INSTRUCTION MANUAL

First applying the Air Bubble Washing System in the world.

Improving washing performance by more than 35%, while

reducing power consumption by 40%.

Applying One-Touch Operation System.

Realizing calm washing through the innovational low-noise

First applying the Radical Technology in the world ... go beyond

washing, sterilize your colthes and deodorize a bad smell.

design.

Before operating this washer, please read this instruction

completely. Thank you

Model: DWF-200M/240M

Full-Auto Electric Washing Machine

➣ Your washer is equipped with the

➣

Your washer is adopted the Radical

Technology that can sterilize your clothes

and deodorize a bad smell and prevent

discoloration.

bubble generator that generates a

great deal of air bubble.

➣ The air bubbles knock the dirt out

of the clothes during wash and

they push up the heavy dirt to

remove it during rinse.

➣ Because the double washing

method using both air bubble &

water current is applied to this

washer, wash efficiency is excellent

in comparison with the original

washer system.

The First Radical Technology and

Air Bubble Washing System in the World

CONTENTS Page

RTS AND FEATURES.......................................................2

WASHER SAFETY.................................................................3

INSTALLATION INSTRUCTIONS.........................................4

ELECTRICAL REQUIREMENTS..........................................5

INLET HOSE CONNECTION................................................6

OPERATING YOUR WASHER.............................................7

THE FUNCTIONS OF THE CONTROL PANEL.................8

WASHING PROCEDURE AND COURSE SELECTION

.......9

GENERAL PROCEDURE FOR OPERATION...................11

CARING FOR YOUR WASHER.........................................12

HOW TO CLEAN THE FILTER...........................................13

REMOVING STAINS............................................................14

TROUBLE SHOOTING........................................................15

SPECIFICATION..................................................................16

A NOTE TO YOU

Thank you for buying a DAEWOO appliance.

DAEWOO washers are easy to use, save time, and help you manage your home better.

This manual contains valuable information about how to operate and maintain your washer properly and safely.

Please read it carefully.

DWF-200/240M(101) 97.1.19 4:21 PM ˘ ` 1

WATER TAP ADAPTER INLET HOSE

PARTS AND FEATURES

DRYTEN (OPTION) COVER UNDER (OPTION)

HOSE DRAIN (FOR NON-PUMP) HOSE DRAIN CLAMP HOSE DRAIN (FOR PUMP) CONNECTOR INLET(OPTION)

DRYTEN

The parts and features of your washer are illustrated on this page.

Become familiar with all parts and features before using your washer.

NOTE

•

The drawings in this book may vary from your washer model.

They are designed to show the different features of all models covered by this book,

Your model may not include all features.

ACCESSORIES

• HOSE DRAIN

• POWER CORD

• LINT FILTER(2EA)

• HOT WATER TAP

• COLD WATER TAP

After using the washer,

close the water tap, In case

of the single valve model,

there is no hot water valve.

After using the washer,

close the water tap

In case of 3-wire power cord

ground wire will not be provided

• CASE DETERGENT

AND SOFTENER

• BLEACH INLET

• ADJUSTABLE LEG

• PULSATOR

• CONTROL PANEL

• GROUND WIRE(OPTION)

RINSE

234

SPIN

ECO.

HEAVY

FUZZY

NIGHT

WOOL

SOAK

BLANKET

FEED

DWF-200/240M(101) 97.1.19 4:21 PM ˘ ` 2

Read all instructions before using your washer

Save these instructions

Your safety is important to us.

To reduce the risk of fire, electrical shock, or injury when using your washer, follow

basic precautions including the following:

Understanding your responsibilities

• Do not wash items that are soiled with vegetable or cooking oil.

These items may contain some oil after laundering.

Due to the remaining oil, the fabric may smoke or catch fire by itself.

• Do not use chlorine bleach and ammonia or acid (Such as vinegar or rust remover) in the

same wash. Hazardous fumes can form.

• Unplug power supply cord before attempting to service your washer.

• Do not wash fiber glass materials.

Small particles can stick to fabrics and cause skin irritation.

• ˚ ˚ Do not use hot water that temperature is over 50 C (120 F).

It can cause a deformation of plastic parts.

• Do not spray water on the control panel and back cover of the washer.

It can cause a fire or an electric shock.

• Flammable fluids (dry-cleaning solvents,

kerosene, gasoline, etc.) should not be

used or stored in near your washer.

.Do not add flammable fluids to your wash

water.These substances give off vapors

that can create a fire hazard or explosion.

• Do not allow children to operate, play

with, or crawl on or inside your washer.

Supervise children closely when your

washer is used near them.

• After starting a cycle, do not reach into

the spin basket unless all motion stops.

• Do not tamper with the controls.

Please ...

• Have only a qualified person install, repair,

or replace parts on washer.

• Maintain washer properly.

• Protect washer from the weather and

keep it where the temperature will not fall

below freezing.

• Do not install the washer at a place of

extremely high humidity. It could cause an

Electrical shock or a short circuit.

• Connect washer to the correct outlet,

electrical supply, water supply, and drain.

• Ground washer properly.

WASHER SAFETY

• If the supply cord is damaged, it must be

replaced by the manufacturer or its service

agent or a similarly qualified person in order

to avoid a hazard

• If the appliance is supplied from a cord

extension set or electrical portable outlet

device it should be positioned so it is not

subjected to splashing or ingress of moisture.

DWF-200/240M(101) 97.1.19 4:21 PM ˘ ` 3
