Sida 1/3

PAD-WDM

Wall, Under Cabinet & Desk Mount

with 2 Mounting Bases for Tablets

(1) Mount Stand (2) Mounting Bases (6) Screws (6) Anchors

PAD-WDM

Removing the Mount Stand from the Mounting Base

Installing the Mount Stand to the Mounting Base

Adjusting the Mount

Twist the mount stand

off of the base

Pull on the tab to

cover the hole.

Slide on the plate.

Slide off the plate.

Note: You want the base of

the Mounting Stand to twist,

not just the Mounting Stand itself.

Remove the plate off of the Mounting

Base and twist the Mount Stand clockwise.

Once the Mount Stand is removed, slide

the plate back on and pull the tab to

extend a circular cover for the hole.

Slide the plate onto the Mounting Base.

Note: The plate will only

completely slide on if the

Mount Stand has been

thoroughly twisted into place.

Once the Mounting Stand is

installed (as shown above), you

may load your tablet.

By twisting the nut that attaches the mount to the

stand, you can adjust how loose or tight the

rotation mechanic is for the mount.

If you plan on using the Mounting Stand without installing the Mounting Base

to a surface, please be careful adjusting the arm extension. Overextension of

the arm or weight imbalances with heavier tablets will cause the product and

your device to fall over, resulting in possible damage.

Align the wedges of the Mount Stand with the

grooves of the Mounting Base and set the Mount

Stand into the Mounting Base. Then, twist the Mount

Stand to your left until you feel resistance and hold it.

Once the wedges of the Mount Stand

align with the grooves of the Mounting

Base, lift to remove the Mount Stand

from the Mounting Base.

Maximum Height: 16.38”

Compatible with tablets ranging 4 – 9 inches

in width, such as the Samsung Galaxy Tab S,

iPad Mini 4 or Google Nexus 9

Produktspecifikationer

Varumärke:	CTA Digital
Kategori:	Inte kategoriserad
Modell:	PAD-WDM
Inbyggda högtalare:	Nej
Korrekt användning:	inomhus
Modell:	Passiv hållare
Kompatibilitet:	Samsung Galaxy Tab S, iPad mini 4, Google Nexus 9
Minsta enhetsbredd:	101.6 mm
Produktens färg:	Vit
Strömkälla av typen:	Stöds inte
Mobilenhetens typ:	Surfplatta/UMPC
Maximumfunktion bredd:	228.6 mm
Maximumfunktion djup:	15 mm
Maximumfunktion höjd:	416 mm
