Sida 1/28

INSTRUCTION MANUAL

COLOR TELEVISION

MODEL NO.

14D4M/20D4M/ 21D4M/14P2M

20P2M/21P2M/14Q2M/20Q2M

21Q2M/14S2M/20S2M/21S2M

14T2M/20T2M/21T2M/14U1M

20U1M/21U1M/14V1M/20V1M

21V1M/14K8MT/20K8MT/21K8MT

14V4M/20V4M/21V4M/14V4T

20V4T/21V4T/14U1T/20U1T/21U1T

14V1T/20V1T/21V1T/14D4T

20D4T/21D4T/14D3T/20D3T

21D3T/14D7T/20D7T/21D7T

14E5M/20E5M/21E5M/14S2T

20S2T/21S2T/21U3MTS/20T1TS

20T1ZS/20Q1TS/21T5TS/21U3T

2131N/2132N/2134N/2130N

21FL6N/2131NT/2132NT/2134NT

2130NT/21FL6NT/14D7N/20D7N

21D7N/14K8M/20K8M/21K8M

14S2/20S2/21S2/14D4/20D4

21D4/14V5TB/14V5TS/14V5TW

14Q1N/20Q1N/21Q1N

KR14E5 / KR20E5 / KR21E5

KR14E5M / KR20E5M / KR21E5M

KR14U1T / KR20U1T / KR21U1T

KR14U2T / KR20U2T / KR21U2T

KR14U3T / KR20U3T / KR21U3T

KR14V1T / KR20V1T / KR21V1T

KR14V4T / KR20V4T / KR21V4T

KR14V4 / KR20V4 / KR21V4

KR14D7T / KR20D7T / KR21D7T

KR14D7 / KR20D7 / KR21D7

KR14U1TS/KR20U1TS/KR21U1TS

KR14V1TS/KR20V1TS/KR21V1TS

KR14V4TS/KR20V4TS/KR21V4TS

KR14V5TB/KR14V5TS/KR14V5TW

KR21FL6M/KR2131FL/KR2132FL

KR2134FL/KR2132NT/KR2134NT

KR2130N/KR2131N/KR2132N

KR2134N/KR2130NT/KR2131NT

KR21FL6N/KR15U7FL/KR15U7T

KR15U5FL/KR15U5T/KR14V5T

KR20V5T/KR21V5T/KR14D4TS

KR14D3TS/KR20D3TS/KR21D3TS

KR14D4TS/KR20D4TS/KR21D4TS

KR14D4Z/KR20D4Z/KR21D4Z

KR1420Z/KR2020Z/KR2120Z

KR21FL6/KR15A1FL/KR15U7FL

KR15U5FL-2T/KR15U7FL-2T

Contents

Important safeguards 1

Before Operation 2

Connecting external equipment 3

Identification of Controls 5

Daily use 6

Menus 8

Teletext (Option) 14

The othello game 16

Specifications 18

Troubleshooting 19

This information is placed by The law of RF on

Protechion of the Consumer Rights and the

Governmental Resolution of RF No.720.

The working life of this set is 7 years since its

production date. After the working life, this set may

be not work properly and cause damage to the life

of the customer or his property.

Important safeguards

WATER AND MOISTURE

Never install the set in the following places : In a wet

basement, bathroom. Do not place any container with

liquid on the set.

The apparatus shall not be exposed to dripping or

splashing water and that no objects filled with liquids, such

as vases, shall be placed on the apparatus.

HEAT

Never place the set near heat sources.

VENTILATION

Do not cover the ventilation openings in the cabinet and

never place the set in a confined space such as a

bookcase or built-in unless proper ventilation is provided.

Leave a minimum 10cm gap all around the unit.

OBJECT ENTRY

Do not insert foreign objects, such as needles and coins,

in the ventilation openings.

LIGHTNING STRIKING

You should disconnect the set from the mains and the

aerial system during thunderstorms.

CLEANING

Unplug the set from the mains during cleaning.

AFTER MOVING THE SET

If the set is moved in a different direction, the MAIN

POWER button must be switched off for at least 15

minutes in order to take out a colour strain on the screen.
