Sida 1/4
CHRYSLER DODGE
2011 – 201 3004 – 2011 2014 Charger
– 2011 2015 Journey
Uconnect 8.4” Screen / 2 piece radio with 22 -pin connector
UC-2 Interface Module
CH-22 Harness
CH- 22
Harness
rev.052115
UC-2 Interface
Module
Rear-view camera
Rear of
Headunit
Grey female
22- pin connector
Vehicle harness
White female
22- pin connector
Vehicle harness
+12V Rear- view camera (max. 500mA)
Video in Motion selective (optional)
1
continued
DIP Switch Setting
Vehicle/ navigation
DIP 1
DIP 2
DIP 3
DIP 4
DIP 5
DIP 6
Video in- -motion permanent
ON
ON
OFF
OFF
OFF
OFF
Video in- -motion selective*
OFF
ON
OFF
OFF
OFF
OFF
* With DIP 1 set to OFF, the green wire is used to activate selective - - video in motion function.
DIP -2 switch functions of the UC
DIP – 1 Activate Video in Motion
DIP – 2 Activate Rear- view camera
DIP – 3 no function
DIP – 4 no function
DIP CAN – 5 -bus termination resistor on the vehicle side
DIP CAN – 6 - - bus termination resistor on the head unit side
Pin-assignment (8pin Molex)
Cable colour
Pin- No.
Assignment
● Yellow
Pin 4
CAN HIGH - – connection to the head-unit
● Blue
Pin 3
CAN-LOW – - connection to the head unit
●● Yellow/Black
Pin 8
CAN HIGH - – connection to the vehicle
●● Blue/Black
Pin 7
CAN-LOW – connection to the vehicle
● Red
Pin 1
+12V Constant
● Black
Pin 5
Ground
● Green
Pin 6
Activation of the video- - in motion function
(+12V = Video In Motion, only if DIP1=OFF)
● White
Pin 2
Reverse Trigger output (+12V DC 500mA)
(only if DIP2=ON and reverse gear engaged!)
2 / 4
rev.052115
continued
Connect female 8-pin Molex connector of harness CH- -22 to male 8 pin Molex connector of
CAN . Interface
Transfer white female 22-pin connector of vehicle harness from rear of the head-unit into
male white female 22- pin connector of harness CH- . 22
Plug white female 22-pin connector of harness CH- 22 into male 22- pin connector on
the rear of the head- unit.
Transfer grey female 22-pin connector of vehicle harness from rear of the head-unit into
male grey female 22-pin connector of harness CH- . 22
Plug grey female 22-pin connector of harness CH- 22 into male 22- pin connector on
the rear of the head- unit.
3 4 /
Connecting the CAN interface to the factory navigation
rev.052115
CH- 22
Harness
UC-2 Interface
Module
Grey female
22- pin connector
Vehicle harness
White female
22- pin connector
Vehicle harness
Rear of
Headunit
