3. Attaching Foam Pad to Tablet Holder
Gooseneck Chair Clamp
PAD-CHAIRPB - PAD-CHAIRPW
INSTRUCTION - MANUAL
CONTENTS:
INSTALLATION:
888-733-4448
1A. Align the base (A) with
the gooseneck (B).
2A. Align both sides of the hoop (A and C) to the
chairs cylinder.
2B. While holding the (4) Hex Nuts (B) in the back,
align the Washers (F) and the (4) Bolts (D) with the
holes. Use the included Allen Key (G) tool to screw
the (4) Bolts until securely tightened.
1B. While aligned, rotate the goosenecks base
(B) until completely secured.
1C. Rotate butterfly knob to securely fasten
gooseneck (B) to body (A).
1. Connecting Base with Gooseneck
2. Attaching Base to Chair
x1
F
Washer
x4
Hex Nut
x4
E
Bolt
x4
D
Base
A
Outer Clamp
x4
C
Allen Key
x1
GH
2 Keys
x1
B
A
G
E
A
D
F
C
B
A
B
A
A
**Chair shown for
example and NOT included
x1
Gooseneck &
Tablet Holder
B
3A. Select the appropiate foam pad (I) according to the thickness of your tablet (or tablet in
its case), then press adhesive side into center of the tablet holder.
- Use this table to determine the appropiate
foam pad (B) to use with your tablet.
Note:
sizes refer to total tablet size with or
without a case
Tablet Thickness:
Foam Pad
Thickness:
1mm0.67-1.06in / 17-27mm
0.51- 0.91in / 13-23mm
0.31- 0.71in / 8-18mm
5mm
10mm
I
B
1mm
5mm
10mm
Foam Pads
x3
1mm
5mm
10mm
I
