector A
- Retains Harman Kardon amplifier
Crux Interfacing Solutions • 21541 Nordhoff St Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.230201
SWRSU-38D
Radio Replacement with
Select Amplied 2017 - Up Subaru Vehicles
Steering Wheel Control Retention for
2 of 2
RAD IO EPL A NT R CE ME
SW RET TIO NC EN
+
R
INTERFACING SOLUTIONS
DIP SWITCH SETTINGS:
SUBARU STEERING WHEEL CONTROL DIP SWI TCH SETTING:
AFTERMARKET RADIO DIP SWI TCH SETTINGS:
RADIO BRAND: DIP: 1 2 3 4
Atoto, Dual, Farenheit, Jensen, Pioneer
Power Acoustik, Soundstream
Alpine
Clarion
Kenwood
JVC
Boss, Old Sony
New Sony
OFF OFF ON ON
OFF OFF ON ON
OFF OFF ON ON
OFF OFF OFF OFF
OFF ON ON OFF
OFF ON ON ON
OFF ON OFF ON
OFF ON OFF OFF
OFF OFF ON OFF
SWC MODULE
ON RADIO VEHICLE
1 2 3 4 5 6 7 8
NOTE:
check the aftermarket radio’s manual to see if the SWC buttons need to be programmed.
3.5MM SWC CABLE
VEHICLE APPLICATIONS:
SUBARU
2018 - 2022
2017 - 2022
2018 - 2022
2018 - 2022 Legacy w/ Harman Kardon Amplier
Outback w/ Harman Kardon Amplier
2018 - 2021 WRX / STi w/ Harman Kardon Amplier
Impreza w/ Harman Kardon Amplier
DIP: 5 6 7 8
#1
#2
ON OFF OFF ON
OFF ON OFF ON
SWC MODULE
ON RADIO VEHICLE
1 2 3 4 5 6 7 8
Subaru
RED to SWC Key 1
WHITE to SWC Key 2
SHIELD to SWC Ground
Note that there are some radios that only have
NOTE: = Phone pick up and hang up buttons will be reversed.
STARLINK RETENTION:
NOTE:
2019 - 2022 Ascent w/ Harman Kardon Amplier
Crosstrek w/ Harman Kardon Amplier
